MCP Tester

A full-featured VSCode extension for testing and debugging Model Context Protocol (MCP) servers. This extension provides the same functionality as the official MCP Inspector, supporting multiple transport protocols with an intuitive interface for MCP server management and interaction.

🚀 Core Features

📡 Multi-Protocol Support

STDIO Transport: Support for local command-line MCP servers
SSE (Server-Sent Events): HTTP streaming event-based connections
Streamable HTTP: HTTP streaming transport protocol
Custom Headers: Authentication and custom HTTP headers support

🛠️ Complete MCP Functionality

Tools Management: List, view, and invoke MCP tools
Resources Management: Browse, read, and subscribe to MCP resources
Prompts Management: Manage and use MCP prompt templates
Roots Management: View and manage server root directories
Real-time Notifications: Receive server notifications and status updates

🎯 Advanced Features

Visual Interface: Modern WebView UI built with Vue.js
Configuration Management: Save and manage multiple server configurations
Request History: Complete request/response history tracking
Error Handling: Comprehensive error handling and user feedback
Status Monitoring: Real-time connection status and server capabilities display
Sampling Support: MCP sampling request and response support
Completion Support: Parameter auto-completion support

🔧 Developer Tools

Command Palette Integration: All features accessible via VSCode command palette
Status Bar Display: Real-time connection status display
Config Import/Export: MCP server configuration import/export support
Log Management: Support for setting log levels and viewing logs
Ping Testing: Test server connection and response

📦 Installation

Build from Source

Clone the repository:

git clone https://github.com/echo-ai100/mcp-tester.git
cd mcp-tester

Install main project dependencies:

npm install

Install Vue webview dependencies:

npm run install-webview

Build the project:

cd ./src/vue-webview && npm run build
cd ../../ && npm run build

Build the .vsix file:

npx vsce package

Install from VSIX

Download the latest .vsix file from releases
Open VSCode
Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (macOS)
Type "Extensions: Install from VSIX..."
Select the downloaded .vsix file
Reload VSCode when prompted

🎮 Usage

1. Launch MCP Tester

Via Command Palette:

Open command palette (Ctrl+Shift+P / Cmd+Shift+P)
Type "MCP: Open MCP Tester"

Via Activity Bar:

Click the MCP Tester icon in the left activity bar

Via Status Bar:

Click the MCP connection status in the bottom status bar

2. Connect to MCP Server

STDIO Transport (Recommended for local development)

For local command-line MCP servers:

{
  "type": "stdio",
  "command": "node",
  "args": ["path/to/your/mcp-server.js"],
  "env": {
    "API_KEY": "your-api-key",
    "DEBUG": "true"
  }
}

Example Configuration:

{
  "type": "stdio",
  "command": "npx",
  "args": ["@modelcontextprotocol/server-everything"],
  "env": {
    "NODE_ENV": "development"
  }
}

SSE (Server-Sent Events) Transport

For HTTP streaming transport:

{
  "type": "sse",
  "url": "http://localhost:3000/sse",
  "customHeaders": {
    "Authorization": "Bearer your-token",
    "X-API-Key": "your-api-key"
  }
}

Streamable HTTP Transport

For HTTP streaming transport:

{
  "type": "streamable-http",
  "url": "http://localhost:3000/mcp",
  "customHeaders": {
    "Authorization": "Bearer your-token"
  }
}

3. Use MCP Features

Once connected, you can:

🛠️ Tools

List Tools: View all tools provided by the server
View Tool Details: Check tool input/output schemas
Invoke Tools: Call tools using form or JSON format
View Results: See tool execution results and error messages

📄 Resources

Browse Resources: View available resource list
Read Resources: Get resource content
Subscribe Resources: Subscribe to resource change notifications
Resource Templates: Use parameterized resource templates

💬 Prompts

Manage Prompts: View and use predefined prompts
Parameter Filling: Provide parameters for prompts
Get Results: Retrieve generated prompt content

📁 Roots

View Roots: List server root directories
Directory Management: Manage server filesystem access

🔔 Real-time Features

Server Notifications: Receive real-time server notifications
Connection Status: Monitor connection status changes
Request History: View complete request/response history

⚙️ Configuration Options

VSCode Settings

Configure mcp-tester options in VSCode settings:

Configuration	Type	Default	Description
`mcp-tester.autoStart`	boolean	true	Auto-start on VSCode launch
`mcp-tester.defaultTransport`	string	"stdio"	Default transport protocol
`mcp-tester.timeout`	number	30000	Request timeout (milliseconds)
`mcp-tester.maxHistory`	number	100	Maximum history entries
`mcp-tester.enableLogging`	boolean	false	Enable logging
`mcp-tester.maxRetryAttempts`	number	3	Maximum retry attempts
`mcp-tester.retryDelay`	number	1000	Retry delay (milliseconds)

Server Configuration

Configure the mcp-tester.servers array in settings to predefine servers:

{
  "mcp-tester.servers": [
    {
      "name": "Everything Server",
      "type": "stdio",
      "command": "npx",
      "args": ["@modelcontextprotocol/server-everything"],
      "env": {
        "NODE_ENV": "development"
      }
    },
    {
      "name": "Remote API Server",
      "type": "sse",
      "url": "https://api.example.com/mcp/sse",
      "customHeaders": {
        "Authorization": "Bearer your-token"
      }
    },
    {
      "name": "Local HTTP Server",
      "type": "streamable-http",
      "url": "http://localhost:8080/mcp"
    }
  ]
}

🎛️ Command Palette Commands

Command	Description
`MCP: Open MCP Tester`	Open MCP Tester main interface
`MCP: Connect to MCP Server`	Connect to MCP server
`MCP: Disconnect from MCP Server`	Disconnect from server
`MCP: List Tools`	Display tools list in editor
`MCP: List Resources`	Display resources list in editor
`MCP: List Prompts`	Display prompts list in editor
`MCP: Ping Server`	Test server connection
`MCP: Show Connection Status`	Show connection status information
`MCP: Clear Request History`	Clear request history
`MCP: Export Server Configuration`	Export server configuration
`MCP: Import Server Configuration`	Import server configuration

🏗️ Project Architecture

mcp-tester/
├── src/
│   ├── extension.ts              # VSCode extension entry point
│   ├── mcp-tester-provider.ts    # WebView provider for UI interaction
│   ├── server/
│   │   └── mcp-server-manager.ts # MCP server manager for protocol communication
│   └── vue-webview/             # Vue.js frontend interface
│       ├── src/
│       │   ├── components/      # Vue components
│       │   │   ├── MainApp.vue  # Main application component
│       │   │   ├── Sidebar.vue  # Sidebar component
│       │   │   ├── ToolsPanel.vue # Tools panel component
│       │   │   └── ...          # Other feature components
│       │   ├── assets/styles/   # Style files
│       │   └── main.ts         # Vue application entry
│       ├── package.json
│       └── vite.config.ts
├── package.json                 # Extension configuration and dependencies
├── webpack.config.js           # Webpack build configuration
└── tsconfig.json              # TypeScript configuration

Architecture Features

Layered Architecture:
- Extension Layer: VSCode extension API integration
- Business Layer: MCP protocol handling and state management
- Presentation Layer: Vue.js WebView interface
Event-Driven:
- Use EventEmitter for inter-component communication
- Support real-time status updates and notifications
Modular Design:
- Independent server manager module
- Reusable Vue components
- Clear separation of responsibilities

🔧 Development Guide

Development Environment Requirements

Node.js: >= 16.x
npm: >= 7.x
VSCode: >= 1.74.0
TypeScript: >= 4.9.x

Development Scripts

Command	Description
`npm run compile`	Compile TypeScript and build Vue app
`npm run watch`	Watch mode compilation
`npm run build`	Complete project build
`npm run dev-webview`	Run Vue app in development mode
`npm run build-webview`	Build Vue app
`npm run install-webview`	Install Vue app dependencies
`npm run lint`	Code linting
`npm run package`	Production build

Vue WebView Development

The Vue frontend interface is located in the src/vue-webview/ directory:

# Navigate to Vue project directory
cd src/vue-webview

# Install dependencies
npm install

# Development mode
npm run dev

# Build production version
npm run build

Adding New Features

Add New MCP Protocol Feature:
- Add new method in MCPServerManager
- Add message handling in MCPTesterProvider
- Add UI interaction in Vue components
Add New Vue Component:
- Create component in src/vue-webview/src/components/
- Import and use in MainApp.vue
- Add corresponding styles and interaction logic
Add New VSCode Command:
- Declare in package.json's contributes.commands
- Register command handler in extension.ts

🧪 Testing

Unit Tests

# Run tests
npm test

# Watch mode testing
npm run test:watch

Integration Tests

Test STDIO Transport:

# Use official example server
npx @modelcontextprotocol/server-everything

Test HTTP Transport:

# Start HTTP MCP server
# Then connect to the corresponding URL in the extension

Debugging Tips

Enable Verbose Logging:
- Enable mcp-tester.enableLogging in settings
- Check VSCode developer console output
Vue DevTools:
- Can use Vue DevTools in development mode
- WebView debugging requires enabling developer mode
Network Debugging:
- Use browser developer tools to monitor HTTP requests
- Check WebSocket connection status

🤝 Contributing

Code Submission

Fork the project
Create feature branch (git checkout -b feature/amazing-feature)
Commit changes (git commit -m 'Add some amazing feature')
Push to branch (git push origin feature/amazing-feature)
Open Pull Request

Code Standards

TypeScript: Use strict mode with complete type annotations
Vue: Use Composition API and <script setup> syntax
Styles: Use VSCode theme variables for consistency
Comments: Provide clear comments for important logic

Commit Message Format

type(scope): description

[optional body]

[optional footer]

Types include:

feat: New feature
fix: Bug fix
docs: Documentation update
style: Code formatting
refactor: Code refactoring
test: Test related
chore: Build or tool changes

📝 License

This project is licensed under the MIT License - see the LICENSE file for details.

🙏 Acknowledgments

Model Context Protocol (MCP) team for the protocol specification
VSCode team for the excellent extension API
Vue.js team for the reactive framework
All contributors who have helped improve this project

📞 Support

Issues: GitHub Issues
Discussions: GitHub Discussions
Email: support@example.com

Developer: Echo AI
Version: 0.0.2
Last Updated: November 2024

MCP Tester

echoai

MCP Tester

🚀 Core Features

📡 Multi-Protocol Support

🛠️ Complete MCP Functionality

🎯 Advanced Features

🔧 Developer Tools

📦 Installation

Build from Source

Install from VSIX

🎮 Usage

1. Launch MCP Tester

Via Command Palette:

Via Activity Bar:

Via Status Bar:

2. Connect to MCP Server

STDIO Transport (Recommended for local development)

SSE (Server-Sent Events) Transport

Streamable HTTP Transport

3. Use MCP Features

🛠️ Tools

📄 Resources

💬 Prompts

📁 Roots

🔔 Real-time Features

⚙️ Configuration Options

VSCode Settings

Server Configuration

🎛️ Command Palette Commands

🏗️ Project Architecture

Architecture Features

🔧 Development Guide

Development Environment Requirements

Development Scripts

Vue WebView Development

Adding New Features

🧪 Testing

Unit Tests

Integration Tests

Debugging Tips

🤝 Contributing

Code Submission

Code Standards

Commit Message Format

📝 License

🙏 Acknowledgments

📞 Support
