Git (VsGit) for VS Code

A full-featured, Git client for VS Code. VsGit spawns the git binary directly — no libgit2, no reimplementation of git in JavaScript — and surfaces 160+ commands across every Git workflow through dedicated views, webviews, and an interactive commit graph.

The images in this README are static illustrations of the interface (the graph is rendered exactly this way from live repository data); they are not live photographs of a running editor.

Table of contents

• Why VsGit
• Highlights
• Screenshots
• Views & features
• Advanced operations
• Keyboard shortcuts
• Getting started
• Settings
• Architecture
• Security model
• Development
• Requirements
• License

Why VsGit

VS Code ships with a capable Source Control panel, but power users coming from Eclipse's EGit, gitk, git-cola, or standalone graph tools often want more: a real commit graph, worktrees, interactive rebase, LFS, notes, bisect, subtree, Gerrit, and per-commit operations without dropping to a terminal.

VsGit fills that gap by driving the real git CLI. Because every operation is a genuine git invocation, behaviour matches your shell exactly — the same config, hooks, credential helpers, and aliases apply.

Highlights

• 🌳 Interactive commit graph — an SVG-rendered DAG with colour-coded branch lanes, inline ref pills, an expand-in-place commit-details row, flow tracing, fuzzy find, and a full right-click action menu.
• 📜 History view — paginated log with the same robust graph renderer, branch/author/message/date filtering, and a Compare-Branches mode.
• 🗂️ Rich sidebar — Repositories, Staging, Synchronize, Conflicts, Reflog, Worktrees, and Compare trees, all multi-root aware.
• ✍️ Commit webview — stage by hunk, GPG-sign, DCO sign-off, amend.
• 🔧 Everything else — interactive rebase, LFS, notes, bisect, subtree, archive, patch, Gerrit, submodules, and a built-in git-config editor.
• 🔒 Safe by construction — git is always spawned with an argv array (never a shell), refs are guarded against option injection, and the credential/editor IPC channels are authenticated with a per-session token.

Screenshots

Git Graph

Colour-coded lanes, HEAD → main / remote / tag ref pills, a selected-row commit-details panel (metadata on the left, changed files on the right), and Eclipse Git-style columns: Graph · Description · Author · Authored Date · Committer · Committed Date (each toggleable).

Activity bar & trees

The VsGit container uses its own commit-graph logo (distinct from the built-in Source Control icon) and hosts the Repositories and Staging trees, among others.

Views & features

Repositories view

• Multi-root workspace support with per-repo ahead/behind indicators.
• Full tree of branches, remotes, tags, stashes, submodules, and worktrees.
• Inline checkout, push, pull, fetch, merge, and rebase from tree nodes.
• Switch To quick picker (⌘⇧G B / Ctrl+Shift+G B) across all branches and tags.
• Sequencer controls (Continue / Skip / Abort) appear automatically during an in-progress rebase, merge, cherry-pick, or revert.

Staging view & Commit webview

• Staged / Changes / Conflicts groups.
• Hunk-level stage and unstage (forward/reverse patch apply to the index).
• Commit with GPG sign (-S) and DCO sign-off options, or amend the last commit (message prefilled).

History view

• Paginated commit log (page size configurable) rendered with the shared, unit-tested graph layout — branch lanes stay connected across rows.
• Filter by branch, author, or message; restrict by date range.
• Per-commit context menu: checkout (detached), create branch/tag, cherry-pick, revert, reset (soft / mixed / hard), compare with HEAD or another commit, copy SHA, and show full details.
• Compare Branches mode for a symmetric A...B diff.
• Commits are loaded in --topo-order so a child always precedes its parents, which is what the lane layout needs to draw a correct graph.

Git Graph

• SVG-rendered commit graph: one overlay path system spanning every row, so edges never break apart between rows.
• Inline ref labels, an expand-at-selection commit-details row, and Ctrl/Cmd-click to compare any two commits.
• Flow tracing: highlight ancestors / descendants of the selected commit.
• Find (Ctrl/Cmd+F) across message, author, hash, and ref names.
• Toolbar: per-repo Pull / Push / Fetch / Commit / Branch / Merge / Stash with ahead/behind badges, plus an in-progress operation banner.
• Right-click any commit or ref pill for the full action menu (checkout, branch, tag, merge, rebase, cherry-pick, revert, drop, reset, compare, copy SHA; branch/tag/stash management on ref pills).

Compare view

• Side-by-side branch/ref comparison tree listing commits unique to each side and all changed files; click a file to open a diff.

Synchronize view

• Incoming (behind) and outgoing (ahead) commits vs the configured upstream; right-click to cherry-pick or checkout any incoming commit.

Conflict resolution

• Conflicts view lists every conflicted file with Use Ours / Use Theirs / Open Merge Editor / Mark Resolved, backed by VS Code's built-in 3-way merge.

Reflog view

• Browse git reflog and checkout or reset to any entry.

Advanced operations

Interactive rebase and commit-message editing are routed back into VS Code via a small editor shim wired to GIT_SEQUENCE_EDITOR / GIT_EDITOR, so git rebase -i opens a native editor instead of a terminal vi session.

Keyboard shortcuts

All 160+ commands are also available from the Command Palette under the Git (VsGit) category.

Getting started

VsGit isn't published to the Marketplace yet; build and install it from source.

git clone https://github.com/ajaykontham/git-vscode
cd git-vscode
npm install
npm run build                 # bundle the extension into dist/
npx vsce package --no-dependencies -o vsgit.vsix
code --install-extension vsgit.vsix

Or run it live in the Extension Development Host: open the folder in VS Code, run npm run watch, then press F5.

Once installed, click the VsGit icon in the activity bar, or run Git (VsGit): Show Git Graph from the Command Palette.

Settings

All settings live under the vsgit.* namespace.

There's also a graphical Git Config editor (⌘⇧G ,) for editing local / global / system git config, and a Remotes manager.

Architecture

src/
  extension.ts            activation: registers commands, views, providers
  git/
    GitExecutor.ts        the ONLY place git is spawned (argv array, no shell)
    Repository.ts         per-repo cached state + all git operations
    RepositoryManager.ts  multi-root discovery + change notifications
    GitContentProvider.ts vsgit: URIs that feed VS Code's diff editor
    argGuard.ts           option-injection guards (safeRef / safeRemoteUrl)
    parsers/              pure, unit-tested output parsers
                          (log, graphLog, status, refs, diff, blame, config,
                           reflog, rebaseTodo, worktree)
  views/                  tree data providers (Repositories, Staging, …)
  webviews/               webview panels (Graph, History, Commit, pickers)
  services/               auto-fetch, file-system watcher, status bar
  util/                   IPC servers (askpass / editor) + helpers
resources/
  graphLayout.js          shared, unit-tested commit-graph layout (UMD)
  graph.js / graph.css    Git Graph panel client
  askpass.js              GIT_ASKPASS shim
  sequence-editor.js      GIT_SEQUENCE_EDITOR / GIT_EDITOR shim
  icon.svg                activity-bar logo

Key design points:

• One spawn site. Every git call funnels through GitExecutor, which uses child_process.spawn(gitPath, args) with an argv array — never a shell string.
• Machine-readable output. Operations request NUL-/porcelain-formatted output and parse it in small, pure functions under git/parsers/, each with tests.
• One graph layout. Both the Git Graph panel and the History view import the same resources/graphLayout.js (a UMD module that also loads in Node), so there is a single, verified implementation of lane layout and edge geometry.
• Live refresh. A file-system watcher plus RepositoryManager.onDidChange keep every view in sync after internal or external git changes.

Security model

• No shell. Git is spawned with an argv array, so shell metacharacters (;, |, $(), backticks) are inert.
• Option-injection guards. Refs, SHAs, branch names, and remote URLs coming from webview messages or rendered commit data are validated by safeRef / safeRemoteUrl: values beginning with - (which git would parse as options) are rejected, as are the ext:: / fd:: remote-helper transports that can run arbitrary commands.
• Authenticated IPC. Credential prompts (GIT_ASKPASS) and rebase/commit editing run over a unix socket / named pipe whose name is enumerable by other local processes. Each session generates a random token, passed to the shim only via its environment; the server rejects any connection that doesn't echo it — preventing local credential phishing or edit injection. Credential prompts are masked unless they explicitly ask for a username.

Development

npm install
npm run watch        # esbuild in watch mode; F5 launches the dev host
npm run check-types  # tsc --noEmit
npm run build        # production bundle into dist/
npm test             # compile + run the unit-test suite

Testing

Tests run on Node's built-in test runner (node --test) — no VS Code instance required. They cover the pure logic that's most worth pinning down:

• every output parser under src/git/parsers/ (log, graph-log, status, refs, diff, blame, config, reflog, rebase-todo, worktree),
• the shared commit-graph layout (resources/graphLayout.test.js),
• the argument guards and the IPC token comparison.

npm test     # 60 tests

CI (GitHub Actions) runs type-check, build, the test suite, and packages the VSIX on every push and pull request.

Requirements

• VS Code 1.85+
• git 2.20+ on $PATH (or set vsgit.git.path)
• git-lfs for the LFS commands (optional)

License

MIT
