CodeRefactor

CodeRefactor brings your local commit-review and refactor loop into VS Code.

What It Does

• Watches commit-level review updates from refactor watch --json.
• Shows commit status in a dedicated CodeRefactor sidebar (Commits view).

Commit timeline (Commits view)

The Commits view renders your reviewed commits as a colored, Graphite-style lane graph — the base (main/master) branch on lane 0, and each refactor branch on its own colored lane, with resolved-request rows nested underneath the finalize commit that produced them. A legend at the top maps each color to its branch (and how many requests it applied).

Each commit card is a navigation/status surface — click it to open its requests in the Requests panel. Phase-scoped actions live on the card:

• Latest commit: a Fresh Review (↻) button re-reviews the commit from scratch (discards its current requests) — runs headlessly.
• Finalize commits: Merge, Drop, Diff, Back to Review.
• Resolved-request rows: Revert.

Merge/Drop and Fresh Review run headlessly (no terminal) with an in-editor confirmation, streaming output to the CodeRefactor output channel. In review-only (local_heuristic) mode the apply/merge/drop/revert buttons are hidden.

When your working tree has uncommitted changes and the project is fully set up, an Uncommitted changes node appears at the tip of the trunk with a Commit… button — commit locally (git add -A && git commit -m …) without leaving the panel. The resulting commit is reviewed automatically via the post-commit hook.

Request cards (Requests view)

Click a commit to open its Refactor Request cards in the Requests panel — a click-first detail surface (no terminal, no prompts):

• Each card shows a severity dot, location, request id, rationale, recommendation, and the proposed diff.
• Refactor / Reject apply or skip a single request headlessly; Revert undoes an applied one; Apply all processes each request in turn.
• Actions stream their output into the card and refresh its status on completion.
• In review-only (local_heuristic) mode the apply/revert buttons are hidden.

Onboarding (initialize git, refactor init, login, install hook) and switching the execution mode can all be done headlessly from the panel — the terminal refactor flow is unchanged and can still be used directly.

Requirements

• refactor CLI installed and available on PATH (pipx install is supported).
• Open workspace must be a git repository.
• Run refactor login once.
• Install hook once with refactor hook install.

Install

• VS Code — from the Visual Studio Marketplace (search "CodeRefactor").
• Cursor / VSCodium / other OpenVSX-based editors — from Open VSX (search "CodeRefactor").

Local VSIX (private / pre-release)

cd vscode-extension
npm install
npm run package

Then in your editor:

1. Open Extensions
2. ... menu -> Install from VSIX...
3. Select the generated .vsix
4. Reload window

First Run

1. Open command palette -> CodeRefactor: Check Status
2. Open the CodeRefactor activity view
3. Make a commit in your repo
4. Watch the commit appear and update in the Commits panel

Configuration

• refactorai.cliPath: path to refactor executable (default: refactor).
• refactorai.autoOpen: auto-focus CodeRefactor panel when new commit arrives.
• refactorai.historyLimit: commit history depth for initial stream load.

Troubleshooting

• CLI not found: set refactorai.cliPath (common GUI PATH issue).
• Not authenticated: run refactor login.
• No commit events: run refactor hook install.
• No panel updates: use the panel Refresh button or reload window.
