Twee 3 Language Tools

cyrusfirheir

|
504 installs
| (1) | Free
Syntax highlighting and programmatic language tools for Twee 3.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

Twee 3 Language Tools

Syntax highlighting for HTML and select storyformats (see Features) on top of Twee 3 code.

Made possible through contributions from @Goctionni and @MinusGix, and feedback from the folks over at the Twine Games Discord Server.

Features

Twee

  • Syntax highlighting.

  • Command palette tool to generate IFID: open the command palette (Ctrl/Cmd + Shift + P by default) and search for "IFID".

  • A list of passages for quick jumps (can be grouped by files, folders, or passage tags. See extension-settings.) Open from the Twee 3 Language Tools tab on the activity bar (the forking paths logo.)

    Passage List

  • A story-map view (Contributed by @Goctionni) that opens in the browser! Still in very early stages. Also accessible from the Twee 3 Language Tools tab on the activity bar. Currently implemented features:

    • Snap to grid (button on top-left.)
    • Arrows to linked passages.
    • Passage tags, position, and size editing via a sidebar. Changes can be saved to file.

    Story Map

Chapbook

(id: chapbook-1)

  • Syntax highlighting.
    Chapbook syntax

Harlowe

(id: harlowe-3)

  • Syntax highlighting.
    Harlowe syntax

SugarCube

(id: sugarcube-2)

  • Syntax highlighting.
    SugarCube syntax
  • Macro documentation on hover. (Contributed by @MinusGix) (Custom definitions can be added via *.twee-config.yml. See: Custom macro definitions for SC) Screenshot
  • Container macro pair highlights. SC macro pairs
  • Diagnostics:
    • Macros with opening tags but no closes (and vice-versa):
      • Screenshot - diagnostics
    • Deprecated macros:
      • Screenshot - diagnostic
    • Deprecated <<end...>> closing macros:
      • Screenshot - diagnostic
      • Screenshot - quick fix
    • Unrecognized macros. New/custom macros can be defined manually (see: Custom macro definitions for SC), but anything else will throw a warning. This can be turned off by the twee3LanguageTools.sugarcube-2.undefinedMacroWarnings setting (see settings):
      • Screenshot - diagnostic
      • Screenshot - quick fix (Writes definitions to t3lt.twee-config.yml in the root of the first workspace folder.)
    • Invalid argument syntax in macros (Contributed by @MinusGix):
      • Screenshot - diagnostics
    • Argument validation (Contributed by @MinusGix): Read here for more information.

Requirements

The extension relies on a workspace (or a folder) being open. If single files are to be edited, the storyformat must be configured manually.

Supported file extensions:

  • .tw
  • .twee

To set the correct storyformat for the files, a StoryData passage with the storyformat (and version) (see example below) mentioned in it is preferred. If not, the extension provides the option to set the format explictly. (See Extension Settings.)

:: StoryData
{
	"ifid": "514BB5F3-27EC-40E4-936B-45A21A048BCC",
	"format": "SugarCube",
	"format-version": "2.33.2"
}

twee-config

Custom Macro definitions for SugarCube

The extension adds diagnostics for erroneous usage of macros in TwineScript for the sugarcube-2 storyformat. By default, only the definitions for the core SugarCube library are present, but custom definitions can be added. The process is as follows:

  1. Add a *.twee-config.yaml (or .yml) OR *.twee-config.json (* represents any valid file name) file to your project folder (or anywhere in the workspace.)
  2. Define custom macros as follows:
    • If using *.twee-config.yaml (indentation is important for YAML files):
        sugarcube-2:

          macros:

            customMacroName:
              container: true

            anotherOne: {}

    • If using *.twee-config.json:
        {
        	"sugarcube-2": {
        		"macros": {
        			"customMacroName": {
        				"container": true
        			},
        			"anotherOne": {}
        		}
        	}
        }


The following properties are currently programmed, even though not all of them are used as of now:

  • name (string) optional: Name of the macro (currently unused in code; the name of the object suffices for now.)
  • description (string) optional: Description of macro. Shown on hover. Supports markdown.
  • container (boolean) optional: If the macro is a container (i.e. requires a closing tag) or not. false by default.
  • selfClose (boolean) optional: If the macro is a self-closable. Requires macro to be a container first. false by default.
  • children (string array) optional: If the macro has children, specify their names as an array (currently unused in code.)
  • parents (string array) optional: If the macro is a child macro, specify the names of its parents as an array (currently unused in code.)
  • deprecated (boolean) optional: If the macro is deprecated or not. false by default.
  • deprecatedSuggestions (string array) optional: If the macro is deprecated, specify any alternatives to the macro as an array.
  • parameters (object) optional: Allows for macro argument validation. Read here for more information.

NOTE: Multiple twee-config files can be present in a workspace. They will stack and add to the macro definitions for the workspace. The recommended strategy is to make separate files for separate macro sets/libraries, e.g. (the following file can also be used as an example):

  • click-to-proceed.twee-config.yaml (Link)

Extension Settings

This extension contributes the following settings:

Automatically set by the StoryData special passage (if it exists):

  • twee3LanguageTools.storyformat.current: Identifier of the storyformat in use.

Manual settings:

NOTE: It's recommended to change these settings separately for each workspace instead of globally.

  • twee3LanguageTools.storyformat.override : Identifier of the storyformat to override the format set by StoryData.
    ⠀
  • twee3LanguageTools.directories.include: Directories in which to look for twee files. Use glob patterns relative to the root of the workspace folders (e.g. src/unprocessed/twee, src/static, external). (Searches the entire workspace by default.)
  • twee3LanguageTools.directories.exclude: Directories to exclude from the search of twee files. Use absolute glob patterns (e.g. **/src/processed/**). (Excludes **/node_modules/** by default.) If passage listing is active, excluded files will not be scanned for passages. They also will not be scanned for errors until manually opened.
    ⠀
  • twee3LanguageTools.storyMap.unusedPortClosingDelay: Duration in milliseconds before the story-map server port is closed after the UI in the browser window has been closed. (5000 by default.) ⠀
  • twee3LanguageTools.passage.list: Display list of passages with quick 'jump' links? (false by default.)
  • twee3LanguageTools.passage.group: Group passages by? (None by default. Can be grouped by file of origin, folder of origin, or passage tags.)
    ⠀
  • twee3LanguageTools.twee-3.warning.spaceAfterStartToken: Warn about missing space after the start token (::) in passage headers? (true by default.)
    ⠀
  • twee3LanguageTools.sugarcube-2.warning.undefinedMacro: Warn about macros/widgets which were not found in definitions (*.twee-config.yaml or *.twee-config.json files) or the core SugarCube macro library? (true by default.)
  • twee3LanguageTools.sugarcube-2.warning.deprecatedMacro: Warn about deprecated macros/widgets? (true by default.)
  • twee3LanguageTools.sugarcube-2.warning.endMacro: Warn about the deprecated <<end...>> closing tag syntax? (true by default.)
  • twee3LanguageTools.sugarcube-2.warning.barewordLinkPassageChecking: Provides warnings for links like [[passage]] when passage is not a valid passage name. This could cause false positives in cases where you are using a global variable. (true by default.)
    ⠀
  • twee3LanguageTools.sugarcube-2.error.argumentParsing: Provide errors about invalid argument syntax being passed into macros? (true by default.)
  • twee3LanguageTools.sugarcube-2.error.parameterValidation: Provide errors about invalid argument types being passed into macros? (true by default.)
    ⠀
  • twee3LanguageTools.sugarcube-2.features.macroTagMatching: Highlight opening and closing tags of container macros? (true by default.)
    ⠀
  • twee3LanguageTools.experimental.sugarcube-2.selfClosingMacros.enable: Enable self-closing syntax for container macros? Read here for more information. (false by default.)
  • twee3LanguageTools.experimental.sugarcube-2.selfClosingMacros.warning.irrationalSelfClose: Warn about self-closed instances of content focused macros (e.g. <<script />>)? (true by default.)

Experimental Stuff

SugarCube-2: Self-closing macros

NOTE: SugarCube 2 does NOT have a self-closing syntax for container macros, this feature is just to support custom passage processing functions.

Example of such a function which replaces self-closed instances with the actual closing macro tag (i.e. <<macro />> with <<macro>><</macro>>):

Config.passages.onProcess = function(p) {
    return p.text.replace(/<<([A-Za-z][\w-]*|[=-])((?:\s*)((?:(?:`(?:\\.|[^`\\])*`)|(?:"(?:\\.|[^"\\])*")|(?:'(?:\\.|[^'\\])*')|(?:\[(?:[<>]?[Ii][Mm][Gg])?\[[^\r\n]*?\]\]+)|[^>]|(?:>(?!>)))*))\/>>/gm, "<<$1$2>><</$1>>");
};

The twee3LanguageTools.experimental.sugarcube-2.selfClosingMacros.enable setting enables detection of self-closed macros.


Known issues

Argument validation is still a work in progress. Passage name validation, especially. Shouldn't hinder workflow, however.


Changelog

Changelog here.
