IFML DOP Editor

Graphical editor for IFML (Interaction Flow Modeling Language) diagrams in VS Code. Create new IFML models, manage related resources, and edit element properties in a dedicated IFML panel.

Based on BigUML. See https://github.com/borkdominik/bigUML for reference.

Quick Start

1. Press Ctrl+Shift+P and run Create New Empty IFML Diagram.
2. Choose IFML.
3. Enter a valid file name.

A new workspace will be created with a .core file and a .unotation file.

Add a new core file to an existing .unotation

1. Press Ctrl+Shift+P and run Add New Core File to Existing .unotation.
2. Select the target .unotation.
3. Enter a valid file name.

Edit IFML element properties

1. Click an IFML element in the diagram.
2. Open the IFML tab in the activity bar.
3. Use the Properties view to edit the selected element.

Commands

• Create New Empty IFML Diagram
• Add New Core File to Existing .unotation
