BPM Remote Toolkit

The extension creates packages with the extension .gz and installs them in the target environment.

Features

• Create and install packages in the target environment.
• Support for Creatio and BPMSoft platforms.
• Manage sequential deployment of multiple packages.
• Automatically update metadata when saving files.

How it works

1. Set up your .code-workspace file:
   • Set the path property to the path of custom packages, e.g., ..\Terrasoft.WebApp\Terrasoft.Configuration\Pkg.
   • Add environments.
2. Log in to each environment in the Bpm Environments view.
3. Open your .code-workspace file in Visual Studio Code and add folders from File Explorer to Packages Explorer by right-clicking on the folder and selecting Add Folder To Packages Explorer.
4. In Package Explorer, you can:
   • Create a selected package.
   • Create and upload a selected package.
   • Add packages for deployment (supports multiselect).
5. Use Package Deployment Management for sequential deployment of multiple packages.

Requirements

For Creatio

Install clio before using the extension:

dotnet tool install clio -g

Command Line Interface clio is the utility for integrating the Creatio platform with development and CI/CD tools.

For BPMSoft

Download Utilities Of BPMSoft and register this utility before using the extension:

• Run the ubs.exe application as an administrator in the folder where the archive was unzipped.
• In the console window, type register, press Enter, then Enter again to close the console.

Extension Settings

This extension contributes the following settings:

• bpmtoolkit.general.utility: Select utility: clio (for Creatio), ubs (for BPMSoft), or auto (for automatic detection of the utility based on the path).
• bpmtoolkit.general.autoUpdateTime: Automatically updates the ModifiedOnUtc field in the Descriptor.json file when saving .cs or .js files.
• bpmtoolkit.general.packToZip: If enabled, the .gz file is also compressed into a .zip file.

Settings For .code-workspace file

• id: Identifier of the web application.
• url: Web application URL address.
• isNetCore: Target platform (true for .NET Core, false for .NET Framework).
• gitBranchName: Name of the branch associated with the target environment.
• isEnable: Availability of actions in view area Bpm Environments.
• postRunCommand: Command to be executed in the terminal after deploying packages to the target environment. This can be used for additional actions, such as running custom scripts.

For example:

{
	"folders": [
		{
			"path": "..\\Terrasoft.WebApp\\Terrasoft.Configuration\\Pkg"
		}
	],
	"settings": {
		"bpmtoolkit": {
			"environments": [
				{
					"id": "test",
					"url": "https://test.contoso.com",
					"isNetCore": false,
					"gitBranchName": "test",
					"isEnable": true
				},
				{
					"id": "preprod",
					"url": "https://preprod.contoso.com",
					"isNetCore": false,
					"gitBranchName": "preprod",
					"isEnable": true
				},
				{
					"id": "prod",
					"url": "https://prod.contoso.com",
					"isNetCore": false,
					"gitBranchName": "master",
					"isEnable": false
				}
			]
		}
	}
}

You need to set up the .code-workspace file to display items in the Bpm Environments view.

Known Issues

• If the Package Deployment Management view is empty, drag-and-drop from Package Explorer to Package Deployment Management does not work. Ensure that packages are added to Package Explorer.

Release Notes

1.8.x

• Updated README.
• Added the Package Deployment Management view in Source Control.
• Minor corrections and improvements.
