DC VS Code Extension

VS Code support for building and testing connectors against the Data Connector platform. It lists test credentials from the hosted API, runs the same authenticate → get_objects → get_fields / get_data flow as the platform UI through your local workspace HTTP server, and opens webviews for credential detail and object field inspection.

Requirements

Data Connector API reachable at the origin you configure (default https://dev.dataconnector.com). You need a valid access token and a connector UUID.
Local connector / workspace server (default http://127.0.0.1:5001) exposing POST /invoke for authenticate, get_objects, get_fields, and get_data, matching your connector template. Set the workspace API key if your server requires it.
VS Code ^1.110.0 (see engines in package.json).

Test Connection view

Open the Explorer sidebar and find Test Connection (contributed under the Explorer views).

If anything is missing, the tree shows actions: set API base URL, connector ID, or access token.
After configuration, the tree loads credentials from
GET /api/connector/{connectorId}/credential?test=true.
Click a credential to test connection. The extension:
- Fetches decrypted invoke credentials from the API
- Calls your workspace server: authenticate, then get_objects
On success, expand the credential to see objects. Click an object (with a resolvable object_id) to open object fields in a webview (loads fields and sample data via get_fields / get_data).
Use the view title actions Refresh and Set connector ID as needed.

Errors from the connector appear under the credential with optional raw invoke payloads in the tooltip.

Commands (Command Palette)

All commands use the category Data Connector:

Command	Purpose
Refresh	Reloads the Test Connection tree
Set connector ID	Prompts for the connector UUID; saved to workspace settings when a folder is open, otherwise user settings
Open credential detail	Opens the credential detail webview; requires `connectorId` and `credentialId` arguments (e.g. from another extension or a keybinding)
Test connection	Runs the workspace flow for a credential (normally triggered from the tree)
Open object fields	Opens the object fields webview; requires session/object arguments (normally triggered by clicking an object in the tree)
Set Data Connector access token	Stores the token in VS Code Secret Storage
Set workspace server API key	Stores the key in VS Code Secret Storage
Open Data Connector settings	Opens Settings filtered to `dc.dataConnector`

Extension settings

Setting	Default	Description
`dc.dataConnector.apiBaseUrl`	`https://dev.dataconnector.com`	Data Connector API origin (no trailing slash)
`dc.dataConnector.connectorId`	(empty)	Connector UUID for `/api/connector/{id}/...`
`dc.dataConnector.apiKeyHeader`	`x-data-connector-access-token`	Header name for the Data Connector access token
`dc.workspaceServer.baseUrl`	`http://127.0.0.1:5001`	Local workspace server origin (no trailing slash)
`dc.workspaceServer.apiKeyHeader`	`x-api-key`	Header name for the workspace server secret
`dc.workspaceServer.healthPath`	`/health`	Path used for health-related checks / samples

Changing dc.dataConnector.* refreshes the Test Connection view automatically.

Secrets

Sensitive values are not stored in settings.json. They use VS Code’s Secret Storage:

Data Connector access token — sent with dc.dataConnector.apiKeyHeader
Workspace server API key — sent with dc.workspaceServer.apiKeyHeader

Set them via the Command Palette commands above.

Development

cd apps/dc-vscode-ext
npm install
npm run compile

Watch: npm run watch
Package for publish: npm run package (runs typecheck, lint, production esbuild)

In VS Code, open this folder and use Run Extension (F5); launch.json runs the npm: compile extension preLaunch task.

Scripts

Script	Description
`compile`	Typecheck, lint, bundle with esbuild
`package`	Same as compile with production flags (used by `vscode:prepublish`)
`lint`	ESLint on `src`
`check-types`	`tsc --noEmit`
`test`	`@vscode/test-electron` test runner
