Satori (Preview)

⚠️ This extension is in active development. Functionality may change.

Interactive visualizer for Flutter/Dart projects

Satori transforms your Flutter code into interactive diagrams, allowing you to explore relationships between classes, dependencies, data flow, and project structure with a modern visual interface.

🚀 Quick Start

1. Install prerequisites: Ensure Dart-Code extension is installed and active
2. Open a Flutter/Dart project in VS Code
3. Wait for Dart analysis to complete (status bar shows "Analysis complete")
4. Press Ctrl+Shift+P → "Satori: Show Project Diagram"
5. Select project folder when prompted

✨ Main Features

🎯 Automatic Architectural Analysis

• Layer classification: View, State, Service, Model, Utility

🌐 Interactive Visualization

• Overview View: Navigation through architectural layers
• Focus View: Detailed exploration of classes and their members
• List View: Search and filtering by components
• Folder navigation: Hierarchical project exploration

🔗 Relationship Analysis

• Inheritance: extends, implements, with
• Calls: Methods and functions (local project only)
• Dependencies: Types and instantiation (limited to VS Code's built-in symbol analysis)
• Data flow: Basic detection using the Dart extension's capabilities

Note: Current analysis focuses on structural relationships. Semantic analysis of internal responsibilities and decisions is in development.

📦 Package Management

• External dependency analysis: pub.dev, custom packages
• Import visualization: Relationships between project and packages
• Automatic classification: SDK, official, third-party, local

🛠️ Advanced Features

• Smart navigation: Click-to-code from diagram
• Details panel: Contextual information and collaborations
• Navigation slider: Exploration by abstraction levels

📋 Use Cases

• Refactoring: Identify dependencies before moving classes
• Code Review: Visualize architectural change impact
• Onboarding: Understand new project structure
• Documentation: Automatically generate architecture views

🚀 Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "Satori"
4. Click "Install"

⚙️ Configuration

Prerequisites

• Dart extension: Official Dart-Code extension must be installed and active
• VS Code: 1.74.0 or higher

Initial Setup

{
  "Satori.enableDebugLogs": false,
  "Satori.language": "en"
}

📖 Usage

1. Overview View - Architectural Exploration

Command: "Satori: Show Project Diagram"
Shortcut: Ctrl+Shift+P → Search "Show Project Diagram"

• Navigate through architectural layers (View, State, Service, Model)
• Each layer shows the number of components
• Click to see detailed list of each layer

2. Focus View - Detailed Analysis

• From Overview: Click on any component
• From List: Click on specific element
• Direct navigation: Click on relationships in details panel

Focus View Features:

• 🎯 Central node: The analyzed component with all its members
• ⬅️ Predecessors: Components that depend on the focus
• ➡️ Successors: Components that the focus depends on
• ⬆️ External imports: Dependencies on consumed packages
• ⬇️ Developed imports: Project's own modules

3. Folder Navigation

Navigation slider: Exploration by abstraction levels
💡 Specific → 🌱 Folder → 🏞️ Feature → 🌍 Project

4. Details Panel

• Smart collaborations: Natural language descriptions
• Node clicks: Quick navigation between components
• Visual categorization: UI, Logic, Data, Inheritance

🎨 Visual Interface

Color Scheme by Layers

• 🔵 View: UI Components (Widgets, Screens)
• 🟡 State: State management (BLoC, Provider, Controller)
• 🟢 Service: Services and repositories (API, Database)
• 🟠 Model: Data models (DTOs, Entities)
• ⚪ Utility: Helpers and utilities

Relationship Types

• 🟢 Extends: Class inheritance
• 🔵 Implements: Interface implementation
• 🟣 Calls: Method calls
• 🟠 Reads From: Data reading
• 🔴 Writes To: Data writing

🔧 Available Commands

⚠️ Known Limitations

Important: This extension is in preview. Some functionality is under development.

• Large projects: Analysis may take time on projects with >1000 files
• Complex generics: Some generic type relationships may not be detected
• Generated code: .g.dart files are processed but may create noise
• Semantic analysis: Internal responsibilities and decisions are in development
• External packages: Analysis limited to main public symbols
• Dart extension dependency: Requires the official Dart extension to be installed and active
• Symbol analysis: Depends on the Dart extension's language server for symbol information

🛠️ Development and Contribution

Environment Setup

# Clone repository
git clone https://github.com/your-repo/satori.git
cd Satori

# Install dependencies
npm install

# Compile TypeScript
npm run compile

# Run in development mode
F5 (from VS Code)

Project Structure

src/
├── extension.ts              # Main entry point
├── ui/                       # User interface
│   ├── extension_lifecycle.ts
│   ├── webview_creator.ts
│   └── providers/
├── analysis/                 # Code analysis
│   ├── symbol_processor.ts
│   ├── symbol_transformer.ts
│   └── enrichment/
├── graph/                    # Graph construction
│   ├── graph_builder.ts
│   ├── node_creator.ts
│   └── edge_creator.ts
├── packages/                 # Package management
│   └── graph_integration/
├── lsp/                      # LSP integration
├── core/                     # Utilities and algorithms
└── types/                    # Type definitions

Testing

# Run tests
npm test

# Test with coverage
npm run test:coverage

🛟 Troubleshooting

Dart Extension Issues

1. Ensure the official Dart extension is installed and active
2. Verify the Dart extension can analyze your project files
3. Check that dart pub get has been run in the project

Incomplete Analysis

1. Run dart pub get in the project
2. Restart VS Code
3. Enable debug logs: satori.toggleDebugLogs

Performance Issues

• Close other large projects in VS Code
• Verify available memory (>4GB recommended)
• Consider modular analysis for very large projects

📄 License

MIT License - See LICENSE for more details.

🤝 Contributing

Contributions are welcome! Please:

1. Fork the project
2. Create a feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

Roadmap

• [ ] Support for incremental analysis
• [ ] Diagram export (PNG, SVG)
• [ ] Integration with documentation tools
• [ ] Quality metrics analysis
• [ ] Support for other languages (Kotlin, Swift)
• [ ] Improved symbol analysis independent of external extensions
• [ ] Enhanced relationship detection

🙏 Acknowledgments

• Dart/Flutter team for the excellent Language Server Protocol
• VS Code community for development tools
• D3.js for visualization capabilities
• All contributors and beta users

Problems or suggestions?

• GitHub Issues
• Discussions

Give it a ⭐ if Satori helps you understand your Flutter code better!
