While* Language Support for VS Code

A VS Code extension for While* - an educational programming language designed for teaching programming fundamentals, type systems, and formal program verification.

What is While*?

While* is a simple imperative programming language used in computer science education. It's intentionally minimal so students can focus on core concepts like:

• Basic imperative programming (variables, loops, conditionals)
• Type systems and type safety
• Formal verification using Hoare logic
• Program analysis and control-flow reasoning

Useful links:

• Online While* editor
• While* project at AQUA

What does this extension do?

This extension turns VS Code into a complete development environment for While*. You get:

• 🎨 Syntax highlighting - Your code looks nice with proper colors
• ⚡ Live error checking - Typos and mistakes are underlined as you type
• ▶️ Run programs - Execute your While* code and see the output
• 🐛 Visual debugger - Step through code line-by-line with inline variable values
• ✅ Type checker - Verify your program is type-correct
• 🔍 Proof verifier - Check formal correctness proofs (for Hoare logic assignments)
• 📊 Dataflow analyses - Run liveness, reachability, reaching-definitions, and taint analyses
• 🕸️ Mermaid CFG visualization - View rendered control-flow and transition graphs directly in the extension
• 🔁 Transition CFG support - Inspect the transition system used for program reasoning

Supported While* Features

The extension supports modern While* workflows beyond editing and execution:

• Program execution and interactive debugging
• Type checking and Hoare-style proof checking
• Dataflow analyses:
  • Liveness analysis
  • Reachability analysis
  • Reaching definitions analysis
  • Taint analysis
• Transition CFG generation
• Visual graph rendering for CFG-based analyses

Installation from VSIX

1. Download the .vsix file
2. Open VS Code
3. Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (Mac)
4. Type "Install from VSIX" and select it
5. Choose the downloaded file
6. Reload VS Code

Done! No other setup needed - everything is bundled.

Quick Start

1. Create a new file called test.wstar
2. Write some While* code (example below)
3. Press Ctrl+Shift+P and type "WhileStar: Run Code"
4. See your output!

Example WhileStar program:

vars:
pre: (false)
code:
  print "Hello world!";
post: (true)

Available Commands

Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) and search for:

• WhileStar: Open Interpreter - Opens visual interpreter
• WhileStar: Run Code - Execute your program and see output
• WhileStar: Debug Code - Step through your code with visual debugging
• WhileStar: Type Check Code - Verify your program's types are correct
• WhileStar: Proof Check Code - Verify Hoare logic proofs (if your code has annotations)
• WhileStar: Run Liveness Analysis - Compute liveness information
• WhileStar: Run Reachability Analysis - Compute reachable program states
• WhileStar: Run Reaching Definitions Analysis - Inspect reaching definitions
• WhileStar: Run Taint Analysis - Inspect information-flow/taint propagation
• WhileStar: Show Transition CFG - Show the transition control-flow graph

Local Development

Prerequisites

• Node.js 18 or higher
• pnpm package manager
• VS Code

Setup

1. Install dependencies:

pnpm install

2. Build the extension:

pnpm run build

3. Start debugging:
   • Press F5 in VS Code or run "Debug: Start Debugging" command
   • This opens a new VS Code window with the extension loaded
   • Test your changes there

Authors

• Richard Stewing
• Assanali Uzakov

Credits

This extension builds on:

• wvm - The While* interpreter and verifier
• Langium - Parser generator framework
• Previous work on While* language tooling

Originally developed as a Bachelor thesis project at TU Dortmund University.

License

MIT License - see LICENSE file for details.
