🚀 GitLab Component Helper

Turbocharge your GitLab CI/CD workflow in VS Code! Instantly browse, insert, and manage reusable components from any GitLab instance—public or private.

🎬 See it in Action: Component Browser

---

✨ Key Features

• Component Browser: Explore and insert components from any GitLab project or group
• Smart Completion: Context-aware suggestions for components and versions as you type
• Hover Docs: See full documentation and parameter hints instantly
• Input Validation: Real-time validation of component inputs with intelligent Quick Fix suggestions
• Local Includes: Same hover, completion, and validation for include: - local: entries that declare a spec.inputs block
• Version/Tag Picker: Always use the right version—no more guessing
• Variable Expansion: Full support for GitLab CI/CD variables in URLs and parameters
• Lightning Fast: Caching, batch API calls, and performance optimizations for huge catalogs
• Private Access: 🔑 Add private projects/groups with a token (per GitLab instance)

🎬 Smart Autocomplete in Action

---

🛠️ Quick Start

1. Install: Search "GitLab Component Helper" in VS Code Extensions and click Install
2. Browse Components: Ctrl+Shift+P → "GitLab: Browse Components"
3. Add Project/Group: Ctrl+Shift+P → "GitLab CI: Add Component Project/Group" (add public or private sources, with or without a token)
4. Insert & Complete: Type component: in .gitlab-ci.yml and get instant, real versioned suggestions
5. Hover for Docs: Hover any component URL for instant documentation

🎬 Hover Documentation Demo

---

🔒 Private Components? No Problem!

Add any private project or group with a personal access token—just once per GitLab instance! The extension will use your token for all future requests to that instance.

Your security matters:

• Tokens are stored securely using VS Code's built-in SecretStorage—never in plain text or files.
• Tokens are only used for authenticated API calls to your specified GitLab instance and are never sent to third parties.

⚠️ The legacy gitlabComponentHelper.gitlabToken setting stores tokens in plain text in settings.json and is deprecated. Use the GitLab CI: Add Component Project/Group command instead — it stores tokens encrypted via SecretStorage. If you still have a token in that setting, copy it through the command and clear the field.

---

⚡ Example Usage

include:
  - component: https://gitlab.com/components/terraform@v1.0.0
    with:
      terraform_version: "1.5.0"
      workspace: "default"
      apply: true

Local templates work too — point a - local: entry at any workspace YAML that declares a spec.inputs block and you get the same hover, completion, and validation as a catalog component:

include:
  - local: "gitlab/templates/nx-test.yml"
    inputs:
      job_name: test-nightly
      job_type: nightly

🎬 Adding Component Inputs

🎬 Input Validation & Quick Fixes

---

📝 Template Header Spec (Optional Context)

To provide consistent context in the Component Browser, you can add spec-compliant header comments at the top of a template file. Only these keys are displayed; all other comments are ignored.

Supported keys (must be at top of file):

• summary
• usage
• note

Full format:

# @gitlab-component-helper: summary: Push a Helm chart to Sonic
# @gitlab-component-helper: usage: include + set SONIC_TARGET_* variables
# @gitlab-component-helper: note: Requires a protected ref for publish

Short format:

# @gch: summary: Push a Helm chart to Sonic
# @gch: usage: include + set SONIC_TARGET_* variables
# @gch: note: Requires a protected ref for publish

Notes:

• Header comments must appear before any non-comment content.
• Multiple note entries are supported.
• If no header is present, the Context section stays hidden.

---

📄 Raw YAML Toggle

Component details include a Raw YAML toggle so you can inspect the original template when needed. This is available regardless of whether header comments are present.

---

⚙️ Configuration

Add your favorite sources in VS Code settings:

"gitlabComponentHelper.componentSources": [
  {
    "name": "OpenTofu Components",
    "path": "components/opentofu",
    "gitlabInstance": "gitlab.com"
  },
  {
    "name": "Internal CI Components",
    "path": "devops/ci-components",
    "gitlabInstance": "gitlab.company.com"
  }
]

📁 Recognising non-canonical CI files

Out of the box the extension activates on .gitlab-ci.yml, .gitlab-ci.yaml, and anything under a .gitlab/ directory. If your project keeps included CI configs elsewhere, add their globs to gitlabComponentHelper.additionalFileGlobs — these are merged with the built-in defaults:

"gitlabComponentHelper.additionalFileGlobs": [
  "**/ci/*.yml",
  "**/pipelines/**/*.yaml"
]

Patterns use VS Code's GlobPattern syntax.

---

🗂️ Component Discovery

By default the extension follows the GitLab CI Components spec when scanning a source repository — it looks for templates in templates/ and one subdirectory level deep, matching *.yml and *.yaml. No configuration is required for spec-compliant repos.

For repositories that pre-date the spec, use a custom directory layout, or store templates outside templates/, you can override discovery behavior either globally or per source.

Global defaults

"gitlabComponentHelper.discovery.templateRoots": ["templates", "ci/components"],
"gitlabComponentHelper.discovery.maxDepth": 2,
"gitlabComponentHelper.discovery.filePatterns": ["*.yml", "*.yaml"],
"gitlabComponentHelper.discovery.templateFileNames": ["template.yml", "template.yaml"]

These four settings are also editable from the VS Code Settings UI (search for "GitLab Component Helper Discovery").

Per-source override

Need different rules for one repository? Add a discovery block to that source — its values override the global defaults for that source only.

"gitlabComponentHelper.componentSources": [
  {
    "name": "Standard CI Components",
    "path": "components/opentofu",
    "gitlabInstance": "gitlab.com"
    // uses global discovery defaults
  },
  {
    "name": "Legacy Internal Components",
    "path": "infra/legacy-ci",
    "gitlabInstance": "gitlab.company.com",
    "discovery": {
      "templateRoots": ["ci/components", "shared/pipelines"],
      "maxDepth": 2
    }
  }
]

Limits

To keep the extension fast and predictable:

Field	Limit
templateRoots	Up to 5 roots per source
maxDepth	0–3 (0 = root only, 1 = one subdirectory level, the spec default)
filePatterns	Filename globs only — no path globs (e.g. *.yml ✅, foo/*.yml ❌)
templateFileNames	Filenames only — no slashes

---

🏷️ Monorepo tag conventions

When a single repository holds many components, each component is usually released under its own tags that embed the component name — e.g. deploy-app-1.1.0, deploy-app-2, build-image-4.0.0. Without any hint, the version dropdown for every component would list every tag in the repo.

Set a tag pattern on the source to tell the extension how tags map to components. Each component's dropdown is then scoped to its own tags, and the labels are shown without the prefix (e.g. 1.1.0, not deploy-app-1.1.0). The full tag is still what gets inserted, so the GitLab include resolves correctly.

"gitlabComponentHelper.componentSources": [
  {
    "name": "Shared CI Monorepo",
    "path": "infrastructure/shared-ci",
    "gitlabInstance": "gitlab.com",
    "tagPattern": "{name}-{version}"
  }
]

The template uses two tokens:

Token	Meaning
{name}	The component (= templates/ directory) name.
{version}	The version shown in the dropdown. Matches anything starting with a digit.

Everything else in the pattern is literal text, so other conventions work too:

Tag style	Pattern
deploy-app-1.1.0	{name}-{version}
apps/web/v2.0.0	apps/{name}/v{version}
web_1.0.0	{name}_{version}

Sibling names: because {version} must start with a digit, a component named build-image won't pick up a sibling's build-image-extra-1.0.0 tags. If you need pre-release-only tags with no leading digit (e.g. web-rc1), write a stricter custom pattern for that source.

Leave tagPattern unset for ordinary single-component repos — their tags are listed as-is.

---

🧩 Commands

Use the Command Palette (Ctrl+Shift+P) to access:

• GitLab CI: Browse Components — Explore and insert from all your sources
• GitLab CI: Add Component Project/Group — Add any project/group (with optional token for private access)
• GitLab CI: Refresh Component Cache — Refreshes cached data
• GitLab CI: Show Cache Status — See cache info and stats

---

🆘 Troubleshooting

Component browser not showing components?

• Check file language mode is set to YAML
• Verify component sources are configured

Version dropdown not loading?

• Check network connectivity to GitLab instance
• Verify project permissions and access tokens
• Review cache status and refresh if needed

If you encounter issues:

1. Enable debug output and check for error messages
2. Verify your configuration matches the examples above
3. Test with a simple, known-working component source
4. Submit an issue with debug output and configuration details

---

🔌 API Reference

The extension exposes the following API for other extensions to consume:

interface GitLabComponentAPI {
    getComponentList(): Promise<Component[]>;
    getComponentDetails(name: string, version?: string): Promise<ComponentDetails>;
    validateComponent(component: Component): ValidationResult;
    expandGitLabVariables(text: string, context?: VariableContext): string;
    openComponentBrowser(context?: ComponentContext): Promise<void>;
}

interface Component {
    name: string;
    description: string;
    parameters: ComponentParameter[];
    version?: string;
    source?: string;
    gitlabInstance?: string;
    sourcePath?: string;
    availableVersions?: string[];
    originalUrl?: string;
}

interface ComponentParameter {
    name: string;
    description?: string;
    required: boolean;
    type?: string;
    default?: any;
}

Access through:

const api = await vscode.extensions.getExtension('username.gitlab-component-helper')?.activate();
if (api) {
    const components = await api.getComponentList();
    // Use components...
}

---

🧑‍💻 Development

Prerequisites:

• VSCode 1.102.0 or higher
• Node.js 22.x or higher
• Yarn or npm

Setup:

git clone https://github.com/username/gitlab-component-helper.git
cd gitlab-component-helper
yarn install # or npm install

Build:

yarn compile # or npm run compile

Debug:

1. Open the project in VSCode
2. Press F5 to start debugging
3. A new VSCode window will open with the extension loaded

---

🤝 Contributing

1. Fork the repository
2. Create your feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes using conventional commits:
   • feat: for new features
   • fix: for bug fixes
   • docs: for documentation changes
   • chore: for maintenance tasks
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

Automated Releases

This project uses semantic-release for automated versioning and releases. When your PR is merged to main:

• Version is automatically bumped based on commit messages
• CHANGELOG.md is updated
• GitHub release is created with packaged extension
• No manual versioning needed!

See SEMANTIC_RELEASE.md for more details.

---

📄 License

Distributed under the MIT License. See LICENSE for more information.

---

⚙️ User Settings Reference

The following settings are available for the GitLab Component Helper extension. Add these to your VS Code settings.json or configure via the Settings UI:

Setting	Type	Default	Description
gitlabComponentHelper.gitlabToken	string	""	⚠️ Deprecated — stores tokens in plain text. Use the GitLab CI: Add Component Project/Group command instead, which encrypts via SecretStorage.
gitlabComponentHelper.cacheTime	number	3600	Cache time for components in seconds
gitlabComponentHelper.logLevel	string	ERROR	Logging level for component service. One of: DEBUG, INFO, WARN, ERROR
gitlabComponentHelper.autoShowOutput	boolean	false	Automatically show output channel when log level changes
gitlabComponentHelper.httpTimeout	number	10000	HTTP request timeout in milliseconds
gitlabComponentHelper.retryAttempts	number	3	Number of retry attempts for failed HTTP requests
gitlabComponentHelper.batchSize	number	5	Number of components to process in parallel batches
gitlabComponentHelper.componentSources	array	See below	GitLab repositories containing reusable CI/CD components. Each item supports an optional discovery block (override discovery defaults) and, for monorepos, a tagPattern string.
gitlabComponentHelper.discovery.templateRoots	array	["templates"]	Repository directories scanned for components. Up to 5 entries.
gitlabComponentHelper.discovery.maxDepth	number	1	Subdirectory depth to recurse under each root. Range 0–3.
gitlabComponentHelper.discovery.filePatterns	array	["*.yml", "*.yaml"]	Filename globs identifying component template files. Filename only — no path globs.
gitlabComponentHelper.discovery.templateFileNames	array	["template.yml", "template.yaml"]	Filenames recognised inside per-component subfolders (e.g. templates/foo/template.yml).

Example componentSources value:

"gitlabComponentHelper.componentSources": [
  {
    "name": "GitLab CI Examples",
    "path": "gitlab-org/gitlab-foss",
    "gitlabInstance": "gitlab.com"
  },
  {
    "name": "OpenTofu Components",
    "path": "components/opentofu",
    "gitlabInstance": "gitlab.com"
  }
]

For more details on each setting, see the extension's package.json or the VS Code Settings UI.
