AWS Serverless Offline Toolkit

A VS Code extension for fast pre-deploy validation of AWS serverless projects — without waiting on pipelines or cloud deployments.

Why

When a pipeline takes 10–20 minutes, small mistakes become expensive. This toolkit is built for developers who want to catch resolver bugs, infrastructure wiring issues, missing environment variables, and risky CDK changes before pushing anything.

It is not a full cloud emulator. The goal is shorter feedback loops and earlier detection of common problems.

Features

AppSync Offline Studio

Run AppSync JavaScript and VTL resolvers locally with a realistic ctx simulation — no AWS account required.

• Local GraphQL server with AppSync-style context (arguments, identity, source, stash, result).
• Supports single schema files and multi-file schema folders with hot reload.
• Mock identity modes: apiKey, cognitoUser, iam, admin, guest — switchable per request.
• Query editor with variables, execution history, and schema explorer.
• Resolver Runner tab — run any resolver directly with a custom identity and argument JSON, see the full trace (phase, duration, I/O) without writing a full GraphQL query.
• Lambda data source support — configure a handler spec per data source and the resolver engine invokes the Lambda handler locally instead of the in-memory store.
• 🐛 Debug Lambda — one click spawns the Lambda handler with --inspect-brk and attaches VS Code's Node.js debugger so you can set breakpoints and step through handler code.
• VTL resolver evaluation — .vtl request/response templates are rendered locally, with $ctx, $util.dynamodb.*, #if, #foreach, and $util.error support.
• In-memory DynamoDB with full expression support: GetItem, PutItem, UpdateItem, DeleteItem, Query, Scan, composite keys, FilterExpression, KeyConditionExpression, UpdateExpression (SET/REMOVE/ADD), GSI simulation, and limit/nextToken pagination.
• Resolver run history — the last 20 runs persist in workspace state with one-click replay.
• Auto-detection of project layout or explicit path configuration.

CDK Diff Explainer

Runs cdk diff and classifies every infrastructure change by risk level with actionable explanations.

• Critical, high, medium, and low risk classification across Lambda, DynamoDB, IAM, AppSync, S3, Cognito, SQS, and more.
• Highlights replacements, deletions, and wildcard IAM policies that need review.
• Exportable Markdown report for engineering reviews and approvals.

CDK Stack Preflight Report

Validates synthesized cdk.out templates before any deployment — no AWS credentials required.

• Checks AppSync resolver → DataSource wiring, Lambda → IAM role references, DynamoDB table targets, and AppSync ServiceRole bindings.
• Flags wildcard IAM actions and resources.
• Displays a confidence score (0–100) with a readiness label: Ready to Deploy, Minor Issues, Review Needed, Significant Issues, or Not Ready.
• One command runs cdk synth and validation in a single flow.

AWS Service Map

Reads cdk.out/*.template.json and generates an interactive React Flow diagram of every AWS service in the stack and how they connect — no AWS credentials required.

• Detects AppSync APIs, Lambda functions, DynamoDB tables, Cognito User Pools, SQS queues, SNS topics, EventBridge rules, and API Gateway.
• Resolves CloudFormation Ref and Fn::GetAtt references to trace real connections: DataSource → Lambda/DynamoDB, Cognito → AppSync auth, SQS/SNS → Lambda event source mappings, Lambda env var refs, EventBridge targets.
• Nodes auto-arranged left-to-right by service type with color-coded categories.
• Multiple CDK stacks shown as tabs. Animated edges for triggers and invokes relationships.
• Interactive: drag nodes, zoom, minimap, fit-view controls.

Env Var Preflight

Scans every Lambda function in cdk.out and classifies its environment variables before deployment.

• Detects static values, SSM Parameter Store references, Secrets Manager references, CDK intrinsic tokens, cross-stack refs, and empty strings.
• Supports .env.local overrides for offline validation of cloud-backed variables.
• Shows per-Lambda breakdown with status, source type, and a .env.local snippet for any variables that need cloud resolution.

Commands

Open the Command Palette (Cmd+Shift+P) and run:

Quick Start

AppSync local validation

1. Open a workspace with a GraphQL schema and resolver files.
2. Run AWS: Detect AppSync Project to auto-configure paths.
3. Run AWS: Detect and Start AppSync Offline.
4. Execute queries, inspect resolver output, and iterate with hot reload.

CDK infrastructure review

1. Make infrastructure changes in your CDK app.
2. Run AWS: Run CDK Diff Explainer to review risk before pushing.
3. Run AWS: Synth and Validate Stack Intent to catch wiring issues from synthesized templates.
4. Run AWS: Validate Environment Variables to confirm all Lambda env vars are resolvable.

Project Layout

AppSync

my-appsync-project/
  schema.graphql
  mock-data.json
  resolvers/
    Query.getItem.request.js
    Query.getItem.response.js

Schema folders (lib/schemas/*.graphql) are also supported when auto-detected or configured.

CDK preflight

The extension reads cdk.out/*.template.json — run cdk synth first if cdk.out does not exist. The AWS: Synth and Validate Stack Intent command handles this automatically.

For env var validation, add a .env.local file at the workspace root to provide values for SSM and Secrets Manager references without cloud access:

# .env.local  (excluded from VSIX and git)
MY_SSM_PARAM=local-override-value
ANOTHER_SECRET=dev-value

DynamoDB Expression Support

The in-memory store evaluates real DynamoDB expression syntax, so resolver code written for AWS works locally without changes.

Query with GSI (filters by any attribute — no index schema needed):

// resolver request
export function request(ctx) {
  return {
    operation: 'Query',
    query: {
      expression: 'userId = :userId',
      expressionValues: { ':userId': util.dynamodb.toDynamoDB(ctx.args.userId) },
    },
    filter: {
      expression: '#status = :status',
      expressionNames: { '#status': 'status' },
      expressionValues: { ':status': util.dynamodb.toDynamoDB('active') },
    },
    index: 'byUserId',
    limit: 20,
  };
}

UpdateExpression:

export function request(ctx) {
  return {
    operation: 'UpdateItem',
    key: util.dynamodb.toMapValues({ id: ctx.args.id }),
    update: {
      expression: 'SET #name = :name REMOVE deletedAt',
      expressionNames: { '#name': 'name' },
      expressionValues: { ':name': util.dynamodb.toDynamoDB(ctx.args.name) },
    },
  };
}

Lambda Data Source Setup

To connect a Lambda data source to the local resolver engine, add the handler spec to your workspace settings:

// .vscode/settings.json
{
  "awsToolkit.appsync.lambdaHandlers": {
    "MyLambdaDataSource": "src/handlers/resolver.ts#handler"
  }
}

The key is the AppSync data source name (as defined in your CDK stack or AppSync config). The value is "path/to/handler#exportedFunction" — relative to the workspace root.

Once configured, the Resolver Runner's ▶ Run Resolver button invokes the Lambda locally. Use 🐛 Debug Lambda to attach the VS Code debugger and step through the handler with breakpoints.

Resolver Example (APPSYNC_JS)

export function request(ctx) {
  return {
    operation: 'GetItem',
    key: { id: { S: ctx.arguments.id } },
  };
}

export function response(ctx) {
  return ctx.result;
}

Configuration

Best Fit

Teams working with:

• AWS AppSync with JavaScript resolvers.
• CDK-based serverless stacks.
• Local-first development before CI/CD.
• Fast iteration on schema, resolver, and infrastructure changes.
