Rust Automod

Art produced by Saki

Rust Automod is a Visual Studio Code extension that keeps Rust module files in sync for you. It creates and updates mod.rs, lib.rs, and main.rs module declarations automatically, supports both the classic folder/mod.rs layout and the modern folder.rs + folder/ layout, supports richer .rautomod project rules, adds syntax highlighting and formatting for .rautomod, and now includes smart mod.rs visibility controls plus preview, undo, regenerate, explain, module-tree, and Studio-style config workflows inside VS Code.

This repository now also includes a Zed adaptation under zed/README.md, focused on .rautomod workflows that fit Zed's current extension surface. The current Zed package gives .rautomod files real editor support in Zed with diagnostics, formatting, hover help, and completions, adds Rust code actions for module registration and sync, includes Assistant slash commands for scaffold, audit, explain, and module-pair creation, and now ships a Rust daemon watcher that can automatically update closed Rust module targets after file create, delete, and rename events. When a target is open in the editor, the daemon intentionally defers the write and leaves the fix available as a code action instead of risking buffer/undo conflicts. The sync path now also preserves existing declaration style in targets that are already private/public instead of promoting everything to pub mod, no longer creates broad missing mod.rs targets during generic rescans or startup noise, only manages files that are actually covered by a real .rautomod in the current subtree, trims trailing whitespace plus collapses stale blank-line runs when it rewrites a managed target, now mirrors the VS Code extension more closely when deciding whether declarations should land before or after use blocks, now discovers missing direct and parent targets during watcher/manual sync flows so nested modules without pre-existing mod.rs get picked up more reliably, keeps Rust build outputs under zed/ out of Git through a local .gitignore, and avoids re-rendering the Studio editor while you are actively typing in many form inputs.

Documentation

• For practical scenarios and copy-paste examples, see docs/USE_CASES.md.
• For a more detailed .rautomod reference, see docs/RAUTOMOD_REFERENCE.md.
• For the visual editor and manager UI flows, see docs/RAUTOMOD_STUDIO.md.
• For the Zed adaptation and its current feature matrix, see zed/README.md.
• For the Zed code-action and watcher setup on Rust files, see the install and settings section in zed/README.md.

What it does

• Creates mod.rs when a new Rust file appears in a module folder.
• Updates mod.rs, lib.rs, or main.rs when modules are added or removed.
• Detects whether a folder follows the classic mod.rs style or the modern folder.rs + folder/ style.
• Can create a modern or classic module pair automatically, including the sibling file/folder structure.
• Supports nested folders and parent module registration.
• Supports .rautomod rules for visibility, sorting, target selection, excludes, inheritance, generated comments, strict validation, and more.
• Can run cargo fmt after updates.
• Adds a dedicated file icon, syntax highlighting, linting, completions, and formatting for .rautomod.
• Opens .rautomod in a custom visual editor with Visual, Split, and Raw modes.
• Includes a workspace-wide Rust AutoMod manager UI for browsing configs, filtering audits, scaffolding new ones, and visualizing the module tree.
• Supports preview/dry run, undo of the last automod action, workspace or folder regeneration, and structured logging.
• Can explain why a file was registered a certain way and show the effective config that won for a Rust file.
• Can scaffold a .rautomod file, ignore files or folders from the Explorer, and change module visibility from quick actions.
• Hides mod.rs more intelligently in the Explorer.

How Rust AutoMod decides where to write

When Rust AutoMod reacts to a file or folder, it follows this general order:

1. It finds the effective .rautomod rule for the file, including inherited rules from extends=....
2. It checks whether the file is ignored by exclude= or by a negative pattern=!something.
3. It resolves the target file:
   • target=auto: tries the crate root target when appropriate, otherwise detects classic mod.rs vs modern sibling folder.rs
   • target=mod.rs: always writes to the local folder mod.rs
   • target=lib.rs: writes to the nearest lib.rs
   • target=main.rs: writes to the nearest main.rs
4. It generates the declaration block according to visibility, cfg, reexport, group_order, and blank_lines.
5. It sorts or reorders the managed block according to sort.

If strict=error and the .rautomod file has blocking diagnostics, Rust AutoMod stops before applying those changes.

New automod workflow features

• Preview AutoMod Changes: opens a dry-run summary and diff before writing.
• Undo Last AutoMod Action: restores the previous automod batch without relying on editor undo history.
• Regenerate Rust Modules: rebuilds missing registrations and removes stale ones for a folder or workspace.
• Create Rust Module Pair: scaffolds name/mod.rs or name.rs + name/ based on the detected project style.
• Set Module Visibility: updates the parent declaration to pub, pub(crate), or private without manually editing the parent file.
• Move Module to Crate Root: helps relocate a leaf module and rebuild declarations afterward.
• Explain AutoMod Decision: shows target file, winning rule, ordering, and generated snippet preview for a Rust file.
• Show Effective AutoMod Config: opens the resolved config, matched patterns, diagnostics, and source .rautomod.
• Open Rust AutoMod Log: opens the structured output channel with automod activity.
• Ignore in .rautomod: prepends an exclude= rule for a file or folder from the Explorer.
• Scaffold .rautomod: creates a starter config with the new keys and examples.
• Conflict detection warns when Rust AutoMod notices manual edits in the managed declaration area before writing again.

Rust module layout support

Rust AutoMod now works with both major Rust module styles:

• Classic: feature/mod.rs
• Modern: feature.rs plus feature/

In rustautomod.moduleLayout, you can choose:

• auto: detect the style from the surrounding project structure
• classic: force folder/mod.rs
• modern: force folder.rs + folder/

This affects:

• where target=auto writes declarations
• what Create Rust Module Pair scaffolds
• how folder modules appear in the manager module tree
• how regeneration detects stale declarations

Example modern layout:

src/
  lib.rs
  application.rs
  application/
    queries.rs
    services.rs

With this structure, Rust AutoMod can keep src/lib.rs and src/application.rs synchronized without depending on mod.rs.

Rust AutoMod Studio UI

Rust AutoMod now treats .rautomod as a first-class editing surface instead of only a plain text file.

There are two UI entry points:

1. A per-file visual editor for each .rautomod
2. A manager surface for browsing configs across the workspace

Visual editor for each .rautomod

Each .rautomod file can open in a custom editor with three modes:

• Visual: form-based editing for rule blocks and global config
• Split: visual cards side-by-side with the raw text
• Raw: a focused text area for manual edits

The visual editor exposes:

• schema_version, strict, and extends
• rule cards for visibility, sort, fmt, target, pattern, exclude, cfg, group_order, blank_lines, reexport, header, and generated_comment
• live audit and diagnostics feedback from the extension parser
• inline quick fixes for document and rule fields
• chip-based editors for pattern, exclude, cfg, and extends
• drag-and-drop rule ordering, plus duplicate, remove, and move actions
• impact preview showing matched, ignored, shadowed, and uncovered files
• a matching playground that explains why a path is matched, ignored, or uncovered
• local snapshot history for the current .rautomod
• real draft-state badges so you can see when Visual and Raw diverge
• Format Raw, Apply Raw Changes, and Open Raw Externally

Manager UI

Use Open Rust AutoMod Manager to open a central panel, or open the Rust AutoMod activity bar container to access the manager view.

The manager UI gives you:

• a workspace-wide list of .rautomod files
• quick search by path, workspace, strict mode, or target mode
• summary cards for configs, rules, diagnostics, uncovered files, and overlaps
• direct actions to open a config visually or in raw mode
• scaffold actions for workspace roots
• bulk actions to scaffold all roots, format all .rautomod files, regenerate the workspace, and open configs with diagnostics
• per-config audit cards with duplicate-rule, overlap, ignored, shadowed, and uncovered signals
• per-config impact samples with open-file and reveal-folder actions
• a manager-side why/why-not playground for testing individual paths
• a visual module tree built from crate roots and actual mod declarations
• quick actions on module-tree nodes to create child modules, switch visibility, open files, or move a leaf module to the crate root
• lazy-rendered tree expansion so large module hierarchies stay more responsive as you open and close branches
• stable manager expansion state with in-place tree updates, so opening and collapsing branches keeps the viewport anchored instead of jumping
• quick access to the Rust AutoMod log

This manager is meant to feel closer to a product control surface, similar in spirit to a settings UI, while still keeping the actual .rautomod file as the source of truth.

Studio gallery

The screenshots below use the pdv-server example workspace.

Manager view:

Visual editor for src/application/queries/.rautomod:

Split mode for the same config:

New mod.rs visibility features

Rust Automod now supports three Explorer workflows for mod.rs:

1. Smart hide for all index-like mod.rs
2. Manual hide for one specific mod.rs
3. Restore for both flows

Smart hide

Use the command Toggle Smart mod.rs Hiding.

When it is enabled, the extension hides only mod.rs files that behave like lightweight indexes, such as files containing only:

• mod foo;
• pub mod foo;
• #[cfg(...)] attributes attached to those declarations
• pub use ...; re-exports

If a mod.rs contains real code, like functions, structs, impls, constants, inline modules with bodies, or any other implementation content, it stays visible.

Manual hide

Right-click a mod.rs file in the Explorer and run:

• Hide This mod.rs

This hides only that file.

Restore

To restore hidden files, use:

• Restore Hidden mod.rs

If you run it from the Explorer on a specific mod.rs, it restores that file directly. If you run it from the Command Palette, the extension shows a picker with the manually hidden mod.rs files.

Commands

• Toggle Smart mod.rs Hiding
• Hide This mod.rs
• Restore Hidden mod.rs
• Preview AutoMod Changes
• Regenerate Rust Modules
• Undo Last AutoMod Action
• Explain AutoMod Decision
• Show Effective AutoMod Config
• Ignore in .rautomod
• Scaffold .rautomod
• Create Rust Module Pair
• Set Module Visibility
• Move Module to Crate Root
• Open Rust AutoMod Log
• Open .rautomod Visual
• Open .rautomod Raw
• Open Rust AutoMod Manager

Command workflows

Preview before writing

Use Preview AutoMod Changes on a Rust file or folder when you want to inspect what would change first. Rust AutoMod opens a summary plus a diff of the first affected file without writing to the workspace.

If you want this behavior automatically before every write, enable the setting:

{
  "rustautomod.previewBeforeApply": true
}

Rebuild stale module trees

Use Regenerate Rust Modules when:

• you moved many files outside VS Code
• a branch switch left stale declarations behind
• you want to rebuild a whole folder after changing .rautomod

This command scans the selected folder or workspace, re-adds missing declarations, and removes stale ones.

Create classic or modern module pairs

Use Create Rust Module Pair on a folder when you want Rust AutoMod to scaffold the next module correctly for the surrounding project style.

Depending on detection or your rustautomod.moduleLayout setting, it creates either:

• orders/mod.rs
• orders.rs plus orders/

It also registers the new module in the correct parent target and asks for the visibility up front.

Change visibility and move modules

Use:

• Set Module Visibility to switch an existing module declaration between pub, pub(crate), and private
• Move Module to Crate Root when you want to pull a leaf module upward and then let Rust AutoMod rebuild declarations

These flows are also exposed from the Studio manager module tree when applicable.

Explain and inspect

Use these two commands together when a result looks surprising:

• Explain AutoMod Decision: shows why Rust AutoMod chose a target and what lines it wants to generate
• Show Effective AutoMod Config: shows the winning rule, matched patterns, diagnostics, and config source

Ignore noisy paths

Right-click a file or folder and use Ignore in .rautomod to prepend an exclude= rule to the workspace .rautomod. This is especially useful for:

• generated code
• fixtures
• snapshots
• migration folders
• vendored examples

Edit .rautomod visually

Open any .rautomod file to work in the visual editor. Use Split when you want to see both the rule cards and the raw text at the same time.

The visual editor is especially useful when:

• you are creating a config for the first time
• you want to compare multiple rule blocks quickly
• you want guardrails around valid values such as visibility, sort, or target
• you want diagnostics visible while editing
• you want impact preview and rule-playground feedback without leaving the file
• you want to preserve unmanaged comments while still editing visually

If you want a broader workspace view, run Open Rust AutoMod Manager to open the central panel and jump into a config from there.

.rautomod configuration

Place a .rautomod file at the root of your Rust project, or inside a subfolder, to customize behavior.

The file is now recognized as its own VS Code language, with a dedicated Explorer icon, colors for comments, keys, operators, known values, cfg(...) expressions, and list entries. You can run Format Document on .rautomod files to normalize spacing, assignment style, blank lines, and comma-separated lists, and the extension now provides quick fixes for invalid keys and common missing entries.

If you prefer a GUI instead of editing raw text, open the file in the built-in visual editor. The visual editor still writes back to the same .rautomod text file, so Git history, diffs, merges, and manual editing continue to work normally.

Visual saves now try to preserve:

• leading comment blocks
• unmanaged blocks that are not recognized as Rust AutoMod keys
• comments attached to managed document/rule blocks

For a line-by-line explanation of every key, precedence rule, and matching behavior, see docs/RAUTOMOD_REFERENCE.md.

Example:

visibility=pub
sort=alpha
fmt=enabled
target=auto

Available keys:

• visibility=pub|private|pub(crate)|pub(super)
• sort=alpha|alpha_case_insensitive|none|pub_first|cfg_first
• fmt=enabled|disabled
• target=auto|mod.rs|lib.rs|main.rs
• exclude=generated/**,tests/**
• cfg=feature="serde",all(unix, target_pointer_width = "64")
• pattern=utils,helpers,!tests
• group_order=use,cfg,pub_mod,mod,pub_use
• blank_lines=0|1|2
• reexport=enabled|disabled
• header=generated by rustautomod
• generated_comment=managed by rustautomod
• strict=off|warn|error
• schema_version=1
• extends=./shared.rautomod

Example with inheritance, excludes, and generated comments:

schema_version=1
strict=warn
extends=./shared.rautomod
visibility=pub
sort=alpha
fmt=enabled
target=auto
group_order=use,cfg,pub_mod,mod,pub_use
blank_lines=1
reexport=disabled
generated_comment=managed by rustautomod

pattern=internal,!tests
visibility=private
sort=alpha_case_insensitive
exclude=generated/**
reexport=enabled

Rule behavior

• pattern supports negative entries with !.
• exclude marks matching files or folders as ignored by Rust AutoMod.
• extends resolves relative to the current .rautomod.
• target lets a rule choose mod.rs, lib.rs, main.rs, or automatic resolution.
• group_order controls how managed declarations are grouped relative to use, cfg, public/private modules, and generated pub use.
• blank_lines controls spacing between managed groups.
• strict=error makes validation strict enough for diagnostics to block automod actions that rely on the config file.

Example gallery

Here are a few common shapes that Rust AutoMod handles well:

Simple library crate

src/
  lib.rs
  api.rs
  config.rs

With target=auto, Rust AutoMod can keep src/lib.rs updated with:

pub mod api;
pub mod config;

Folder with private internals

pattern=internal,!tests
visibility=private
sort=alpha_case_insensitive

This is useful when you want helper folders to stay internal even if the rest of the crate is public.

Platform-specific module declarations

pattern=platform
cfg=unix,windows
visibility=pub

This generates #[cfg(...)] attributes before the managed declarations for matching modules.

Generated folders you never want touched

exclude=generated/**,fixtures/**

Rust AutoMod resolves the config but skips writes for matching files and folders.

Re-export based module surfaces

pattern=prelude
reexport=enabled
generated_comment=managed by rustautomod

This is handy for folders where the module file should both declare and re-export submodules.

For more complete, real-world examples, see docs/USE_CASES.md.

Installation

1. Open VS Code.
2. Open Extensions.
3. Search for Rust AutoMod.
4. Install and reload the editor.

Usage

1. Open a Rust project with a Cargo.toml.
2. Optionally add a .rautomod file.
3. Create or delete .rs files inside your module folders.
4. Use Preview AutoMod Changes when you want a dry run and diff.
5. Use Regenerate Rust Modules to rebuild a folder or workspace.
6. Use the Explorer commands when you want to hide or restore mod.rs, ignore paths, or scaffold .rautomod.
7. Use Explain AutoMod Decision and Show Effective AutoMod Config when you want to understand why a file was handled a certain way.

Internal structure

The extension was refactored so each responsibility lives in a smaller module.

Automod core

• src/automod/automodModFile.ts: orchestration for create, delete, rename, regenerate, preview, explain, ignore, and scaffold flows
• src/automod/automodRuntime.ts: shared runtime for preview, diff, undo history, conflict detection, and batch application
• src/automod/modDeclarations.ts: parsing and generation of module declaration blocks
• src/automod/modContentEditor.ts: insertion, removal, and sorting of declaration content
• src/automod/modFileSystem.ts: async file-system helpers and target-file resolution
• src/automod/cargoFmt.ts: isolated cargo fmt integration
• src/automod/automodConfigFile.ts: .rautomod parsing, inheritance, pattern matching, and effective-config resolution

Visibility and workspace state

• src/workbench/control.ts: Explorer command/controller flow
• src/workbench/modVisibility.ts: index-like mod.rs detection and exclude reconciliation
• src/workbench/modVisibilityWorkspaceService.ts: per-workspace visibility persistence and files.exclude sync
• src/workspace/workspaceStateService.ts: generic workspace-scoped state storage
• src/workspace/automodLogger.ts: structured output channel logging
• src/workspace/automodHistoryService.ts: undo stack for automod batches

.rautomod editor support

• src/linting/linting.automod.ts: .rautomod diagnostics and strict-mode severity handling
• src/linting/linting.codeActions.ts: quick fixes for invalid keys and common missing entries
• src/linting/linting.completion.ts: completions for the expanded .rautomod key set
• src/linting/linting.formatting.ts: document formatting provider for .rautomod
• src/ui/rautomodCustomEditor.ts: per-file custom editor with visual, split, and raw workflows
• src/ui/rautomodManagerView.ts: workspace manager sidebar and full manager panel
• src/ui/rautomodState.ts: view-model shaping for the UI layer
• src/ui/rautomodWebviewTemplates.ts: shared HTML shell for the Rust AutoMod Studio webviews
• media/rautomodWebview.css: shared product-style UI styling for the manager and editor
• media/rautomodEditorWebview.js: front-end logic for the per-file visual editor
• media/rautomodManagerWebview.js: front-end logic for the manager UI

Development

Scripts

• yarn compile
• yarn lint
• yarn test:unit
• yarn test
• yarn screenshots:studio

Test coverage

The project now includes:

• unit tests for visibility heuristics
• unit tests for mod.rs content editing
• unit tests for .rautomod formatting
• config-resolution tests for .rautomod inheritance, negation, and excludes
• config-serialization tests for comment and unmanaged-block preservation
• extension integration tests for Explorer commands and files.exclude
• extension integration tests for .rautomod language detection and formatting
• extension integration tests for scaffold, ignore, preview, regenerate, undo, and effective config inspection
• extension integration tests for modern module layout detection, module-pair creation, and manager module-tree rendering
• the existing debounce and rename-detection suites

Notes

• fmt=enabled requires cargo and rustfmt to be available in your environment.
• If no .rautomod file is found, Rust Automod falls back to VS Code settings under rustautomod.*.
• target=lib.rs and target=main.rs are most useful for crate-root style rules.
• The extension ignores invalid or unsafe paths such as .git, target, node_modules, and similar folders.
• Some icon themes may override the default .rautomod icon contributed by the extension.
• Visual saves still normalize managed .rautomod structure, but now try to preserve leading comments, unmanaged blocks, and comments attached to managed sections. Raw and Split are still the safest modes when exact hand-tuned formatting matters.

Contributions, issues, and feature requests are welcome.
