RTK Map Hook Navigator

A VSCode extension that provides intelligent navigation from Redux Toolkit Query (RTK Query) auto-generated hooks directly to their endpoint definitions using both CodeLens annotations and "Go to Definition" functionality.

🎯 Overview

When working with RTK Query, hooks are automatically generated from endpoint definitions. This extension bridges the gap by providing two navigation methods:

1. CodeLens Annotations: Clickable annotations above hook names showing → endpointName
2. Go to Definition: Standard VSCode navigation (F12, Ctrl+Click) from hooks to endpoints

✨ Features

• Smart CodeLens Detection: Automatically detects RTK Query hook destructuring patterns and adds clickable annotations
• Go to Definition Support: Navigate from exported hooks to their endpoint definitions with F12 or Ctrl+Click
• Multiple Format Support: Handles all common RTK Query export patterns (single-line, multi-line)
• TypeScript Support: Works seamlessly with TypeScript files
• Zero Configuration: Works out of the box with standard RTK Query patterns
• Pattern Recognition: Supports useXxxQuery, useXxxMutation, and useLazyXxxQuery formats

🔍 How It Works

The extension analyzes your TypeScript files and provides two navigation methods:

CodeLens Navigation

Adds clickable CodeLens annotations above RTK Query hook names. Each annotation shows → endpointName and clicking it navigates to the corresponding builder.query or builder.mutation definition.

Go to Definition Navigation

Implements VSCode's DefinitionProvider to enable standard "Go to Definition" functionality for RTK Query hooks, allowing Ctrl+Click or F12 navigation.

Hook Name Parsing

The extension intelligently converts hook names to endpoint names:

📋 Supported Patterns

1. Single-Line Destructuring

// CodeLens: → getPokemonByName
export const { useGetPokemonByNameQuery } = pokemonApi

2. Multi-Line Destructuring (Closing Brace on Separate Line)

export const {
  // CodeLens: → getPokemonByName
  useGetPokemonByNameQuery,
  // CodeLens: → createUser
  useCreateUserMutation,
  // CodeLens: → fetchPosts
  useLazyFetchPostsQuery
} = api

3. Multi-Line Destructuring (Closing Brace on Same Line)

export const {
  // CodeLens: → getPokemonByName
  useGetPokemonByNameQuery,
  // CodeLens: → createUser
  useCreateUserMutation,
  // CodeLens: → fetchPosts
  useLazyFetchPostsQuery } = api

🏗️ Architecture

Core Components

src/extension.ts

• Main extension activation and registration
• Registers both CodeLens provider and DefinitionProvider for TypeScript files
• Handles navigation commands

src/definitionProvider.ts

• Implements VSCode's DefinitionProvider interface for "Go to Definition" functionality
• Detects RTK Query hook patterns and resolves to endpoint locations

src/codeLensProvider.ts (if separate)

• Implements VSCode's CodeLensProvider interface
• Creates CodeLens annotations with endpoint names

src/nameParser.ts

• Converts hook names to endpoint names using regex patterns
• Handles useXxxQuery, useXxxMutation, and useLazyXxxQuery formats
• Converts PascalCase to camelCase

src/endpointFinder.ts

• Searches for endpoint definitions in the current document
• Uses regex to find endpointName: builder.(query|mutation) patterns
• Returns VSCode Location for navigation

🎮 Usage

Installation

1. Install the extension from VSCode Marketplace
2. Open any TypeScript file containing RTK Query slices

Navigation Methods

CodeLens Navigation

1. Enable CodeLens: Go to VSCode settings → Search for "CodeLens" → Ensure "Editor: Code Lens" is enabled
2. Look for CodeLens annotations above hook names (shows → endpointName)
3. Click the annotation to navigate to the endpoint definition

Go to Definition Navigation

• Ctrl+Click (or Cmd+Click on Mac) on any exported hook name
• Press F12 while cursor is on a hook name
• Right-click and select "Go to Definition"

Example Usage

import { createApi, fetchBaseQuery } from '@reduxjs/toolkit/query/react'

export const pokemonApi = createApi({
  reducerPath: 'pokemonApi',
  baseQuery: fetchBaseQuery({ baseUrl: 'https://pokeapi.co/api/v2/' }),
  endpoints: (builder) => ({
    // ← Navigation targets here
    getPokemonByName: builder.query<Pokemon, string>({
      query: (name) => `pokemon/${name}`,
    }),
    createPokemon: builder.mutation<Pokemon, Partial<Pokemon>>({
      query: (pokemon) => ({
        url: 'pokemon',
        method: 'POST',
        body: pokemon,
      }),
    }),
  }),
})

// CodeLens annotations appear above each hook
// Go to Definition works on hook names below
export const {
  useGetPokemonByNameQuery,    // → getPokemonByName
  useCreatePokemonMutation,    // → createPokemon
} = pokemonApi

🔧 Requirements

• VSCode: ^1.90.0
• TypeScript: Files must be TypeScript (.ts, .tsx)
• RTK Query: Standard RTK Query patterns and naming conventions
• CodeLens: Must be enabled in VSCode settings for CodeLens features

🔧 Technical Details

Hook Pattern Recognition

/^use(Lazy)?([A-Z][a-zA-Z0-9]*)(Query|Mutation)$/

Endpoint Pattern Matching

/^\s*endpointName\s*:\s*builder\.(query|mutation)\s*[<(]/

Destructuring Pattern Detection

• Single-line: /^\s*export\s+const\s*\{\s*([^}]+)\s*\}\s*=\s*(\w+)\s*;?\s*$/
• Multi-line start: /^\s*export\s+const\s*\{\s*$/
• Multi-line end: /\}\s*=\s*(\w+)\s*;?\s*$/

🚀 Development

Prerequisites

• Node.js
• pnpm

Setup

# Install dependencies
pnpm install

# Compile TypeScript
pnpm run compile

# Run in development mode
# Press F5 in VSCode to launch extension development host

Build Commands

pnpm run compile    # Build the extension
pnpm run watch      # Watch mode for development
pnpm run package    # Package for publishing
pnpm run test       # Run tests

🎯 Use Cases

• Large RTK Query slices with many endpoints
• Team collaboration where hook usage and definitions are in different parts of files
• Code reviews to quickly understand hook-to-endpoint relationships
• Refactoring to locate endpoint definitions from hook usage

🐛 Known Issues

• Only works within the same file (doesn't follow imports across files)
• Requires standard RTK Query naming conventions
• Works with injectEndpoints and createApi patterns only
• CodeLens annotations may not appear if CodeLens is disabled

🔮 Future Enhancements

• Cross-file navigation (hooks imported from other files)
• Support for custom RTK Query naming conventions
• Integration with RTK Query devtools
• Reverse navigation (endpoint → hooks)
• Configuration options for custom patterns

📝 Release Notes

0.0.1

• Initial release
• CodeLens navigation support
• Go to Definition support
• TypeScript file support
• Standard RTK Query pattern recognition

🤝 Contributing

Contributions are welcome! Please ensure your code follows the existing patterns and includes appropriate TypeScript types.

1. Fork the repository
2. Create a feature branch
3. Make your changes
4. Add tests if applicable
5. Submit a pull request

📄 License

MIT License - see LICENSE file for details

📚 Related Documentation

• RTK Query Documentation
• VSCode Extension API
• DefinitionProvider API
• CodeLensProvider API

Made with ❤️ for the RTK Query community
