figdeck VS Code Extension

VS Code extension for figdeck - Markdown to Figma Slides.

Features

Snippets

Quick insertion of figdeck-specific syntax:

• figdeck-global - Global frontmatter with background, color, align, valign
• figdeck-slide - New slide with separator
• figdeck-transition - Slide with transition animation
• :::columns2/3/4 - Column layouts (2-4 columns)
• :::figma - Figma link block
• figdeck-gradient - Gradient background
• And more...

Syntax Highlighting

Enhanced highlighting for figdeck-specific syntax:

• :::columns / :::column / :::figma directives
• key=value attributes (link, gap, width, x, y, hideLink, text.*)
• Image size/position specs (w:, h:, x:, y:)

Slide Outline

Tree view in the Explorer sidebar showing all slides:

• Click to jump to slide
• Shows slide number and title
• Updates automatically on document changes

Commands:

• figdeck: Go to Next Slide
• figdeck: Go to Previous Slide

Diagnostics

Real-time validation of figdeck Markdown:

• Unclosed frontmatter blocks
• Unsupported image formats
• Invalid image size/position values
• Missing link= in :::figma blocks
• Invalid Figma URLs
• Column count validation
• Gap/width parameter validation

Quick Fixes

CodeActions to fix common issues:

• Add link= property to figma blocks
• Clamp gap to maximum value

CLI Integration

Run figdeck commands from VS Code:

• figdeck: Init slides.md - Create new slides file
• figdeck: Build JSON (current file) - Build to JSON
• figdeck: Start Serve - Start WebSocket server
• figdeck: Stop Serve - Stop WebSocket server
• figdeck: Restart Serve - Restart WebSocket server
• figdeck: Show Output - Show output channel

Status bar shows serve status and port.

Settings

CLI Detection

The extension looks for figdeck CLI in this order:

1. node_modules/.bin/figdeck in workspace
2. figdeck in PATH
3. figdeck.cli.command setting

If not found, you'll be prompted to install or configure it.

Development

Build Commands

cd packages/vscode

# Build for production (minified)
bun run build

# Build for development (with sourcemaps)
bun run build:dev

# Watch mode for development
bun run dev

# Type check
bun run typecheck

# Run tests
bun test src

Debugging

The project includes VS Code launch configurations in .vscode/ for debugging the extension.

Quick Start

1. Open the figdeck workspace in VS Code
2. Press F5 (or Run > Start Debugging)
3. Select "Run Extension" configuration
4. A new VS Code window (Extension Development Host) will open
5. Open a Markdown file with figdeck: true in frontmatter to activate the extension

Available Launch Configurations

Available Tasks

Run via Cmd+Shift+P > "Tasks: Run Task":

Debugging Tips

• Breakpoints: Set breakpoints in src/ files. Sourcemaps are enabled in dev builds.
• Console output: View extension logs in the Debug Console panel.
• Reload extension: In the Extension Development Host, run Developer: Reload Window to reload after code changes.
• Watch mode: Use "Run Extension (Watch)" for automatic rebuilds on file changes.

Configuration Files

The debug configuration files are located in the repository root .vscode/ directory:

{
  "version": "0.2.0",
  "configurations": [
    {
      "name": "Run Extension",
      "type": "extensionHost",
      "request": "launch",
      "args": [
        "--extensionDevelopmentPath=${workspaceFolder}/packages/vscode"
      ],
      "outFiles": [
        "${workspaceFolder}/packages/vscode/dist/**/*.js"
      ],
      "sourceMaps": true,
      "preLaunchTask": "vscode: build dev"
    },
    {
      "name": "Run Extension (Watch)",
      "type": "extensionHost",
      "request": "launch",
      "args": [
        "--extensionDevelopmentPath=${workspaceFolder}/packages/vscode"
      ],
      "outFiles": [
        "${workspaceFolder}/packages/vscode/dist/**/*.js"
      ],
      "sourceMaps": true,
      "preLaunchTask": "vscode: watch"
    }
  ]
}

{
  "version": "2.0.0",
  "tasks": [
    {
      "label": "vscode: build dev",
      "type": "shell",
      "command": "bun",
      "args": ["run", "build:dev"],
      "options": {
        "cwd": "${workspaceFolder}/packages/vscode"
      },
      "group": "build",
      "problemMatcher": "$esbuild"
    },
    {
      "label": "vscode: watch",
      "type": "shell",
      "command": "bun",
      "args": ["run", "dev"],
      "options": {
        "cwd": "${workspaceFolder}/packages/vscode"
      },
      "isBackground": true,
      "group": "build",
      "problemMatcher": {
        "owner": "esbuild",
        "pattern": {
          "regexp": "^✘ \\[ERROR\\] (.+)$",
          "message": 1
        },
        "background": {
          "activeOnStart": true,
          "beginsPattern": "^\\[watch\\]",
          "endsPattern": "^\\s*dist/extension\\.js"
        }
      }
    },
    {
      "label": "vscode: build",
      "type": "shell",
      "command": "bun",
      "args": ["run", "build"],
      "options": {
        "cwd": "${workspaceFolder}/packages/vscode"
      },
      "group": "build",
      "problemMatcher": "$esbuild"
    },
    {
      "label": "vscode: test",
      "type": "shell",
      "command": "bun",
      "args": ["test", "src"],
      "options": {
        "cwd": "${workspaceFolder}/packages/vscode"
      },
      "group": "test",
      "problemMatcher": []
    }
  ]
}

License

MIT
