ilimap for VS Code

ilimap adds editor support for .ilimap mapping profiles in Visual Studio Code. The extension keeps the client intentionally thin and delegates parsing, validation, formatting, and semantic analysis to the Java ilimap language server that ships with this repository.

Features

• Language registration for .ilimap
• Syntax highlighting through a TextMate grammar
• Diagnostics on open and on every document change
• Document formatting
• Document symbols for the Outline view
• Folding ranges for mappings, enum blocks, rules, bags, refs, and assignment blocks
• Context-aware completions for common ilimap keywords and model-backed symbols
• Hover information for inputs, outputs, rules, and enum maps
• Go to Definition for ilimap symbol references
• Quick fixes for selected enum map diagnostics
• Rename refactoring (F2) for local .ilimap symbols: input, output, rule, enum, source alias, join alias, bag, ref
• Read-only mapping overview webview with trace inspector, coverage matrix, source usage, and diagnostics
• Language server log output and restart command

Getting Started

1. Install the extension.
2. Open a folder that contains .ilimap files.
3. Open an .ilimap file.
4. If the published extension contains a bundled runtime for your platform, the language server starts immediately.
5. If no bundled runtime is available, configure ilimap.java.path or make sure java is available on your PATH.

The extension starts the server with:

<java> -jar <server-jar>

By default the extension uses the bundled ilimap language-server JAR at server/ilimap-lsp-all.jar. You can override it with ilimap.server.jarPath.

Commands

• ilimap: Restart Language Server
• ilimap: Show Language Server Logs
• ilimap: Format Mapping
• ilimap: Validate Mapping
• ilimap: Open Mapping Overview

ilimap: Validate Mapping currently opens the Problems view. It does not trigger a separate server-side validation pass beyond the diagnostics that are already kept up to date while you edit.

Settings

• ilimap.java.path Overrides the Java executable path. Leave it empty to prefer a bundled runtime when present and otherwise fall back to java from PATH.
• ilimap.server.jarPath Overrides the language-server fat JAR. Leave it empty to use the bundled server/ilimap-lsp-all.jar.
• ilimap.server.jvmArgs Adds extra JVM arguments when starting the language server.

Runtime Behavior

Published builds are expected to bundle runtimes for:

• darwin-arm64
• linux-arm64
• linux-x64
• win32-x64

Runtime resolution works like this:

1. Use ilimap.java.path when it is configured.
2. Otherwise use the bundled runtime for the current platform when available.
3. Otherwise fall back to java from PATH.

This keeps local development simple while allowing published builds to work without a separate Java installation on supported platforms.

Mapping Overview

Run ilimap: Open Mapping Overview while an .ilimap editor is active to open a read-only summary beside the editor. The webview shows:

• a summary with counts and lists for inputs, outputs, enum maps, rules, bags and refs
• diagnostics, shown both globally (grouped by the rule, input, output or enum map they belong to) and in context as count badges on the affected rules, inputs, outputs and coverage attributes
• class coverage
• a per-rule target coverage matrix (attribute, status, type, cardinality, source/expression) that highlights missing mandatory attributes
• a source usage section that lists used and, when models are loaded, unused source attributes and roles grouped by source class

The overview is read-only: it does not edit mappings. It does compute and display class coverage, the rule coverage matrix and source usage. The coverage matrix and source usage sections provide read-only filter links (for example "Missing only" or "Unused only") that only change what is displayed. Clicking on a target attribute in the coverage matrix or a source member in the source usage section opens a Trace Inspector below the matrix. The trace shows which source attributes, roles, enum maps, and functions produce the target value — or, in reverse, which target attributes consume a given source member.

The overview stays bound to the document it was opened for and keeps its summary current: it refreshes automatically when that .ilimap document is saved and after a short debounce when it is edited. A non-editing Refresh link reloads the summary on demand. A status line reports loading, stale, error and last-updated state without adding any editable controls.

Editor integration

Each rule in an .ilimap file shows a CodeLens above its declaration with a Show in Overview action and a concise read-only summary such as Coverage 12/14 · 2 refs · 1 bag · 1 warning. The CodeLens actions run the ilimap.showRuleInOverview and ilimap.showRuleCoverage commands, which open (or reuse) the Mapping Overview and select the rule in the read-only Rule Inspector. Moving the cursor into a rule highlights that rule in an already open overview. The coverage segment appears once models are loaded (after save or ilimap: Validate Mapping).

Bidirectional node-level sync: moving the cursor to a target attribute assignment, a source alias declaration, or an alias.member expression highlights the corresponding element in the overview (coverage row, source usage member, etc.). Conversely, clicking any data-nav-line link in the overview jumps to the exact editor location.

Developer notes

Further DX roadmap: see ./docs/ilimap-vscode-mapping-overview-dx-spec.md.

Local Development

Use this workflow when working on the extension from this repository:

1. Build and stage the current server JAR:

   ./gradlew copyDevIlimapServerJar


2. Open vscode/ilimap-vscode as the VS Code workspace.

3. Install dependencies:

   npm install


4. Optionally keep the client rebuilt while editing:

   npm run watch


5. Run the VS Code task Prepare ilimap Dev Host.

6. Start the launch configuration Run ilimap Client.

7. After Java server changes, run ./gradlew copyDevIlimapServerJar again and use ilimap: Restart Language Server.

Current Scope

The current extension focuses on editing and understanding ilimap mappings. It does not currently provide:

• semantic tokens
• workspace-wide symbol search
• code actions beyond the currently implemented quick fixes and formatting source action
• editing inside the mapping overview webview

Packaging and Publishing

The repository contains scripts and CI automation for packaging the extension as a .vsix and publishing the same artifact to Visual Studio Marketplace and Open VSX. Maintainer details live in the repository publishing note.
