Semantic Models for VS Code

Semantic Models for VS Code is a Visual Studio Code extension for editing RDF/Turtle documents, including SAMM Aspect Models.

For RDF/Turtle documents, it features syntax highlighting, document outline and automatic syntax validation. For SAMM Aspect Models, the extension additionally features Go to Definition for elements and semantic model validation.

Configuration

• semantic-models.languageServerSettings.activateEmbeddedLanguageServer (boolean, default: true)
  • When enabled, the extension starts the SAMM language server process. When disabled, an external language server must be started manually.
• semantic-models.languageServerSettings.automaticUpdateCheck (boolean, default: true)
  • Automatically check for updates to the SAMM language server and notify when a new version is available.
• semantic-models.languageServerSettings.sammCliPath (string)
  • Path to the SAMM CLI executable or JAR file to use as the language server. Can be downloaded or selected using the 'Select SAMM CLI Executable' command.
• semantic-models.languageServerSettings.serverPort (number, default: 1846)
  • TCP port used to connect to the SAMM language server.
• semantic-models.languageServerSettings.traceLevel (string, default: off)
  • Controls the verbosity of Language Server Protocol (LSP) tracing. Options: off, messages, verbose.

Use the command Semantic Models: Select SAMM CLI Executable to choose either:

• one of the latest SAMM CLI GitHub releases, or
• a custom executable path from your local file system.

Features

• Prefix Go to Definition inside Turtle files.
• Two-level validation:
  • Fast validation while typing from the regular Turtle parser diagnostics provided by the server (appear in the editor and Problems).
  • Full Aspect validation from the server for model-level issues (results shown in notifications and status bar).
• Manual validation command:
  • Semantic Models: Validate Document Now

Running the Server and Extension Together

1. In this extension project, install the dependencies using npm install.
2. Build the extension with npm run build.
3. Press F5 in VS Code to open an Extension Development Host.
4. Open an RDF/Turtle file such as samples/valid.ttl or your Aspect model file.

If the server cannot be downloaded or started, the extension shows an error and writes a detailed message in the Turtle LSP output channel.

Validation Behavior

Fast feedback while typing:

• Driven by the server's regular Turtle parsing diagnostics.
• Results appear in the editor and Problems view.
• Intended for quick editor feedback while you type.

Full Aspect validation:

• Runs on the server, not in the extension.
• Results are displayed in notification messages (for manual validation) or status bar (for save-triggered validation).
• Always uses detailed server validation messaging when the server returns report text.
• Always shows visible progress for long-running validation.
• Runs automatically when saving and can also be triggered manually.

When each validation runs:

• On type: fast syntax feedback only.
• On save: heavy Aspect validation for Turtle documents.
• Manual: Semantic Models: Validate Document Now for the active Turtle document.

Commands

• Semantic Models: Validate Document Now
  • Sends a server request for the active Turtle document.
• Semantic Models: Select SAMM CLI Executable
  • Opens a quick pick with the latest ten GitHub releases and a custom-path option.
• Semantic Models: Restart Language Server Connection
  • Restarts the language server and reconnects the client.

UX During Long-Running Validation

• Manual validation shows a progress notification while the request is running.
• Save-triggered validation always uses a short status-bar progress indicator instead of repeated pop-up notifications.
• After completion, the user gets a summary message with validation results.
• Automatic save validation keeps progress and completion status in the status bar.

Verify Go To Definition

Use samples/valid.ttl:

1. Open samples/valid.ttl.
2. Place the cursor on foaf:Person, foaf:name, or another prefixed name.
3. Run Go to Definition.
4. Confirm that VS Code jumps to the matching @prefix declaration.

Expected behavior:

• foaf:* resolves to @prefix foaf: ....
• ex:* resolves to @prefix ex: ....

Verify Aspect Validation

Use samples/org.eclipse.esmf.test/1.0.0/Aspect.ttl or samples/invalid.ttl.

Manual check:

1. Open an Aspect model file.
2. Run Semantic Models: Validate Document Now.
3. Wait for validation to complete.
4. Confirm that validation results are displayed in a notification.

On-save check:

1. Save the model file.
2. Confirm that the status bar shows validation progress.
3. Confirm that a summary message appears in the status bar after completion.
