MapScope

嵌入式 MAP 文件分析器 —— 一个 VSCode 扩展，在一个界面里直观地展示固件的 内存占用 与 地址空间分布，帮助嵌入式工程师快速回答："Flash 还够不够、RAM 用剩多少、哪个模块/文件吃得最多"。

Embedded MAP file analyzer — a VSCode extension that visualizes firmware memory usage and address-space layout in one place, answering "Is Flash running low? How much RAM is left? Which module/file eats the most?"

MapScope 仅做分析，不修改任何工程代码，读完即走，无侵入、无副作用。

MapScope only analyzes and never modifies your project code — it is non-invasive and side-effect free.

支持的构建工具链 / Supported Build Toolchains

只需提供 .map 文件即可，MapScope 会自动识别工具链并解析，无需额外配置。

Just point MapScope at a .map file — it auto-detects the toolchain and parses, with no extra configuration.

工具链 / Toolchain	解析内容 / What is parsed
IAR EWARM / IAR ELF Linker	完整布局（含 PLACEMENT 段）、符号、模块汇总 / Full layout (incl. PLACEMENT), symbols, module summary
GNU ld（GCC / arm-none-eabi / S32DS）	Link map、运行区、符号 / Link map, execution regions, symbols
Greenhills (MULTI) Load Map	Image 段、ROM()/ZI 模型、镜像段去重 / Image segments, ROM()/ZI model, mirror-dedup
Keil AC5 / AC6（含 EIDE 变体）	Execution / Load Region
HighTec（英飞凌 AURIX）	工具链专用 map / Toolchain-specific map
TASKING TriCore	工具链专用 map / Toolchain-specific map

主要功能 / Key Features

1. 多视图总览 / Multiple Overview Views

打开 map 后，顶部立即给出 ROM / RAM 占用率（进度条 + 百分比），并提供多个 Tab 重点不同地看同一份数据。

On opening a map, the top immediately shows ROM/RAM utilization (gauge + percent) and several tabs that view the same data from different angles:

Overview（概览）：地址空间带状图 + 物理分段明细表 + 各存储类型占用柱。/ Address-space strip + physical-segment table + per-memory-type bars.
Treemap（矩形树图）：整个固件按模块渲染成色块，面积 ∝ 占用，一眼找出大户。/ Whole firmware as colored blocks; area ∝ usage to spot the big eaters.
Bar（柱状图）：按模块/分组维度的 ROM/RAM 对比。/ ROM/RAM comparison by module/group.
Pie（饼图）：各类存储（Code / RO Data / RW Data / ZI）占比环。/ Share ring of each storage kind.
Top N（排行榜）：占用最大的若干模块/文件排行。/ Ranking of the largest modules / files.
Table（明细表）：逐条的 section / 模块明细列表。/ Itemized section / module list.

视图提供 Region / Module 两种切换，均可向下钻取到目标文件（.o）。 Views support switching between Region / Module, and drilling down to object files (.o).

2. 地址空间分布（Memory Map）/ Address-Space Layout

以横向带状图展示芯片的物理地址空间——ROM、RAM、空洞、未映射区按真实地址比例排布，悬停查看段内内容。

A horizontal strip shows the chip's physical address space — ROM, RAM, holes and unmapped areas laid out to scale; hover to inspect what lives at an address.

3. Physical Segments（物理分段明细表）/ Physical Segments Table

按芯片**物理存储块（Bank）**列出每段的起止地址、跨度和 占用率（Used / Fill）。识别芯片后：

Lists each of the chip's physical storage banks with its start/end, span and fill rate (Used / Fill). Once the chip is recognized:

每个 Bank 都会列出，即使 0% 占用也显示，让你看清"这块留着没动"。/ Every bank is shown, even at 0% usage, so free banks are visible.
多 Bank、双核 ITCM/DTCM 镜像等结构会逐一如实呈现。/ Multi-bank and dual-core ITCM/DTCM mirror layouts are rendered faithfully.

4. MCU 芯片库与自动识别 / MCU Library & Auto-Detect

内置常用 MCU 地址库（覆盖主流车规 / 工业 / 通用厂商），并能：

Ships with a library of common MCUs (automotive / industrial / general-purpose) and can:

自动识别：从内存地址自动猜出芯片，随后用"芯片物理容量"作 ROM/RAM 总量基准。/ Auto-detect the chip from addresses, then use its physical capacity as the ROM/RAM base.
手动选择：自动识别不准时下拉手动选；一键清除回到自动识别。/ Pick manually if detection is off; one-click clear to return to auto-detect.

5. 报告导出 / Report Export

一键导出为 HTML 报告（离线存档 / 分享）或 CSV（便于 Excel 二次统计）。

Export as an HTML report (for archiving / sharing) or CSV (for further Excel analysis) with one click.

6. 阈值告警 / Threshold Alerts

内置 ROM/RAM 警告阈值（默认 80% 警告、95% 报错）。分析视图打开期间，VSCode 状态栏（左下角） 会显示 ROM/RAM 占用百分比，并在超限时变为**黄色（警告）/ 红色（报错）**并加上 ⚠ ROM!/RAM! 标记，便于交付前快速确认 Flash / RAM 余量。

Built-in ROM/RAM thresholds (default warn 80%, error 95%). While the analysis view is open, the VSCode status bar (bottom-left) shows ROM/RAM percentages and turns yellow (warn) / red (error) with a ⚠ ROM!/RAM! tag when a limit is crossed — handy for a quick pre-release Flash/RAM budget check.

安装 / Installation

在 VSCode 打开 Extensions 视图（Ctrl+Shift+X）。 Open the Extensions view in VSCode (Ctrl+Shift+X).
搜索 MapScope。 Search for MapScope.
点击 Install 安装。 Click Install to install.
完成后重启（或执行 Reload Window）。 Reload the window (or restart VSCode).

使用方法 / Usage

打开分析视图（两种方式/ Open the analysis view (either way)

右键资源管理器中任意 .map 文件 → MapScope: 分析 MAP 文件（Analyze MAP File）； Right-click any .map file in the Explorer → MapScope: Analyze MAP File;
按下 Ctrl+Shift+P 打开命令面板，运行 MapScope: 分析当前文件（Analyze Current File）。 Press Ctrl+Shift+P to open the command palette, then run MapScope: Analyze Current File.

面板打开期间，左下角状态栏会同步显示 ROM/RAM 占用与阈值告警（见"阈值告警"）。 While the panel is open, the bottom status bar shows ROM/RAM usage and threshold alerts (see "Threshold Alerts").

界面元素 / UI elements

顶部条形区 / Top bar：ROM / RAM 占用率进度条与百分比；ROM/RAM utilization gauges.
Tab 栏 / Tabs：Overview / Treemap / Bar / Pie / Top N / Table。
芯片选择框 / Chip selector：当前 MCU 型号与数据来源（内置库 / 自定义 / 按地址聚类）；current MCU and its source (library / custom / address clustering).

常见操作 / Common actions

我想…… / I want to…	怎么做 / What to do
换一种看法 / See it differently	顶部点击不同 Tab / Click a tab
某模块占多少 / See a module's usage	Treemap 点色块，或 Bar 看柱高 / Click a block in Treemap, or read the Bar column
深挖到单文件 / Drill into a file	视图内向下钻取，返回回上层 / Drill down, then back up
看精确地址 / Inspect an address	Overview 的地址空间带状图悬停定位 / Hover the strip in Overview
手动指定芯片 / Pick a chip	顶部芯片选择框输入型号后选 / Type in the chip selector
用自定义芯片 JSON / Use a custom chip JSON	点 MCU JSON 按钮选择一个 `.json` 芯片文件（选后面板立即更新显示芯片信息；文件无效会提示错误）/ Click MCU JSON to pick a `.json` chip file (panel updates instantly; an invalid file shows an error)
修改已选的 json / Edit a chosen json	改完后用 MCU JSON 按钮重新选择该文件（在当前面板即时生效，无需重开面板）；json 缺少 ROM/RAM 地址、或 map 用了 RAM 而 json 无 RAM 字段，都会弹提示 / Edit then re-pick it via the MCU JSON button (takes effect in the current panel immediately); missing addresses or a json with no RAM while the map uses RAM triggers a warning
取消自定义 / Cancel custom JSON	点芯片框旁清除，或在下拉里选内置型号 / Auto detect 即可放弃自定义文件并回退 / Click clear, or pick a built-in part / Auto detect to drop the custom file
回到自动识别 / Re-auto-detect	点芯片框旁清除 / Click clear beside the selector
改告警阈值 / Adjust thresholds	设置 `mapscope.thresholds` / Change `mapscope.thresholds`
导出结果 / Export	运行导出 HTML 报告 / 导出 CSV 报告（Export HTML / CSV Report）

界面支持中英文，自动跟随 VSCode 语言。 UI is Chinese/English, following the VSCode language.

设置项 / Settings

在 VSCode 设置（Ctrl+,）中搜索 mapscope。

Search mapscope in VSCode settings (Ctrl+,).

配置 / Setting	说明 / Description
`mapscope.memoryConfig`	为特定 map 手动指定 ROM/RAM 总量（KB）覆盖推断 / Per-map ROM/RAM total (KB) to override inference
`mapscope.thresholds`	ROM/RAM 警告/错误阈值（默认 80 / 95）/ ROM/RAM warn/error thresholds (default 80 / 95)
`mapscope.mcuInfoPath`	自定义 MCU JSON 芯片文件（内置库之外补充自己的芯片，也兼容目录）/ Custom MCU JSON chip file to add your own chips (a directory is accepted too)
`mapscope.mcuPart`	按文件锁定使用的芯片型号 / Lock the chip used per file

数据来源说明 / Data-source notes

ROM/RAM 已用量：优先采用工具链链接器总账（权威口径），如 IAR 的 N bytes of readonly code/data memory。/ Used: prefer the linker grand total (authoritative), e.g. IAR's N bytes of readonly code/data memory.
ROM/RAM 总量：优先取所选芯片物理容量（识别到芯片时），否则回退 map 内 Load Region / 内存区推断。/ Total: prefer the chip's physical capacity (when recognized), else fall back to Load Region / memory-region inference.
Physical Segments 分段行与合计行：分段按芯片物理 Bank 累加段字节；合计用链接器总账，两者正常基本一致（差异仅少量元数据 / 对齐填充）。/ Segment vs total rows: segments sum bytes per physical bank; the total uses the linker grand total; they normally agree within a small amount (metadata / alignment).

若某芯片不在内置库又希望被自动识别，可用 mapscope.mcuInfoPath 添加自己的芯片信息。 If a chip is missing from the library, add your own via mapscope.mcuInfoPath.

自定义 MCU JSON 格式 / Custom MCU JSON format

通过 MCU JSON 按钮（或 mapscope.mcuInfoPath）选择的 .json 芯片文件，用 ROM/RAM 地址范围来描述一颗芯片。支持两种等价写法：

A .json chip file picked via the MCU JSON button (or mapscope.mcuInfoPath) describes a chip by its ROM/RAM address ranges. Two equivalent layouts are supported.

顶层列表（推荐）/ Top-level lists (recommended)

{
  "Product": { "PartNumber": "R7F7015473AFP-C" },
  "CodeFlash": [
    { "StartAddr": "0x00000000", "EndAddr": "0x001FFFFF" },
    { "StartAddr": "0x01000000", "EndAddr": "0x01007FFF" }
  ],
  "RAM": [
    { "StartAddr": "0xFEBF0000", "EndAddr": "0xFEBFFFFF" },
    { "StartAddr": "0xFEBF8000", "EndAddr": "0xFEBFFFFF" }
  ],
  "DataFlash": [
    { "StartAddr": "0xFF200000", "EndAddr": "0xFF20FFFF" }
  ]
}

CodeFlash / ProgramFlash → ROM（Flash）；RAM → RAM（变量内存）；DataFlash → 独立数据存储区（可选）。 CodeFlash/ProgramFlash → ROM (Flash); RAM → RAM (variable memory); DataFlash → a separate data-storage area (optional).
每键都是数组；ROM 或 RAM 有多个不连续段时，用逗号分隔多个 {StartAddr,EndAddr} 项（如上例 CodeFlash 两块、RAM 两块）。 Each key is an array; for multiple non-contiguous ROM/RAM ranges, add more {StartAddr,EndAddr} entries separated by commas (e.g. two CodeFlash and two RAM blocks above).
每项 { "StartAddr": "…", "EndAddr": "…" }，地址用十六进制，支持 0x 前缀或 FF20_0000 下划线分隔。所有值都是闭区间（EndAddr 涵盖最后一个字节）。 Each entry { "StartAddr": "…", "EndAddr": "…" } uses hex addresses, either 0x-prefixed or _-separated (FF20_0000). Both ends are inclusive.
Product 里只需 PartNumber（型号名，用于搜索与自动匹配）；其它字段（如 Manufacturer、Series）会被忽略，省略。 Only Product.PartNumber (the part name, used for search & auto-match) is read; other fields such as Manufacturer/Series are ignored and may be omitted.

内存镜像 / Mirrored memory（可选）

同一物理存储若有主/别名两个窗口，用 primary + alias 描述；两者容量必须一致，别名窗口不计入总容量：

If the same physical memory has primary/alias windows, use primary + alias; both sizes must match and the alias is not counted twice:

"RAM": [
  { "primary": { "StartAddr": "0xFEBF0000", "EndAddr": "0xFEBFFFFF" },
    "alias":   { "StartAddr": "0xFEFF0000", "EndAddr": "0xFEFFFFFF" } }
]

Memory_Map 字典风格 / Memory_Map dict style（如 S32K）

也支持 Memory_Map 对象，键名按内容识别为 ROM/RAM（含 flash / sram / dtcm 等关键词），值同样是 {StartAddr,EndAddr}：

Also accepts a Memory_Map object whose keys are classified by name (flash / sram / dtcm etc.); values use the same {StartAddr,EndAddr} shape:

{
  "Product": { "PartNumber": "S32K344" },
  "Memory_Map": {
    "Flash":        { "StartAddr": "0x00400000", "EndAddr": "0x007FFFFF" },
    "SRAM_L":       { "StartAddr": "0x20000000", "EndAddr": "0x2002FFFF" },
    "Segments": {
      "Data_Flash": { "StartAddr": "0x10000000", "EndAddr": "0x1003FFFF" }
    }
  }
}

字段要求 / Field requirements

Product.PartNumber：型号名（可选），用于下拉搜索与自动匹配；缺失时用文件名代替。 Product.PartNumber: part name (optional), used for search & auto-match; falls back to the file name.
至少应提供一个有效 ROM 或 RAM 地址段；两者都缺会被拒绝并提示。 At least one valid ROM or RAM range is required; a file with neither is rejected with a warning.
若 map 使用了 RAM 而 JSON 完全没有 RAM 字段，会提示"缺少 RAM 字段"。 If the current map uses RAM but the JSON has no RAM at all, a "missing RAM field" warning is shown.

已知限制 / Known limitations

分析依赖 .map 文件详尽程度：若某工具链只输出摘要而无逐项段地址，部分视图（如 Treemap 精细展开）受限，但顶部 ROM/RAM 总览以链接器总账为准，仍然可靠。 Analysis depends on map detail: if a toolchain only emits a summary without per-section addresses, some views (e.g. fine Treemap expansion) are limited, but the top ROM/RAM overview uses the linker total and stays reliable.
个别型号的 RAM 地址在源数据中可能缺失（源数据本身限制，非解析缺陷），此时按地址聚类回退。 Some parts may lack RAM addresses in the source data (a source-data limit, not a parser bug); address clustering is used as fallback.
