Skylit.DEV I/O - WordPress Sync

Real-time file synchronization between your IDE and WordPress Gutenberg.

Work in your code editor and see changes appear in Gutenberg without manually triggering sync. Designed for local development and professional workflows where WordPress background tasks are unreliable.

Requires the Skylit.DEV WordPress plugin. This extension will not work without the plugin installed on your WordPress site.

What It Does

IDE → WordPress: Save HTML/CSS and sync into Gutenberg automatically
Optional WordPress → IDE sync (when supported by your setup)
Status bar controls for connect, disconnect, and quick actions
Folder-based workflows for creating, trashing, and restoring content (plugin-dependent)

Quick Start

Install the Skylit.DEV WordPress plugin on your site (required)
Open your WordPress project in VS Code or Cursor
Click the Skylit status item in the status bar and connect
Paste the auth token generated in WordPress (WP Admin → Skylit.DEV)

Features

Automatic HTML/CSS sync to Gutenberg
Workspace detection for WordPress projects
Connection status and logs
Manual "Sync current file" command
Works on local, SSH, WSL (environment dependent)

Settings

File → Preferences → Settings → Skylit.DEV I/O

Auto Connect
Debounce Delay (default: 500ms)
Show Notifications
Cursor Tracking
Debug Output

Commands

Command Palette (Ctrl+Shift+P / Cmd+Shift+P)

Skylit: Connect to WordPress
Skylit: Disconnect
Skylit: Sync Current File
Skylit: Setup Auth Token
Skylit: Scan for WordPress
Skylit: Show Menu

Status Bar

Skylit: Connected
Skylit: Connecting...
Skylit: Disconnected
Skylit: Error

Click the status to see options and logs.

Troubleshooting

Extension won't connect

Confirm the WordPress plugin is installed and active
Regenerate the auth token in WordPress and re-enter it
Ensure REST API is reachable from your environment

Files aren't syncing

Check the status bar shows "Connected"
Make sure you're editing files in the correct folder structure
Enable Debug Output to inspect logs

Cursor sync not working

Enable Cursor Tracking in settings
Refresh the Gutenberg editor
Verify the plugin supports this feature

Requirements

VS Code or Cursor IDE (version 1.80.0 or higher)
Skylit.DEV WordPress plugin (required)
Local or remote WordPress installation

Documentation and Issues

Documentation: https://github.com/dimy-osman/skylit-dev-extension
Report Bugs: https://github.com/dimy-osman/skylit-dev-extension/issues
Plugin access: currently private while in early development

License

GPL-2.0-or-later

Technology: Axios (HTTP client)

What it does:

Sends authenticated HTTP requests to WordPress
Handles token-based authentication
Manages request/response cycle

API Endpoints Used:

File Sync: POST /wp-json/skylit/v1/sync/import-instant

{
  "post_id": 123,
  "html": "<section>...</section>",
  "css": ".class { color: red; }",
  "token": "abc123..."
}

Folder Actions: POST /wp-json/skylit/v1/sync/folder-action

{
  "post_id": 123,
  "action": "trash|restore|delete",
  "token": "abc123..."
}

Theme Folder: GET /wp-json/skylit/v1/theme/path
- Retrieves WordPress theme folder path
- Used for bidirectional theme file sync

Authentication:

Token stored in VS Code SecretStorage (encrypted)
Sent in request body (not headers for compatibility)
WordPress validates token against saved value in options table

3. Workspace Manager (`workspaceManager.ts`)

What it does:

Scans workspace for WordPress installations
Looks for wp-config.php files
Extracts site URL from wp-config
Determines prj-dev-root/ location
Supports multiple WordPress sites in one workspace

Detection algorithm:

1. Find all wp-config.php files in workspace
2. For each wp-config:
   - Parse PHP to extract WP_HOME or WP_SITEURL
   - Look for prj-dev-root/ folder nearby
   - Check if folder contains pages/ posts/ products/ etc.
3. Store detected site info (URL, dev folder, theme path)
4. Allow user to connect to each site independently

4. Status Bar (`statusBar.ts`)

What it does:

Shows connection status in VS Code status bar
Updates based on connection/sync state
Provides quick menu access

States:

✅ Skylit: Connected - Watching files, ready to sync
🔄 Skylit: Syncing... - Currently sending data to WordPress
❌ Skylit: Error - Connection failed or auth invalid
⏸️ Skylit: Disconnected - File watching stopped

5. Protocol Handler (`protocolHandler.ts`)

What it does:

Registers skylit:// URI scheme
WordPress can open IDE files via: skylit://open?file=/path/to/file.html&line=42
Used for "Jump to Code" feature from Gutenberg

How Gutenberg → IDE works:

User clicks block in Gutenberg editor
JavaScript captures click, sends AJAX to WordPress
WordPress searches HTML file for block's position
WordPress returns: { file: 'pages/home_123/home_123.html', line: 42 }
Gutenberg opens: skylit://open?file=...&line=42
Extension receives URI, opens file at exact line

Detailed Feature Breakdown

Feature 1: Instant File Sync (IDE → WordPress)

Timeline of events:

T=0ms:    You save home_123.html in IDE
T=10ms:   Chokidar fires 'change' event
T=10ms:   Extension starts 500ms debounce timer
T=510ms:  Debounce completes, extension reads file
T=520ms:  POST /wp-json/skylit/v1/sync/import-instant
          {
            post_id: 123,
            html: "<section>...</section>",
            css: ".home { color: blue; }",
            token: "abc123..."
          }
T=800ms:  WordPress receives request
T=810ms:  WordPress validates token
T=820ms:  WordPress parses HTML into Gutenberg blocks
T=850ms:  WordPress updates wp_posts.post_content
T=860ms:  WordPress returns success
T=860ms:  Extension shows "✅ Synced" notification

Meanwhile in browser:
T=0ms:    User has Gutenberg editor open
T=3000ms: Gutenberg polls for updates (every 3 seconds)
T=3050ms: WordPress returns: "content changed"
T=3100ms: Gutenberg refreshes editor with new blocks

Total latency: ~4 seconds (mostly from Gutenberg's 3s poll interval)

Feature 2: Folder Action Detection

How folder watching works:

Extension watches for these specific patterns:

pages/about_456/         ← Original location
_trash/pages/about_456/  ← Trashed location

Trash detection:

// When folder moves TO _trash/
1. Extension detects: unlink event for pages/about_456/
2. Extension checks: Does _trash/pages/about_456/ now exist?
3. If yes: POST /folder-action { action: "trash", post_id: 456 }
4. WordPress calls: wp_trash_post(456)
5. Post status → "trash"
6. Gutenberg redirects to trash page

Restore detection:

// When folder moves FROM _trash/
1. Extension detects: add event for pages/about_456/
2. Extension checks: Did _trash/pages/about_456/ just disappear?
3. If yes: POST /folder-action { action: "restore", post_id: 456 }
4. WordPress calls: wp_untrash_post(456)
5. Post status → "publish" (or previous status)
6. Gutenberg shows restored post

Delete detection:

// When folder is permanently deleted from _trash/
1. Extension detects: unlink event for _trash/pages/about_456/
2. Extension checks: Folder gone from both locations?
3. If yes: POST /folder-action { action: "delete", post_id: 456 }
4. WordPress calls: wp_delete_post(456)
5. Post removed from database

Feature 3: New Folder Detection

When you create a new post folder:

// User creates: pages/new-page/
1. Extension detects new folder
2. Extension waits 2 seconds (for HTML file creation)
3. If new-page.html exists:
   - POST /folder-action { action: "create", slug: "new-page" }
   - WordPress creates new post
   - WordPress returns new post_id
   - Extension renames folder: new-page/ → new-page_789/
4. If no HTML file: ignore (might be a temp folder)

Feature 4: Bidirectional Theme Sync

WordPress theme files sync both directions:

Theme → Dev:

WordPress child theme files (.php, .css, .js)
When modified in WordPress Customizer
Extension polls WordPress every 5 seconds
Downloads changed files to themes/child-theme/ folder

Dev → Theme:

When you edit theme files in IDE
Extension uploads to WordPress theme directory
WordPress refreshes Customizer automatically

Installation & Setup

1. Prerequisites

You must have:

Skylit Dev I/O WordPress plugin v3.5.0+ installed and activated

A WordPress development folder structure like this:

wp-content/
├── prj-dev-root/          ← Extension watches this
│   ├── pages/
│   │   └── home_123/
│   │       ├── home_123.html
│   │       └── home_123.css
│   ├── posts/
│   ├── products/
│   └── _trash/
├── themes/
└── plugins/

2. Install Extension

From Marketplace:

Open VS Code/Cursor
Extensions panel (Ctrl+Shift+X)
Search: "Skylit.DEV I/O"
Click Install

From VSIX file:

Download skylit-dev-io-X.X.X.vsix
Extensions panel → ... → Install from VSIX
Select downloaded file

3. Generate Auth Token in WordPress

Open WordPress admin
Navigate to Skylit → About
Scroll to "Extension" section
Click "Generate Auth Token"
Copy the generated token (long alphanumeric string)

What this does:

Creates a random 64-character token
Saves to WordPress options: update_option('skylit_extension_token', $token)
Extension uses this token to authenticate API requests

4. Connect Extension

Open your WordPress project in VS Code/Cursor
Extension auto-detects WordPress (searches for wp-config.php)
Status bar shows: "🔴 Skylit.DEV I/O" (red disconnected state)
When ready to connect, click the red status bar
Choose "Connect to WordPress"
If prompted, enter your WordPress site URL
Enter/paste auth token from WordPress
Status bar updates: "✅ Skylit.DEV I/O" (green connected state)

What happens internally:

1. Workspace scanned: find wp-config.php, extract site URL
2. User clicks "Connect to WordPress" → prompts appear
3. Token stored: await context.secrets.store('skylit_token', token)
4. Dev folder located: find prj-dev-root/ relative to wp-config
5. File watcher started: chokidar.watch(devFolder)
6. Test connection: GET /wp-json/skylit/v1/health
7. If success: status = "Connected" (green)

New in v1.3.4: Extension no longer auto-prompts on startup. It loads silently with a red disconnected status bar and waits for you to manually initiate connection.

Configuration

Extension Settings

Open VS Code Settings (Ctrl+,) and search for "Skylit":

{
  // Auto-connect when WordPress detected in workspace (deprecated in v1.3.4)
  // Connection is now always user-initiated via status bar click
  "skylit.autoConnect": true,

  // Milliseconds to wait after file change before syncing
  // Higher = fewer API calls, lower = faster sync
  "skylit.debounceMs": 500,

  // Show desktop notifications for sync success/errors
  "skylit.showNotifications": true,

  // Override auto-detected WordPress site URL
  // Leave empty to auto-detect from wp-config.php
  // Set this to skip the URL prompt on first connection
  "skylit.siteUrl": ""
}

Debounce Explanation

Without debounce:

You type: "Hello World"
H → sync
He → sync
Hel → sync
Hell → sync
Hello → sync
Hello  → sync
Hello W → sync
... (11 API calls)

With 500ms debounce:

You type: "Hello World"
H → (wait)
He → (reset timer)
Hel → (reset timer)
...
Hello World → (wait 500ms) → sync
(1 API call)

Commands

Access via Command Palette (Ctrl+Shift+P / Cmd+Shift+P):

Command	What It Does
`Skylit: Scan for WordPress`	Re-scan workspace for WordPress installations
`Skylit: Connect to WordPress`	Start file watching and connect to WordPress
`Skylit: Disconnect`	Stop file watching (changes won't sync)
`Skylit: Setup Auth Token`	Enter/update WordPress authentication token
`Skylit: Sync Current File`	Force immediate sync of currently open file
`Skylit: Show Menu`	Open quick menu from status bar

Troubleshooting

Extension Not Connecting

Symptom: Status bar stuck on "Disconnected" or "Error"

Check:

# 1. Is WordPress running?
curl http://localhost:8000

# 2. Is REST API accessible?
curl http://localhost:8000/wp-json/

# 3. Is Skylit plugin active?
# Check: WordPress Admin → Plugins → Skylit Dev I/O (must be blue/active)

# 4. Is token correct?
# Regenerate in WordPress, paste again in extension

Fix:

Click status bar → "Disconnect"
WordPress Admin → Skylit → About → Generate New Token
Click status bar → "Setup Auth Token"
Paste new token
Click status bar → "Connect"

File Changes Not Syncing

Symptom: You edit files, but Gutenberg doesn't update

Check:

Status bar shows "✅ Connected" (not disconnected/error)
File is inside prj-dev-root/ folder
File is *.html or *.css (other extensions not watched)
Post folder follows format: {slug}_{post_id}/

Debug:

// Open Output panel
View → Output → Select "Skylit Dev UI"

// You should see:
[14:23:45] File changed: pages/home_123/home_123.html
[14:23:45] Debouncing for 500ms...
[14:23:46] Syncing to WordPress...
[14:23:46] POST /wp-json/skylit/v1/sync/import-instant
[14:23:47] ✓ Sync successful

// If you see errors:
[14:23:47] ✗ Sync failed: 401 Unauthorized
// ^ Token invalid, regenerate in WordPress

[14:23:47] ✗ Sync failed: 404 Not Found
// ^ Post ID doesn't exist in WordPress

[14:23:47] ✗ Sync failed: ECONNREFUSED
// ^ WordPress not running

Force sync:

Open file in editor
Command Palette → "Skylit: Sync Current File"
Check Output panel for response

Folder Actions Not Working

Symptom: Moving folders to _trash/ doesn't trash posts

Common mistakes:

✗ Wrong: pages/home_123 → Recycle Bin (OS trash, extension can't detect)
✓ Right: pages/home_123 → _trash/pages/home_123 (extension detects)

✗ Wrong: pages/home/ → _trash/pages/home/ (no post ID in folder name)
✓ Right: pages/home_123/ → _trash/pages/home_123/ (has post ID)

✗ Wrong: pages/home_123.html → _trash/ (moving file, not folder)
✓ Right: pages/home_123/ → _trash/ (moving entire folder)

Check folder name:

// Folder name must be: {slug}_{post_id}
pages/about_456/          ← Correct
pages/456/                ← Wrong (no slug)
pages/about/              ← Wrong (no post ID)
pages/about-page_456/     ← Correct (slug can have hyphens)

Performance Issues

Symptom: Extension feels slow, many notifications

Possible causes:

Debounce too low: Set skylit.debounceMs higher (1000-2000ms)
Too many files: Extension watches entire prj-dev-root/, if you have 1000s of files, performance drops
Network latency: Slow connection to WordPress server

Optimize:

{
  // Increase debounce (wait longer before syncing)
  "skylit.debounceMs": 1500,

  // Disable notifications (less UI overhead)
  "skylit.showNotifications": false,

  // Manually control connection
  "skylit.autoConnect": false
}

Cross-Platform Support

This extension is fully cross-platform and works identically on:

✅ Windows (local)
✅ macOS (local)
✅ Linux (local)
✅ Remote SSH (Linux servers)
✅ WSL (Windows Subsystem for Linux)

How this is achieved:

All dependencies bundled via webpack into single JavaScript file
Platform-specific modules (like fsevents on macOS) marked as optional
Uses Node.js path module for cross-platform path handling
File watcher (chokidar) handles OS differences internally

Remote SSH: When you connect to a remote server via SSH, the extension runs on the remote server (not your local machine). This means:

File watching happens on the server
API calls are made from server to WordPress (likely localhost on server)
No network latency between extension and WordPress

Technical Specifications

Dependencies

Runtime:

chokidar ^3.5.3 - File system watcher
axios ^1.6.0 - HTTP client

Dev:

typescript ^5.0.0 - Type-safe compilation
webpack ^5.104.1 - Dependency bundling
ts-loader ^9.5.4 - TypeScript webpack loader

Bundle Size

extension.js: 354 KB (minified, all dependencies included)
VSIX package: 377 KB total (includes docs, icon, source maps)

Performance Metrics

File change detection: < 100ms (chokidar native file watching) Debounce delay: 500ms (configurable) API request time: 50-200ms (depends on server) Total sync time: ~700-800ms (detection + debounce + request) Memory usage: ~30-50 MB (Node.js + dependencies) CPU usage: < 1% idle, ~2-5% during sync

Roadmap

Current Version (1.3.1)

✅ Cross-platform support (Windows, Mac, Linux, SSH)
✅ File sync (HTML/CSS)
✅ Folder actions (trash/restore/delete)
✅ Jump-to-code (Gutenberg → IDE)
✅ Multi-site support
✅ Theme bidirectional sync
✅ New folder detection

Future Versions

v1.4.0: WebSocket support (eliminate polling, < 500ms latency)
v1.5.0: Conflict detection (warn if file edited in both places)
v1.6.0: Visual diff viewer (see changes before syncing)
v2.0.0: Live collaboration (multiple developers, one site)

License

GPL-2.0-or-later

Version: 1.3.1
Last Updated: January 2026
Made by: Skylit.DEV

Skylit.DEV I/O - WordPress Sync

Dimy Osman

Skylit.DEV I/O - WordPress Sync

What It Does

Quick Start

Features

Settings

Commands

Status Bar

Troubleshooting

Requirements

Documentation and Issues

License

3. Workspace Manager (workspaceManager.ts)

4. Status Bar (statusBar.ts)

5. Protocol Handler (protocolHandler.ts)

Detailed Feature Breakdown

Feature 1: Instant File Sync (IDE → WordPress)

Feature 2: Folder Action Detection

Feature 3: New Folder Detection

Feature 4: Bidirectional Theme Sync

Installation & Setup

1. Prerequisites

2. Install Extension

3. Generate Auth Token in WordPress

4. Connect Extension

Configuration

Extension Settings

Debounce Explanation

Commands

Troubleshooting

Extension Not Connecting

File Changes Not Syncing

Folder Actions Not Working

Performance Issues

Cross-Platform Support

Technical Specifications

Dependencies

Bundle Size

Performance Metrics

Roadmap

Current Version (1.3.1)

Future Versions

License

3. Workspace Manager (`workspaceManager.ts`)

4. Status Bar (`statusBar.ts`)

5. Protocol Handler (`protocolHandler.ts`)
