LabelEditor for VSCode

Annotate images directly in VS Code — polygon, rectangle, line, point, and SAM AI-assisted masks — and save in the LabelMe JSON format used by most ML pipelines, or work natively in YOLO format (open a data.yaml, edit, save .txt). No extra app, no context switch.

✨ Features

Annotation Tools

• Shape types: polygon, rectangle, line, point, and circle — all saved in LabelMe JSON (circle as center + edge points)
• Drawing modes: 👁️ View (browse/select, default) · ⬠ Polygon · ▭ Rectangle · ⟋ Line · • Point · ◯ Circle
• Unified edit mode: click a shape to move it or drag its vertices; circle handles translate (center) or resize (edge)
• Context menu: right-click any shape to Edit, Rename, Hide, or Delete
• Labels & descriptions: assign and edit a label per region, plus an optional description shown in the sidebar (omitted from JSON when empty)
• Undo / redo with up to 50 history states

Selecting & Editing Instances

• Smart overlap selection: clicking overlapping instances picks the smallest / most specific one (points and lines before filled shapes); click again in place to cycle down the stack with an N / M badge; hovering shows a dashed outline of what a click would select
• Multi-select: Ctrl+Click to toggle (canvas or list), Shift+Click to range-select in the list, Ctrl+A for all, drag a box in View mode (Ctrl+Drag to add)
• Clear selection: press Esc, or click empty space — on the canvas, or the blank area of the Labels / Instances panels
• Batch operations: Rename, Hide/Show, or Delete the whole selection from the context menu or sidebar
• Eraser: Shift+Click for a polygon eraser, Shift+Long-press+Drag for a rectangle eraser — boolean-subtracts the area from all overlapping shapes (interior cut-outs become hole-free polygons); right-click / Esc to cancel
• Merge (Ctrl+G): union multi-selected overlapping polygons/rectangles (all-rectangles → bounding box; otherwise → polygon); a single undo restores the originals
• Draw Over Instances (opt-in): when on, clicking inside an existing instance in a drawing mode starts a new annotation instead of selecting it; right-click still selects/deletes
• Per-instance visibility toggle, in-place label editing, and delete

AI-Assisted Annotation (SAM)

• Interactive segmentation with the Segment Anything Model — enter via the ✨ button or I
  • Left click positive prompt · Shift+Left click negative · Left-drag box prompt · Right click undo last · Double click confirm
  • Point and box prompts combine (a new box replaces the previous one); real-time mask preview
• Encode mode: Full Image (default) or Local Crop — Local Crop encodes only the zoomed viewport for far better accuracy on small targets (encoded region shown as a yellow dashed box)
• Encode source: Original file (default) or Adjusted View — encodes with Brightness/Contrast/CLAHE/Channel baked in, useful for low-contrast / medical / microscopy data
• Output shape: Polygon (default) or Rectangle (mask reduced to its bounding box, with a WYSIWYG preview)
• Supports SAM1 & SAM2 ONNX models (auto-detected); runs as a standalone Python HTTP server in a VS Code terminal and works over Remote-SSH
• Requires Python with onnxruntime, opencv-python, numpy

SAM model setup

1. Download SAM2 ONNX models from HuggingFace
2. Put the encoder and decoder .onnx files in one folder (filenames containing "encoder"/"decoder"; otherwise the larger file is assumed to be the encoder)
3. Press I to enter SAM mode; if the service isn't running, a config modal lets you pick the model folder and Python interpreter and starts it in a terminal tab

ONNX Batch Inference

• Tools menu → ONNX Batch Infer: run an ONNX segmentation model across all images or just the current one
• Configurable model directory, Python interpreter, CPU/GPU, and RGB/BGR; existing annotations can skip / merge / overwrite; progress shown in the terminal
• Requires Python with onnxruntime, opencv-python, numpy, tqdm (outputs LabelMe polygons, or YOLO .txt when launched from a YOLO dataset)

YOLO Format Mode

• Work directly in YOLO format — right-click a YOLO data.yaml → "LabelEditor: Open as YOLO Dataset"
• Resolves the dataset's path + train / val / test image directories and imports existing .txt labels (Ultralytics images/ → labels/ convention); detection lines (cls cx cy w h) load as rectangles, segmentation lines as polygons
• Edits save back as .txt, choosing bbox vs segmentation per shape automatically (one file may mix both)
• Drawing is scoped to 👁️ View · ✨ SAM · ⬠ Polygon · ▭ Rectangle
• Label dialog matches LabelMe mode: it shows the current image's labels and your history (not the full data.yaml class list); entering a class that isn't in the yaml prompts to add it, appended at the next index and written straight back to data.yaml (its list / dict / block-sequence style is preserved, nc is bumped)

Image Browser & Navigation

• Sidebar image list: every workspace image organized by folder, click to jump, current image highlighted, resizable — virtual scrolling handles 8000+ images smoothly; symbolic links to images and folders are followed (with cycle protection)
• Quick search: filter the list by filename as you type
• Advanced search: the sliders button in the search box opens a condition builder — add Name (substring), Name (regex), and Class (multi-select via a searchable, scrollable picker) conditions; conditions AND together while multiple classes in one condition OR. Results keep the image browser's natural order — filtering only narrows the list, it never reorders it — shown with a clearable banner. Name/regex search reads no annotation files; class search indexes sidecar JSON once (cached, with progress and cancel), so it stays fast on large datasets
• Open Folder for Annotation: right-click a folder to work with just its images
• Multi-panel: open several images/folders side-by-side; re-opening the same one reveals its existing panel
• Zoom & pan with mouse-centered pivot; prev/next buttons and A / D (navigation stays within the active filter's results)
• Copy image path: click the filename to copy the absolute path, right-click for the name only
• Manual save (Ctrl+S) with an unsaved-changes warning on navigation

Display & Image Adjustment

• Theme: ☀️ Light / 🌙 Dark / ◐ Auto (follows VS Code)
• Brightness & Contrast sliders and RGB channel isolation (view R/G/B as grayscale), each with reset and a lock that preserves the value across images
• CLAHE: brighten low-contrast images without color distortion (luminance-only), with a clip-limit slider
• On-canvas class names (opt-in): draw each instance's label as a colour-matched pill at its corner, readable at any zoom
• Image info popup (dimensions, file size, DPI, bit depth); border width (1–5px) and fill opacity (0–100%) controls
• All adjustments affect display only — never the original file

Dataset Export — COCO / YOLO

• Tools menu → Export Dataset: COCO Instances or YOLO, over all images or the current one
• YOLO exports a ready-to-train Ultralytics dataset (data.yaml + images/train/ + labels/train/), auto-selecting bbox vs segmentation per shape; COCO writes annotations.json
• Copy images option: bundle the images into the dataset for a self-contained copy, or leave them out (the folder structure is still created)
• Classes reflect the current dataset (the YOLO class order comes from its data.yaml); reorder / rename / remove rows to control class indices (first row = 0 for YOLO, 1 for COCO)
• Output directory defaults to <dataset>/export and is chosen (or created) via a save dialog; a run that writes zero annotations warns (likely a class-name mismatch) instead of silently "succeeding"; filename collisions across nested folders are auto-suffixed

SVG Export

• Tools menu → Export SVG: write annotation outlines as SVG — the current image or all annotated images — into a folder you choose
• The output-folder picker lets you select an existing folder or type/create a new one (missing folders are created); all-images mode writes one .svg per annotated image, mirroring the source's subfolders

Labels Panel

• All label categories with live instance counts; show/hide every instance of a label at once
• Click a label to select all its instances (Ctrl/Cmd-click adds the group to the current selection, or toggles it off); the row stays highlighted while every instance is selected
• 24 preset colors + custom hex, with per-label reset; colors persist globally

Workspace & UX

• Rebindable keyboard shortcuts (Settings → Keyboard Shortcuts) with conflict detection and per-row / global reset; Ctrl+Y and Backspace stay as secondary Redo / Delete
• Multi-language: English / 简体中文 (Settings → Language) — strings live in media/i18n.js, PRs for more locales welcome
• In-webview notifications: status messages appear inline in the toolbar (severity-colored) instead of stacking as native popups; native dialogs are reserved for Save / Discard / Cancel prompts
• Rich hover tooltips on every control (title, description, and the live keyboard shortcut)
• macOS-style UI: SVG icons, blur-backdrop modals, click-outside-dismiss menus, and segmented controls
• All settings persist globally across sessions

📦 Installation

From OpenVSX

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "LabelEditor for VSCode"
4. Click Install

From Source

1. Clone this repository
2. Run npm install
3. Run npm run compile
4. Press F5 to open Extension Development Host

🚀 Usage

Basic Workflow

1. Right-click any image file (.jpg, .jpeg, .png, .bmp) in the Explorer
2. Select "LabelEditor: Open Image Annotator"
3. Or right-click a folder and select "LabelEditor: Open Folder for Annotation" to work only with images in that folder
4. Switch to Polygon Mode (⬠) or Rectangle Mode (▭) as needed
5. For polygons: Click to add vertices, click near the first point to close
6. For rectangles: Click to set start point, move and click to set end point
7. Enter a label name
8. Save with Ctrl+S

YOLO Dataset Workflow

1. Right-click a YOLO data.yaml in the Explorer
2. Select "LabelEditor: Open as YOLO Dataset"
3. Existing .txt labels load automatically (boxes and polygons); annotate with Polygon / Rectangle / SAM
4. Pick a recent/current label or type a class name; a class not yet in data.yaml prompts to add it
5. Save with Ctrl+S — labels are written back as YOLO .txt

Labels Management

• Click a label name to select all of its instances (Ctrl/Cmd-click to add the group to the current selection)
• Click the color indicator to customize label colors
• Click eye icon to toggle visibility for all instances of a label
• Click reset icon (↻) to restore default color

Advanced Options

• Click the ⚙️ icon to open advanced settings
• Choose theme: Light (☀️), Dark (🌙), or Auto (◐)
• Adjust brightness and contrast with sliders (display only, lock to preserve across images)
• Adjust border width and fill opacity with sliders
• Click ↺ on any setting to reset to default

Keyboard Shortcuts

• Left Click: Add point / Select shape
• Right Click: Undo last point while drawing
• Ctrl+Wheel: Zoom in/out
• V: Switch to View Mode
• P: Switch to Polygon Mode
• R: Switch to Rectangle Mode
• L: Switch to Line Mode
• O: Switch to Point Mode
• C: Switch to Circle Mode (New in v1.0.0)
• I: Switch to SAM AI Mode
• Ctrl+Z (Cmd+Z on Mac): Undo last action
• Ctrl+Shift+Z or Ctrl+Y: Redo action
• Shift+Click: Start polygon eraser
• Shift+Long-press+Drag: Start rectangle eraser
• Ctrl+A (Cmd+A on Mac): Select all instances
• Ctrl+G (New in v0.15.0): Merge selected polygon/rectangle instances (overlapping ones only)
• Ctrl+R (New in v0.15.0): Rename the selected shape (single or batch)
• Ctrl+H (New in v0.15.0): Toggle visibility of the selected shape(s)
• ESC: Cancel current drawing / Cancel eraser / Clear selection
• A: Previous image
• D: Next image
• Ctrl+S (Cmd+S on Mac): Save annotations
• Delete/Backspace: Delete selected shape
• Ctrl+D (in label modal, New in v0.14.1): Reveal chip shortcut badges, then press a digit (1-9, or 0 for the 10th) to commit that label

Toolbar Buttons

• ◀ / ▶: Navigate between images
• 👁️ / ⬠ / ▭ / ⟋ / • / ✨: Switch between View, Polygon, Rectangle, Line, Point, and SAM modes
• ⚙️: Open advanced rendering options
• Save: Save current annotations

📄 Output Format

Annotations are saved in LabelMe JSON format:

```json { "version": "5.0.1", "flags": {}, "shapes": [ { "label": "person", "points": [[x1, y1], [x2, y2], ...], "group_id": null, "shape_type": "polygon", "flags": {}, "description": "optional annotation note" } ], "imagePath": "image.jpg", "imageData": null, "imageHeight": 1080, "imageWidth": 1920 } ```

Note: visible property is not saved to JSON - it's a session-only UI state. description is only included when non-empty.

🛠️ Known Limitations

This extension is still under active development. Some known limitations include:

• No support for ellipse shape type yet (Circle is shipped — points: [[cx, cy], [edgeX, edgeY]], LabelMe-compatible)
• No import from other formats (export to COCO and YOLO is supported via the Tools menu)
• Performance may degrade with very large images (10000x10000+)
• No support for video frame annotation
• SAM mode requires a local Python environment with ONNX Runtime

🤖 Development

Most code in this extension was written by AI:

• Gemini 3 Pro
• Gemini 3.1 Pro
• Claude Sonnet 4.5
• Claude Opus 4.5
• Claude Opus 4.6
• Claude Opus 4.7 (1M context)
• Claude Opus 4.8 (1M context)

Code review by AI:

• GPT 5.3 Codex
• GPT 5.4

Community PRs are also welcome — see CHANGELOG for per-release contributor credit.

This project serves as a demonstration of AI-assisted development capabilities.

📝 Roadmap

Planned features for future releases:

• [x] ~~Undo/Redo support~~ Added in v0.2.0
• [x] ~~Performance optimizations~~ Added in v0.2.0
• [x] ~~Labels management panel~~ Added in v0.3.0
• [x] ~~Custom label colors~~ Added in v0.3.0
• [x] ~~View/Edit mode toggle~~ Added in v0.3.0
• [x] ~~Advanced rendering options~~ Added in v0.3.0
• [x] ~~Rectangle shapes~~ Added in v0.4.0
• [x] ~~Global settings persistence~~ Added in v0.6.0
• [x] ~~Image Browser with virtual scrolling~~ Added in v0.7.0
• [x] ~~Theme switching (Light/Dark/Auto)~~ Added in v0.8.0
• [x] ~~Refresh image list button~~ Added in v0.9.0
• [x] ~~Open folder for annotation~~ Added in v0.9.0
• [x] ~~Click to copy image path~~ Added in v0.9.0
• [x] ~~Point annotations~~ Added in v0.9.2
• [x] ~~Line (polyline) annotations~~ Added in v0.9.2
• [x] ~~Unified Edit Mode~~ Added in v0.10.0
• [x] ~~Context Menu (Rename/Hide/Delete)~~ Added in v0.10.0
• [x] ~~SVG Export~~ Added in v0.11.0
• [x] ~~Instance Description~~ Added in v0.11.1
• [x] ~~ONNX Batch Inference~~ Added in v0.11.2
• [x] ~~SAM AI Annotation~~ Added in v0.12.0
• [x] ~~Circle shapes~~ Added in v1.0.0
• [x] ~~Export to other formats (COCO, YOLO, etc.)~~ Added in v1.0.0
• [x] ~~Image display adjust (brightness, contrast)~~ Added in v0.13.4
• [x] ~~Keyboard shortcuts customization~~ Added in v1.0.0
• [x] ~~Multi-language support~~ Added in v1.0.0
• [x] ~~Advanced search (filename / regex / class, ranked)~~ Added in v1.3.0

🤝 Contributing

Contributions are welcome! Please feel free to submit issues or pull requests.

📜 License

MIT License - see LICENSE file for details

🙏 Acknowledgments

• Inspired by the LabelMe annotation tool
• Built for the VS Code extension ecosystem
• Developed primarily by AI language models, with feature contributions from the community — see "Development" above

Enjoy annotating! 🎨
