Protos VS Code integration

This directory is the approved current home for the Protos reference VS Code integration.

The extension is intentionally thin and declarative at this stage. Protos language semantics remain owned by ../../spec/PROTOS_GRAMMAR.md and the real parser/runtime/resolver authorities; the VS Code surface must not become a second implementation of the language.

Current LM009-B assets:

• package.json — declarative VS Code extension manifest;
• language-configuration.json — comments and structural delimiter behavior;
• syntaxes/protos.tmLanguage.json — non-normative TextMate grammar;
• test/fixtures/lexical.protos — representative valid Protos source;
• test/validate_grammar.py — lexical-asset structural guard; and
• test/validate_extension.py — manifest/language-association/configuration structural guard.

The approved manifest identity and compatibility floor are:

extension id:    guillermomolina.protos
extension name:  protos
publisher:       guillermomolina
extension ver.:  0.1.0
engines.vscode:  ^1.104.0
language id:     protos
file extension:  .protos
TextMate scope:  source.protos

The extension version is intentionally independent from the Protos Maven/runtime implementation version. The VS Code support floor is not raised merely because a new Stable version exists; a future increase requires a concrete editor API or dependency need introduced after VS Code 1.104.

Local validation

From editors/vscode/:

npm ci
npm run build
npm run package:assets
python3 test/validate_grammar.py
python3 test/validate_extension.py
python3 test/validate_packaging.py
node test/run_current_file.test.js
node test/debug_integration.test.js
node test/language_server_integration.test.js

D127 Candidate B′ makes the editor dependency build reproducible: the npm lockfile is committed, npm ci is the clean-install path, and the production entry point is dist/extension.js. The generation-1 bundle is built with pinned esbuild and keeps VS Code's host-provided vscode module external while bundling the JavaScript vscode-languageclient closure and the local debug adapter.

@vscode/vsce is pinned as build/packaging tooling. I1-B adds the explicit VSIX boundary: package-root license.txt, deterministic THIRD_PARTY_NOTICES.txt, .vscodeignore, and an exact artifact-content guard. The package command is:

npm run package:vsix -- --out /tmp/protos.vsix
python3 test/validate_vsix.py /tmp/protos.vsix

The VSIX contains only the bundled runtime client, declarative editor assets, README, icon and required license/notices. Raw node_modules, tests, fixtures, source-only editor JavaScript, build scripts, the npm lockfile and esbuild metafile do not ship.

When bundled npm dependencies or the project license change, regenerate the tracked package assets after npm ci && npm run build with:

node scripts/sync_package_assets.js

Normal packaging runs the same generator in --check mode and fails closed if the committed license/notices are stale. Generated dist/, node_modules/, and *.vsix files remain repository artifacts only and are not committed.

Node/npm remains an editor-development/packaging concern only; ordinary Protos Maven/runtime development and execution do not depend on Node/npm. The real Protos runtime/language server remains external through protos.runtime.executable.

S1 live VS Code check

The manifest can be loaded directly as an extension-development path without publishing anything to Marketplace:

cd editors/vscode
npm ci
npm run build
code --new-window --extensionDevelopmentPath="$PWD"

In that VS Code window, open test/fixtures/lexical.protos and verify:

1. the language mode is Protos;
2. .protos receives the source.protos TextMate grammar;
3. // and /* ... */ are recognized as the configured comment forms; and
4. (), [], and {} use the structural bracket configuration.

LM009-B S1 was completed by the project owner on 2026-09-10 in a real VS Code Extension Development Host: .protos was recognized as Protos, highlighting was active, the configured line/block comment actions worked, and structural delimiter auto-closing worked. The steps above remain the reproducible live editor check; the repository-side validators complement rather than replace it.

No VSIX/Marketplace release is performed by LM009-B, and no Run action, DAP/LSP client, runtime-discovery policy, formatter, parser, or TypeScript semantic model is introduced here.

Run current Protos file (LM009-C)

Protos: Run Current File executes the active file through the real external Protos launcher. The extension does not evaluate Protos itself and does not reconstruct Java/JAR internals.

Runtime resolution is intentionally small:

protos.runtime.executable

is a machine-scoped setting whose default is protos, resolved through the extension host's ordinary PATH. Configure it in User/Remote settings when the launcher is installed elsewhere, for example:

{
  "protos.runtime.executable": "/absolute/path/to/protos"
}

The configured value is passed directly to VS Code ProcessExecution; it is not interpolated into a shell command. The source filename is a separate process argument, so spaces in launcher/source paths do not create shell-quoting policy.

The Run action requires:

• a trusted VS Code workspace/window;
• an active protos document backed by either the local file: filesystem or VS Code Remote's vscode-remote: workspace filesystem;
• a successful save first when the document is dirty.

The executable integration is explicitly a VS Code workspace extension, so it runs where the workspace and configured Protos launcher live. Local file: resources use ordinary Uri.fsPath. For vscode-remote:, the decoded URI path is first converted to a file: URI in that workspace extension host and only then converted to the host-native filesystem path. The extension never treats a remote URI's fsPath as if it belonged to the UI machine.

Other schemes, including virtual-workspace resources such as vscode-vfs:, are not executable by Run Current File. Safe language association and highlighting remain available; LM009-C simply does not fabricate a filesystem path that an external launcher cannot consume.

Execution uses a VS Code Task with a dedicated, revealed terminal. Its working directory is always the current file's parent directory. LM009-C does not add application arguments, workspace/package-module execution, Java/JAR discovery, or debugger behavior.

In Restricted Mode, Protos syntax highlighting remains available but execution is blocked. protos.runtime.executable is also listed as a restricted configuration, and the command implementation independently checks workspace.isTrusted before any process can be started.

S2 live VS Code check

After the LM009-C run-wiring tranche is published, load the extension from editors/vscode/ in an Extension Development Host or install a local test VSIX, ensure a real Protos launcher is available through PATH or protos.runtime.executable, trust the test window, and open an ordinary standalone .protos file. Local file: and VS Code Remote vscode-remote: resources are valid execution surfaces when the launcher exists in the same workspace extension-host environment.

Invoke:

Protos: Run Current File

The S2 live check passes when the dedicated Task terminal shows the real Protos program's stdout/stderr and ordinary task/process completion outcome, with the source executed from its parent directory.

LM009-C S2 was completed by the project owner on 2026-09-10 in a real VS Code Dev Container with the repaired workspace extension. The installed guillermomolina.protos 0.1.0 extension recognized .protos, exposed Protos: Run Current File for the vscode-remote: resource, and the command successfully executed the current source through the real external Protos launcher. LM009-C is therefore CLOSED; packaging/Marketplace remains LM009-I.

The current supported end-user distribution is POSIX/JVM, but this editor contract is not POSIX-specific: it consumes a directly executable Protos launcher. A future Windows/native launcher can satisfy the same contract without changing the editor command semantics.

Debug Protos in VS Code (LM009-E)

LM009-E consumes the public debugger launcher closed by LM009-D; the extension does not construct GraalVM options or implement a second debug adapter.

The ordinary single-file path is F5 with an active executable Protos document. A launch.json file is not required for that case. The in-memory configuration is equivalent to:

{
  "type": "protos",
  "request": "launch",
  "name": "Debug Protos File",
  "program": "${file}",
  "args": []
}

For repeatable configurations, the same shape may be stored in launch.json. program must resolve to an absolute path in the workspace extension host, and args contains ordinary application arguments passed after the source file.

The runtime executable is the same machine-scoped protos.runtime.executable setting used by Run Current File. The extension starts it directly, without a shell, as:

protos debug <absolute-source-file> [application-args...]

The launcher publishes exactly one D060 startup record on stdout:

PROTOS_DEBUG_READY {"version":1,"protocol":"dap","transport":"tcp","host":"127.0.0.1","port":54321}

The extension validates that record, including a numeric loopback endpoint, and returns a VS Code DebugAdapterServer descriptor. VS Code then speaks DAP directly to the real GraalVM adapter. The extension does not choose a port, probe sockets, parse raw GraalVM readiness, relay DAP messages, or introduce a readiness file.

Launcher diagnostics are shown through the Protos Debug output channel. Guest stdout/stderr remains debugger output delivered by DAP. The extension retains only one launcher child handle per active debug session and has no global port or session registry.

Debug execution remains disabled in Restricted Mode. As with Run Current File, the executable extension runs in the VS Code workspace extension host, so local and Dev Container/Remote sessions use the launcher and filesystem of that workspace host.

The LM009-E baseline intentionally exposes only request: "launch". Attach, remote-network listen configuration, stop-on-entry, readiness-file discovery and a stronger terminateDebuggee promise remain outside this slice.

S3 live VS Code check

Repository-side Node/Python tests validate the orchestration contract but do not close LM009-E. After the E1 wiring is published, S3 must still be exercised in a real VS Code extension host against the real external Protos launcher.

Set a source breakpoint in an ordinary .protos file and press F5. S3 requires live evidence for: breakpoint stop location, threads, stack, activation-local scope, representative scalar/indexed values, step, continue, guest output and clean normal termination. The project owner live check is the acceptance surface; Marketplace publication remains LM009-I.

Language server foundation (LM009-F4)

LM009-F4 consumes ratified PLAT024 and D070. The reference extension stays a thin standard-LSP client and starts the language server through the same selected toolchain executable already used by Run and Debug:

protos.runtime.executable
        +
["language-server"]

The resulting public command is:

protos language-server

The extension uses vscode-languageclient and passes the executable plus argv directly with shell: false. It does not know the Java main class, JAR/classpath layout, or whether a future implementation behind the launcher is JVM, Native Image, a sibling binary, or self-hosted Protos.

The client selects Protos documents by language id only. Their LSP URI and exact editor text are sent through standard document synchronization to the F3 server; the extension does not infer package, module, workspace or filesystem identity from those URIs. Those authorities remain server/toolchain responsibilities for later LM009-G/H work.

The language server is client-session-owned and runs in the workspace extension host. Local, Remote SSH and Dev Container sessions therefore use the same toolchain namespace already selected for Run/Debug. Restricted Mode starts no language-server process; after Workspace Trust is granted, the same controller may start it normally.

F4 adds no diagnostics, symbols, definition, references, completion, hover or signature-help semantics. Those remain LM009-G/H.

S4 foundation live VS Code check

Repository tests prove the CLI/LSP framing and thin client launch contract, but LM009-F closure still requires one real VS Code host check.

After building the current Protos launcher and running npm install --no-package-lock in editors/vscode/, open the extension through an Extension Development Host (or an equivalent local test installation), point protos.runtime.executable at that exact current launcher and open a .protos document.

The foundation live check is:

1. opening the Protos document starts exactly one matching protos language-server child in the workspace extension host;
2. editing the document leaves the server healthy while normal LSP open/change/close synchronization is exercised;
3. no second server-path setting or Java/JAR command is required;
4. closing/reloading the Extension Development Host stops the client-owned server process cleanly; and
5. no static language feature is claimed yet merely because the foundation is alive.

Once this live composition is confirmed, LM009-F can close and LM009-G can own the first visible static diagnostics/symbol/definition features.

Remote/Dev Container LSP URI bridge (LM009-G5A)

The language server remains editor-neutral and file-system based even when the reference extension runs in a VS Code Remote or Dev Container workspace. In an all-vscode-remote: workspace whose folders share one exact remote authority, the thin client translates editor URIs to file: URIs before they cross the LSP boundary and translates server-returned file: URIs back to that same vscode-remote: authority.

This bridge lets the server consume the canonical workspace-host paths already used by ProjectBinding for workspace/symbol and lets definition/symbol locations navigate back through VS Code without teaching the Java language server about VS Code-specific URI schemes. Local file: workspaces are unchanged. Mixed schemes, missing remote authority, multiple remote authorities and foreign remote authorities are not guessed or normalized; conversion fails closed to the ordinary URI representation instead.
