DepGraph for VS Code

Visualize and analyze source file dependencies directly in VS Code. This extension brings the full DepGraph analysis toolkit into the editor — interactive graphs, cycle detection, blast radius, file metrics, and import hover previews.

Prerequisites

The extension uses the DepGraph CLI under the hood. Install it from the project root:

pip install .

This makes the depgraph command available, which the extension invokes to build graph data.

Features

Interactive Dependency Graph

Open the command palette and run DepGraph: Show Dependency Graph to launch a Cytoscape.js graph in a webview panel. The graph includes three layout modes (Force, Hierarchy, Concentric), file search, and a right-click context menu for focusing on individual files.

The graph uses transitive reduction to remove redundant edges, logarithmic node sizing so hubs don't dominate the view, weighted edges that visually emphasize important dependency paths (thicker, darker, more opaque), and a density-adaptive force layout that adjusts spacing based on graph complexity.

Three tree views appear in the Explorer sidebar under a DepGraph section:

Dependencies — files sorted by depth, expandable to show imports and imported-by lists
Cycles — detected circular dependencies with member files
File Metrics — files sorted by impact with per-file depth, stability, and reach percentage

Tree View

A spacious hierarchical tree view shows downstream ("What breaks?") or upstream ("Depends on") dependencies for any file. Nodes display risk indicators, file-type badges, and in-degree counts. Click any node to focus the graph on that file.

Import Hover Preview

Hover over any import statement to see a mini dependency graph for the imported file — its metrics (depth, impact, stability, blast radius), who imports it, and what it imports, with second-level dependencies shown inline. Cycle membership is flagged with a warning.

Supported across all 14 languages: C/C++, JavaScript/TypeScript, Python, Java, Go, Rust, C#, Swift, Ruby, Kotlin, Scala, PHP, Dart, and Elixir.

CodeLens

Inline annotations appear above each file showing inbound/outbound dependency counts, depth, impact, and stability.

Diagnostics

The extension reports cycle membership, excessive dependency depth, and high-impact files as warnings in the Problems panel. The depth threshold is configurable via depgraph.maxDepthWarning.

Commands

Open the command palette (Cmd+Shift+P / Ctrl+Shift+P) and search for "DepGraph":

Command	Description
Show Dependency Graph	Open interactive graph in a webview panel
Find Dependency Cycles	List detected cycles in a quick-pick menu
Show Dependents of Current File	Quick-pick list of files that import the current file
Show Dependencies of Current File	Quick-pick list of files imported by the current file
Show Blast Radius of Current File	Highlight all transitive dependents
Refresh Graph	Rebuild graph data from disk
Export Graph as JSON	Write graph data to a JSON file
Export Graph as DOT	Write graph in Graphviz DOT format
Export Graph as Mermaid	Write graph as a Mermaid diagram

Right-click any file in the editor to access Show Dependents, Show Dependencies, and Blast Radius directly.

Settings

Configure under depgraph.* in VS Code settings:

Setting	Default	Description
`pythonPath`	`python3`	Path to the Python interpreter with depgraph installed
`language`	`auto`	Language mode — `auto` detects from file types, or force a specific language (c, cpp, js, py, java, go, rust, cs, swift, ruby, kotlin, scala, php, dart, elixir)
`hideExternal`	`true`	Hide system/external imports from the graph
`hideIsolated`	`false`	Hide files with no dependencies
`maxDepthWarning`	`8`	Depth threshold for diagnostic warnings
`autoRefresh`	`true`	Automatically refresh the graph when files change

Supported Languages

C, C++, JavaScript, TypeScript, Python, Java, Go, Rust, C#, Swift, Ruby, Kotlin, Scala, PHP, Dart, and Elixir. Language detection is automatic based on which file types are present in the workspace.

Development

cd vscode-extension
npm install
npm run compile

Press F5 in VS Code to launch an Extension Development Host for testing. The extension compiles TypeScript from src/ to out/.

Architecture

File	Purpose
`extension.ts`	Activation, command registration, file watchers
`engine.ts`	Spawns DepGraph CLI, caches and parses graph data
`sidebar.ts`	Tree view providers for dependencies, cycles, and metrics
`commands.ts`	Command implementations (graph, cycles, blast radius, export)
`webview.ts`	Interactive Cytoscape.js graph and tree view in a VS Code panel
`hover.ts`	Mini dependency graph on import hover (14 language patterns)
`codeLens.ts`	Inline dependency counts and metrics above files
`diagnostics.ts`	Cycle, depth, and high-impact warnings in Problems panel
`config.ts`	Reads workspace settings
