Web Lens

Inspect elements, annotate screenshots, record user flows, and capture console logs, all without leaving VS Code.

VS Code Marketplace: Web Lens

Source Code: https://github.com/collectiveai-team/vscode-web-lens

WebLens is an embedded browser for sending page context to AI coding agents

The key features are:

Embedded browser panel — Browse your web app inside a VS Code tab with full navigation (back, forward, reload, URL bar)
Inspect Element — Click any element to see its tag, classes, dimensions, and accessibility info
Add Element to Chat — Send an element's full context (HTML, styles, attributes, ancestor path, React source location) to your AI agent
Annotate Screenshot — Draw arrows, shapes, callouts, and text on top of a screenshot, then send the annotated image with a prompt to your AI agent
Record User Actions — Capture clicks, inputs, scroll, and navigation as a structured JSON event log — ready to feed to an AI agent for generating automated tests
Add Logs to Chat — Capture console output (log, warn, error) from the embedded page and deliver it as context
Screenshot — Take a screenshot of the current page and send it to your AI agent
Multi-agent support — Deliver context to OpenCode, OpenChamber, Claude Code, Codex, or the clipboard
Theme-aware UI — Adapts to your VS Code light/dark theme

How It Works

Web Lens runs a local reverse proxy that loads your web app inside a VS Code webview iframe:

A local HTTP proxy fetches target pages and injects an inspection script
The inject script enables element selection, DOM extraction, console capture, screenshot capture, and user action recording inside the target page
When you inspect, annotate, or capture context, the extension bundles it (HTML, styles, screenshot, logs) and delivers it to your selected AI agent
Context is saved as temporary files (.txt and .png) in a configurable directory, auto-cleaned after 1 hour

The proxy strips Content-Security-Policy and X-Frame-Options headers so pages render correctly in the iframe.

Agent Integrations

Web Lens integrates with five backends. The toolbar shows availability status for each — if the selected backend is unavailable, it falls back to the clipboard.

Agent	Extension	Delivery Method
OpenCode	`anomalyco.opencode`	HTTP API with `@file` references
OpenChamber	`fedaykindev.openchamber`	`openchamber.addToContext` command
Claude Code	`anthropic.claude-code`	`claude-vscode.insertAtMention` command
Codex	`openai.chatgpt`	`chatgpt.addToThread` command
Clipboard	—	Copies file paths to clipboard (always available)

Requirements

VS Code 1.85.0+
A running web app to inspect (defaults to http://localhost:3000)

Configuration

Setting	Default	Description
`webLens.backend`	`"clipboard"`	Active backend: `opencode`, `openchamber`, `claudecode`, `codex`, `clipboard`
`webLens.defaultUrl`	`"http://localhost:3000"`	URL loaded when the browser panel opens
`webLens.screenshotFormat`	`"png"`	Screenshot format: `png` or `jpeg`
`webLens.screenshotQuality`	`0.9`	JPEG quality (0.1–1.0), ignored for PNG
`webLens.contextDirectory`	`".tmp"`	Directory for context files (relative paths resolve from workspace root)

Commands

Command	Description
Web Lens: Open	Open the browser panel
Web Lens: Open URL	Open a specific URL in the browser panel
Web Lens: Inspect Element	Enter element inspection mode
Web Lens: Add Element to Chat	Click an element to send its context to your AI agent
Web Lens: Add Logs to Chat	Send captured console logs to your AI agent
Web Lens: Screenshot	Take a screenshot and send it to your AI agent
Web Lens: Toggle Recording	Start or stop a user action recording session

The Annotate Screenshot button is available directly in the browser panel toolbar.

Use Web Lens: Toggle Recording (or the record button in the toolbar) to capture what you do in the embedded browser. When you stop, the session is saved as a JSON file in .weblens-recordings/ at your workspace root:

.weblens-recordings/
  1712345678-localhost.json   ← clicks, inputs, scroll, navigation events

Feed this file to your AI agent to generate automated tests, reproduce bugs, or document flows.

Troubleshooting

Panel shows a blank page

Check if your web app is running at the configured URL
Some pages with strict CSP may not render correctly through the proxy

Element inspection not working

Ensure the page has fully loaded before entering inspect mode
Pages with aggressive iframe-busting scripts may interfere with the inject script

Context not delivered to AI agent

Verify the target extension is installed and active
Check the backend selector dropdown for availability status
The clipboard fallback always works — check your clipboard if delivery fails

Development

npm install        # Install dependencies
npm run build      # Build extension + webview + inject script
npm run typecheck  # Run TypeScript type checking
npm run lint       # Run ESLint
npm run test:unit  # Run unit tests (vitest)
npm run test       # Run all tests (unit + integration)
npm run package    # Build and package as .vsix

License

MIT

collectiveai-team
