Markdown to PDF (with Mermaid & Math)

📑 Table of Contents

• 🚀 Overview
• ✨ Key Features
• 🎯 Quick Start Guide
• 📊 Supported Mermaid Diagram Types
• 📐 KaTeX LaTeX Mathematical Typesetting
• 🖼️ Smart Local & Relative Image Inlining
• 📄 Intelligent Pagination & Print Engine
• 🖱️ Ways to Export
• ⚙️ Configuration & Settings
• 🆚 Comparison Matrix
• 🔒 Privacy & Security Architecture
• ❓ Troubleshooting & FAQ
• 🛠️ Development & Building
• 🤝 Contributing Guide
• 📄 License & Author

🚀 Overview

Markdown to PDF (with Mermaid & Math) is a modern, 100% offline and local-first Visual Studio Code extension engineered to convert your Markdown (.md) documents into print-ready, publication-grade PDF files.

• GitHub Repository: https://github.com/Dragonwinner/markdown-pdf-exporter.git
• Source Code & Releases: https://github.com/Dragonwinner/markdown-pdf-exporter

Traditional markdown-to-PDF solutions often suffer from critical issues:

• They require downloading heavy headless browser binaries (Puppeteer / Chromium > 300MB) that fail in restricted enterprise environments.
• They fail to render or mangle Mermaid diagrams (cut-off boundaries, distorted fonts, dark theme glitches).
• They lack native support for KaTeX LaTeX math equations or corrupt math formulas during HTML parsing.
• They break pages mid-heading (orphan headers) or fail to resolve relative image paths.

Markdown to PDF solves all of these problems with a bundled client-side rendering pipeline powered by Mermaid 11, KaTeX, Marked, DOMPurify, and jsPDF—giving you pixel-perfect, crisp vector documents without external dependencies.

✨ Key Features

• 📊 High-DPI Mermaid Diagram Engine: Pre-renders SVGs at 2x/3x Retina resolution to crisp PNG vector assets with light background isolation before document assembly.
• 📐 Comprehensive KaTeX LaTeX Math: Beautiful rendering of inline formulas ($E=mc^2$) and multiline block matrices/equations ($$\int_a^b f(x)dx$$).
• 🛡️ Code Block Shielding: Mathematical dollar signs ($) inside inline code (`let $var = 1`) or fenced code blocks (```) are safely shielded and never corrupted.
• 🖼️ Automatic Base64 Image Inlining: Scans relative and local image paths (./images/flow.png, ../assets/logo.svg, etc.) and embeds them directly as Base64 data URIs.
• 📄 Smart Anti-Orphan Pagination: Calculates page layout dynamically, keeping section headings (h1–h6) bound to their child content and preventing awkward page breaks.
• 🎨 5 Built-in Mermaid Themes: Choose from default, neutral, dark, forest, and base themes to match your preferred aesthetic.
• 📐 Flexible Page Geometry: Configure A4, Letter, or Legal formats in portrait or landscape orientations with customizable margin padding.
• 🔒 100% Private & Offline: Zero external network calls, zero analytics/telemetry, and strict Content Security Policy (CSP) enforcement.
• ⚡ Fast 1-Click Export: Trigger from the editor title bar, editor context menu, explorer context menu, or Command Palette.

🎯 Quick Start Guide

Step 1: Open or Create a Markdown Document

Create a .md file with Markdown text, tables, math equations, and Mermaid diagrams:

# High-Performance API Gateway

This document outlines the distributed architecture and routing metrics.

## Architecture Flow

```mermaid
flowchart TD
    Client[Client App] -->|HTTPS| Gateway[API Gateway]
    Gateway --> Auth[Auth Service]
    Gateway --> Orders[Order Processing]
    Orders --> DB[(PostgreSQL)]
```

## Latency SLA Calculation

The allowable tail latency bounds are governed by:

$$L_{\text{total}} = L_{\text{gateway}} + \max(L_{\text{auth}}, L_{\text{orders}}) + \epsilon$$

Where inline jitter satisfies $\epsilon \le 2.5\text{ms}$.

Step 2: Trigger the PDF Export

You have three intuitive ways to export:

1. Editor Title Bar: Click the PDF icon ($(file-pdf)) in the top-right corner of the editor.
2. Right-Click Context Menu: Right-click anywhere in the editor or on a .md file in the Explorer and choose Export Markdown as PDF.
3. Command Palette: Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (macOS) and run Export Markdown as PDF.

Step 3: Save and Open

1. Choose your destination file path in the save dialog and click Save.
2. A progress indicator will display live rendering status.
3. Upon completion, click Open PDF in the notification banner to view your document immediately.

📊 Supported Mermaid Diagram Types

The extension bundles Mermaid v11.16.1, supporting all modern diagram syntax inside standard ```mermaid fences:

1. Flowcharts (flowchart / graph)

```mermaid
flowchart LR
    Start([Request Received]) --> Validate{Valid Token?}
    Validate -- Yes --> Process[Execute Query]
    Validate -- No --> Reject[Return 401 Unauthorized]
    Process --> Cache[(Redis Cache)]
    Process --> Respond([HTTP 200 OK])
```

2. Sequence Diagrams (sequenceDiagram)

```mermaid
sequenceDiagram
    autonumber
    actor User
    participant App as Web App
    participant API as API Server
    participant DB as Database

    User->>App: Click Checkout
    App->>API: POST /api/checkout
    API->>DB: Deduct Inventory & Create Order
    DB-->>API: Transaction Committed
    API-->>App: 201 Created
    App-->>User: Show Confirmation Screen
```

3. Class Diagrams (classDiagram)

```mermaid
classDiagram
    class Vehicle {
        +String make
        +String model
        +int year
        +startEngine() void
    }
    class ElectricCar {
        +int batteryCapacity
        +chargeBattery() void
    }
    Vehicle <|-- ElectricCar
```

4. State Diagrams (stateDiagram-v2)

```mermaid
stateDiagram-v2
    [*] --> Idle
    Idle --> Processing : Submit Task
    Processing --> Succeeded : Complete
    Processing --> Failed : Exception
    Failed --> Retrying : Retry Count < 3
    Retrying --> Processing : Attempt
    Failed --> [*] : Terminated
    Succeeded --> [*]
```

5. Entity Relationship Diagrams (erDiagram)

```mermaid
erDiagram
    USER ||--o{ ORDER : places
    ORDER ||--|{ LINE_ITEM : contains
    PRODUCT ||--o{ LINE_ITEM : "ordered in"
    USER {
        string id PK
        string email
        string name
    }
    ORDER {
        string id PK
        string user_id FK
        datetime created_at
        float total_amount
    }
```

6. Gantt Charts (gantt)

```mermaid
gantt
    title Project Delivery Schedule
    dateFormat  YYYY-MM-DD
    section Phase 1 - Architecture
    System Design       :done,    des1, 2026-09-01, 2026-09-07
    Security Audit      :active,  sec1, 2026-09-08, 5d
    section Phase 2 - Implementation
    Core API Engine     :         dev1, after sec1, 14d
    Frontend Webview    :         dev2, after sec1, 10d
```

7. Git Graphs (gitGraph)

```mermaid
gitGraph
    commit id: "Initial Release"
    branch feature/math-engine
    checkout feature/math-engine
    commit id: "Add KaTeX parser"
    commit id: "Fix DOM placeholders"
    checkout main
    merge feature/math-engine id: "Merge PR [#42](https://github.com/Dragonwinner/markdown-pdf-exporter/issues/42)"
    commit id: "Bump v1.0.1" tag: "v1.0.1"
```

8. Mindmaps (mindmap)

```mermaid
mindmap
  root((Software Architecture))
    Backend
      Microservices
      Event Sourcing
      Caching
    Frontend
      VS Code Webview
      TypeScript
      Tailored CSS
    Infrastructure
      Docker
      CI/CD
```

9. Pie Charts (pie)

```mermaid
pie title Task Allocation
    "Core Exporter Engine" : 45
    "Mermaid & Math Subsystem" : 30
    "UI / UX Design" : 15
    "Documentation" : 10
```

10. Quadrant Charts (quadrantChart)

```mermaid
quadrantChart
    title Feature Impact vs Effort
    x-axis Low Effort --> High Effort
    y-axis Low Impact --> High Impact
    quadrant-1 Strategic Bets
    quadrant-2 Quick Wins
    quadrant-3 Deprioritized
    quadrant-4 Maintenance
    "High-DPI Mermaid": [0.3, 0.85]
    "KaTeX Math": [0.35, 0.9]
    "Headless Puppeteer": [0.85, 0.3]
```

11. Requirement Diagrams (requirementDiagram)

```mermaid
requirementDiagram
    requirement test_req {
        id: 1
        text: System must export PDF locally.
        risk: high
        verifymethod: test
    }
    element test_module {
        type: module
    }
    test_module - satisfies -> test_req
```

12. C4 Architecture Diagrams (C4Context)

```mermaid
C4Context
    title System Context for Internet Banking
    Person(customer, "Banking Customer", "Customer of the bank.")
    System(banking_system, "Internet Banking System", "Allows customers to view accounts and make transactions.")
    System_Ext(mail_system, "E-mail System", "Internal exchange system.")
    Rel(customer, banking_system, "Uses")
    Rel(banking_system, mail_system, "Sends e-mails using")
```

📐 KaTeX LaTeX Mathematical Typesetting

The extension integrates KaTeX v0.18.4 for high-fidelity, publication-quality mathematical notation.

Inline Equations

Enclose standard TeX syntax in single dollar signs ($...$):

• Kinetic Energy: $E_k = \frac{1}{2}mv^2$
• Standard Deviation: $\sigma = \sqrt{\frac{1}{N} \sum_{i=1}^N (x_i - \mu)^2}$
• Euler's Formula: $e^{i\theta} = \cos\theta + i\sin\theta$

Display (Block) Equations

Enclose complex multiline formulas, integrals, and matrices in double dollar signs ($$...$$):

$$f(x \mid \mu, \sigma^2) = \frac{1}{\sqrt{2\pi\sigma^2}} \exp\left( -\frac{(x - \mu)^2}{2\sigma^2} \right)$$

$$\begin{bmatrix} \cos\theta & -\sin\theta \ \sin\theta & \cos\theta \end{bmatrix} \begin{bmatrix} x \ y \end{bmatrix}

\begin{bmatrix} x\cos\theta - y\sin\theta \ x\sin\theta + y\cos\theta \end{bmatrix}$$

$$\oint_C \mathbf{B} \cdot d\mathbf{l} = \mu_0 \left( I_{\text{enc}} + \varepsilon_0 \frac{d\Phi_E}{dt} \right)$$

Safe Code Protection

Equations and dollar signs inside inline code (e.g. `$variable`) or code fences (e.g. ```bash) are preserved without unwanted KaTeX parsing.

🖼️ Smart Local & Relative Image Inlining

Never worry about broken images or missing file references when sharing exported PDFs:

• Supported Image Formats: PNG (.png), JPEG (.jpg, .jpeg), GIF (.gif), WebP (.webp), SVG (.svg), and BMP (.bmp).
• Relative Path Resolution: Automatically resolves paths relative to the active Markdown file (e.g. ![Diagram](https://github.com/Dragonwinner/markdown-pdf-exporter/raw/HEAD/assets/arch.png) or ![Logo](https://github.com/Dragonwinner/markdown-pdf-exporter/raw/HEAD/../images/logo.svg)).
• Embedded Base64: Images are converted to in-memory Base64 data URIs before PDF generation, ensuring 100% self-contained documents.
• External Image Support: Secure HTTPS images (e.g. https://example.com/image.png) are safely rendered when network connectivity is available.

📄 Intelligent Pagination & Print Engine

Unlike standard browser "Print to PDF" which frequently cuts lines of text or leaves lone headers at page bottoms, this extension includes an intelligent layout engine:

1. Anti-Orphan & Anti-Widow Rules: Headings (h1–h6) are never left stranded at the bottom of a page without at least their subsequent child content.
2. Container Preservation: Tables, code blocks, math formulas, and Mermaid diagrams are measured before rendering to avoid mid-element splits whenever possible.
3. High-DPI Raster Scaling: Mermaid diagrams and rich vector content are rendered at 2x or 3x scale factor to preserve crispness when printed on high-resolution physical printers.
4. Custom Page Sizes: Native support for standard paper sizes (A4, US Letter, US Legal) in both Portrait and Landscape orientations.

🖱️ Ways to Export

⚙️ Configuration & Settings

Fine-tune your export preferences via VS Code Settings (Ctrl+, or Cmd+, → search Markdown PDF):

Example settings.json

{
  "markdownPdf.previewTheme": "neutral",
  "markdownPdf.pageSize": "a4",
  "markdownPdf.orientation": "portrait",
  "markdownPdf.margin": 36,
  "markdownPdf.highDpi": 2
}

🆚 Comparison Matrix

🔒 Privacy & Security Architecture

• 100% Local Processing: Every parsing, diagram rasterization, math rendering, and PDF assembly step runs entirely inside your local VS Code instance.
• Zero Telemetry: No user data, file contents, filenames, or metrics are ever collected or sent to any remote server.
• Strict Content Security Policy (CSP): The embedded export webview operates under an isolated CSP sandbox (default-src 'none'; img-src data:; style-src 'nonce-...' 'unsafe-inline'; script-src 'nonce-...';) preventing script injection or unauthorized network activity.
• Safe HTML Sanitization: All parsed markdown content is sanitized through DOMPurify before rendering to safeguard against malicious markdown injections.

❓ Troubleshooting & FAQ

Q: Why didn't my Mermaid diagram render?

A: Ensure your diagram is placed inside a valid fenced code block labeled ```mermaid:

```mermaid
graph TD
    A --> B
```

If there is a syntax error in your diagram code, the exporter will render the diagram text alongside a helpful red warning message identifying the syntax error without failing the rest of your document export.

Q: Why are my equations not rendering?

A: Make sure single dollar signs ($...$) for inline math and double dollar signs ($$...$$) for display math are properly paired. Ensure there are no escaped backslashes interfering with the delimiters. Dollar signs inside code blocks (`code`) are intentionally ignored.

Q: Can I export in Landscape mode for wide tables or Gantt charts?

A: Yes! Open your VS Code Settings (Ctrl+,), search for markdownPdf.orientation, and set it to landscape.

Q: Does this work in restricted offline enterprise environments?

A: Yes. The extension has zero runtime downloads and does not require internet access or headless browser binaries.

🛠️ Development & Building

To clone, build, and test the extension locally:

# 1. Clone the GitHub repository
git clone https://github.com/Dragonwinner/markdown-pdf-exporter.git
cd markdown-pdf-exporter

# 2. Install dependencies
npm install

# 3. Type check & build production bundles
npm run compile

# 4. Package VSIX extension locally
npm run package

🤝 Contributing Guide

Contributions from the developer and open-source community are warmly welcome! Whether you are reporting a bug, proposing a new diagram type, or improving documentation, your support is appreciated.

How to Contribute

1. Fork the Repository on GitHub: https://github.com/Dragonwinner/markdown-pdf-exporter
2. Clone your fork locally:

   git clone https://github.com/Dragonwinner/markdown-pdf-exporter.git
   cd markdown-pdf-exporter


3. Create a descriptive feature branch:

   git checkout -b feature/your-feature-name
   # or
   git checkout -b fix/issue-description


4. Make your changes and verify the build:

   npm run check    # Verifies TypeScript types
   npm run compile  # Bundles extension and webview runtimes


5. Commit your changes following the Conventional Commits format:

   git commit -m "feat(mermaid): add quadrant chart high-dpi scaling support"


6. Push to your fork and submit a Pull Request targeting the main branch.

For detailed guidelines, code style, and security rules, please refer to our full CONTRIBUTING.md.

📄 License & Author

Distributed under the MIT License. See LICENSE for full license text.
