OpenCode VS Code Extension

A VS Code extension that wraps the OpenCode AI coding assistant in a rich, IDE-native experience — with implementation planning, real-time streaming, subagent orchestration, quota monitoring, and a full-featured React chat panel.

[!IMPORTANT] Disclaimer: This extension is an independent personal project and is not affiliated with, endorsed by, or maintained by OpenCode or its creators.

[!NOTE] Marketplace publishing, releases, and support for this extension are managed by the project author (chryzxc) only.

Screenshots & GIFs

This repository is public, so relative image links from ./assets/ render correctly on GitHub and are suitable for Marketplace publishing.

Demo GIF

OpenCode demo

Conversation View

Conversation view 1 Conversation view 2 Conversation view 3

Extended Panels

Extended panel 1 Extended panel 2

Quota + Questions

Quota popover Interactive questions

Overview
Features
Screenshots & GIFs
Architecture
Prerequisites
Installation
Development
Usage
Keyboard Shortcuts
Configuration
Project Structure
Core Services
Webview (React UI)
Logging
Testing
Contributing

Overview

This extension provides a VS Code-native UI on top of the OpenCode runtime. It communicates with the local OpenCode server over HTTP using the @opencode-ai/sdk, streams events in real time via SSE, and renders everything in a React-based webview with Tailwind CSS styling.

[!IMPORTANT] This repository is a personal integration project. It is not an official OpenCode client.

Key differentiators over a plain terminal OpenCode workflow:

Implementation Plan workflow — AI generates a structured implementation_plan.md before touching any code; plans are parsed and rendered interactively
Subagent orchestration UI — background tasks are tracked, rendered inline as cards, and inspectable in a detail modal
Per-session quota & budget monitoring — tracks token consumption and daily budget across OpenAI, GitHub Copilot, Google Gemini, Zhipu, and other providers
Extended right panel — live MCP server status, LSP server status, installed skills, and agent roster always visible on wide screens

Features

AI Chat

Full streaming chat with real-time token counting (prompt / response / reasoning / cache read-write)
Markdown rendering with syntax highlighting via highlight.js
Thinking/reasoning bubble display with collapsible sections
Copy message content to clipboard
Image attachments and inline image preview modal
Contiguous message grouping for visual clarity
Unified error display with specific error messages from the API:
- API Errors (Red): Raw errors from API responses (e.g., "Token refresh failed: 401")
- Timeout Errors (Orange): Request timeout messages with retry option
- Structured Output Errors (Blue): Model compatibility issues
- All errors include appropriate icons and actionable retry buttons

Implementation Planning

Switch to Plan agent to generate an implementation_plan.md before any code changes
"View Implementation Plan" button appears on every AI response that generated a plan
Dedicated plan viewer (PlanViewProvider) with interactive checklist tracking
Plan can be commented on, revised, and then executed
Interactive plan editing workflow inspired by Antigravity-style planning loops (review -> revise -> proceed)

Agents & Skills

Agent selector (Build, Plan, and any plugin agents registered via app.agents())
Per-message agent name badge with the agent's configured color
Skills (/command) panel in the right sidebar listing all slash-command skills from the server

Subagent Orchestration

Background tasks ("subagents") are tracked via SubagentTracker
Active task panel with live status dots and step progress
Expandable subagent detail modal with full timeline, thinking events, and tool calls
Subagent cards rendered inline inside assistant messages
Dedicated subagent UI for monitoring parallel task execution and detailed per-subagent inspection

Interactive Q&A Flow

Supports interactive question/answer exchanges inside the chat timeline
Handles multiple interaction types (question, quick actions, confirm) with inline response controls
Preserves interactive context across session hydration/reload

Session Management

Persistent chat history across VS Code restarts (stored in globalState)
Session list sidebar with rename, delete, and fork support
Session compaction support (large histories are summarized server-side)
VCS diff review panel (DiffReviewProvider) — inspects changes made in a session

Quota & Budget Monitoring

Real-time quota data fetched from provider APIs (OpenAI, Copilot, Gemini, Zhipu, ZAI)
QuotaMonitor panel in the right sidebar with usage bars and projected monthly consumption
RequestBudgeter calculates a daily request allowance to last the full billing month
Configurable warning thresholds and optional hard enforcement
Live quota status monitor for rapid provider/account health checks while working

Plugin Ecosystem Support

Works with OpenCode plugin-driven workflows (including community plugin collections like Oh My OpenCode)
Surfaces plugin-provided agents, skills, and capabilities directly in the extension UI

Extended Right Panel (Desktop ≥ 1100 px)

Active Task Panel — current subagent progress
Quota Monitor — provider quota and budget
Todo Panel — session-scoped todo items surfaced from AI
MCP Servers — live status of all Model Context Protocol servers with per-server tool lists
LSP Servers — Language Server Protocol status
Skills — slash-command catalog from client.command.list()
Agents — all agents from client.app.agents() with mode badge, color dot, and description

Streaming & Reliability

Fetch-based SSE client (not EventSource) for full header control
Auto-reconnect with 5-second back-off on connection loss
AbortController cancellation on stop/new session
Stop Request button to interrupt any in-flight AI response

Architecture

┌─────────────────────────────────────────────────────────────┐
│                    VS Code Extension Host                    │
│                                                             │
│  extension.ts                                               │
│    ├── OpencodeServerManager  (manages local OpenCode server)│
│    ├── SessionService         (persistence + sync)          │
│    ├── StatusBarProvider      (connection indicator)        │
│    ├── ChatViewProvider       (main webview host)           │
│    ├── PlanViewProvider       (implementation plan viewer)  │
│    └── DiffReviewProvider     (VCS diff panel)              │
│                                                             │
│  Services                                                   │
│    ├── MessageStreamService   (SSE event streaming)         │
│    ├── SubagentTracker        (background task tracking)    │
│    ├── QuotaService           (provider quota polling)      │
│    ├── RequestBudgeter        (daily budget calculation)    │
│    ├── PlanParser             (implementation_plan.md)      │
│    └── GeminiTokenUsageTracker                              │
└────────────────────┬────────────────────────────────────────┘
                     │  HTTP + SSE via @opencode-ai/sdk
                     │  (port: auto-assigned or configured)
┌────────────────────▼────────────────────────────────────────┐
│                    OpenCode Local Server                     │
│                (accessed via `@opencode-ai/sdk`)            │
│                                                             │
│  REST API                                                   │
│    GET  /agent         — list agents                        │
│    GET  /command       — list slash-command skills          │
│    GET  /mcp           — MCP server status                  │
│    GET  /lsp/status    — LSP server status                  │
│    GET  /event         — SSE event stream                   │
│    POST /session/:id/prompt — send message                  │
│    ...and many more session, file, tool, VCS endpoints      │
└─────────────────────────────────────────────────────────────┘
                     │
┌────────────────────▼────────────────────────────────────────┐
│                   Webview (React + Tailwind)                 │
│                   webview/shared/dist/chat.js               │
│                                                             │
│  ChatShell.tsx           — layout container                 │
│  MessageComponents.tsx   — user + assistant messages        │
│  PanelComponents.tsx     — all sidebar panels               │
│  StreamingComponents.tsx — live streaming card              │
│  BudgetIndicator.tsx     — inline budget banner             │
│  SubagentDetailModal.tsx — subagent inspection modal        │
└─────────────────────────────────────────────────────────────┘

Data flow:

User types in the chat input → vscode.postMessage({ type: "sendPrompt", ... })
ChatViewProvider receives the message, calls client.session.prompt()
MessageStreamService streams SSE events from the server
Events are forwarded to the webview as postMessage calls
messageHandler.ts in the webview dispatches them into the React reducer
Components re-render reactively

Prerequisites

Node.js ≥ 18
VS Code ≥ 1.85.0
OpenCode installed on your device (required runtime):
```
npm install -g opencode
```
Configure at least one AI provider in OpenCode:
```
opencode
/connect
```

Installation

From Source

# Clone the repository
git clone https://github.com/your-org/vscode-opencode.git
cd vscode-opencode

# Install root dependencies
npm install

# Build the webview and extension
npm run build

Then press F5 in VS Code to launch an Extension Development Host.

Packaging (.vsix)

npm install -g @vscode/vsce
vsce package

This produces opencode-vscode-<version>.vsix, installable via Extensions → Install from VSIX.

Development

# Start both the extension compiler and webview bundler in watch mode
npm run watch                  # extension TypeScript (esbuild)
npm run webview:watch          # React webview (in a second terminal)

After making changes:

Extension code (src/): esbuild recompiles automatically; reload the Extension Host with Ctrl+R / Cmd+R inside the host window, or run the "Developer: Reload Window" command.
Webview code (webview/shared/src/): Vite/esbuild rebuilds automatically; reload the webview by running opencode.focus again or reloading the window.

Structured Output Contract Sync

The JSON schema for structured AI responses is shared between the backend and webview. Keep it in sync whenever you modify it:

npm run structured-output:sync   # write to webview/shared/src/chat/lib/generated/
npm run structured-output:check  # verify the generated file is up to date (CI)

Usage

Opening the Chat Panel

Action	Shortcut
Focus / open chat	`Ctrl+Esc` / `Cmd+Esc`
New session	`Ctrl+Shift+Esc` / `Cmd+Shift+Esc`
Send selected code	`Ctrl+L` / `Cmd+L`
Insert file reference	`Ctrl+Alt+K` / `Cmd+Alt+K`

You can also open the panel from the Activity Bar (the OpenCode icon) or via the Command Palette (Ctrl+Shift+P → OpenCode: Focus Chat).

Sending a Message

Type your prompt in the text area and press Enter (or Shift+Enter for a newline). You can:

Attach images — paste or drag images directly into the input
Reference files — press Ctrl+Alt+K to pick a file; it's inserted as @path/to/file
Use slash commands — type / to see available skills from the server (e.g. /build, /plan)
Select an agent — use the agent dropdown to switch between Build, Plan, and any custom agents

Plan Mode

Select the Plan agent from the agent dropdown
Describe the feature or change you want
OpenCode generates an implementation_plan.md
Click View Implementation Plan on the response to open the plan viewer
Review sections, add comments, check off steps
Click Proceed (or switch to the Build agent) to execute

Managing Sessions

Click the History icon in the chat header to open the sessions sidebar
Sessions are listed with title, date, and token count
Right-click (or use the ⋯ menu) to rename, delete, or fork a session

Stopping a Response

Click the Stop button (square icon) in the chat header at any time to abort the current AI request.

Keyboard Shortcuts

Command	Windows / Linux	macOS
Focus chat	`Ctrl+Esc`	`Cmd+Esc`
New session	`Ctrl+Shift+Esc`	`Cmd+Shift+Esc`
Send selection	`Ctrl+L`	`Cmd+L`
Insert file reference	`Ctrl+Alt+K`	`Cmd+Alt+K`

All shortcuts can be rebound via File → Preferences → Keyboard Shortcuts.

Configuration

Access via File → Preferences → Settings → OpenCode or add to settings.json:

Server

Setting	Type	Default	Description
`opencode.serverPort`	`number`	`0`	Port for the OpenCode server. `0` = auto-assign a free port.
`opencode.autoStart`	`boolean`	`true`	Start the server automatically when the extension activates.
`opencode.persistSessions`	`boolean`	`true`	Persist chat sessions across VS Code restarts.

Logging

Setting	Type	Default	Description
`opencode.logging.level`	`string`	`"info"`	Minimum log level: `error`, `warn`, `info`, `debug`.
`opencode.logging.enableConsole`	`boolean`	`true`	Write logs to the VS Code Output channel.
`opencode.logging.enableFile`	`boolean`	`false`	Write logs to a rotating file on disk.
`opencode.logging.maxFileSize`	`number`	`5242880`	Max log file size in bytes before rotation (5 MB default).
`opencode.logging.maxFiles`	`number`	`3`	Number of backup log files to keep.

Example `settings.json`

{
  "opencode.serverPort": 0,
  "opencode.autoStart": true,
  "opencode.persistSessions": true,
  "opencode.logging.level": "debug",
  "opencode.logging.enableFile": true
}

Project Structure

vscode-opencode/
├── src/                          # Extension host TypeScript source
│   ├── extension.ts              # Activation entry point, command registration
│   ├── providers/
│   │   ├── ChatViewProvider.ts   # Main webview host, message routing
│   │   ├── DiffReviewProvider.ts # VCS diff review panel
│   │   ├── PlanViewProvider.ts   # Implementation plan viewer
│   │   └── StatusBarProvider.ts  # Status bar connection indicator
│   ├── services/
│   │   ├── OpencodeServerManager.ts    # OpenCode server lifecycle management
│   │   ├── SessionService.ts           # Session persistence and sync
│   │   ├── MessageStreamService.ts     # SSE event streaming
│   │   ├── SubagentTracker.ts          # Background task tracking
│   │   ├── QuotaService.ts             # Provider quota polling
│   │   ├── RequestBudgeter.ts          # Daily budget calculation
│   │   ├── PlanParser.ts               # implementation_plan.md parser
│   │   └── GeminiTokenUsageTracker.ts  # Gemini-specific token tracking
│   ├── shared/                   # Types and utilities shared by providers
│   ├── types/                    # TypeScript type definitions
│   └── utils/
│       └── Logger.ts             # Structured logging utility
├── webview/
│   └── shared/
│       ├── src/
│       │   ├── chat/
│       │   │   ├── ChatShell.tsx          # Layout container
│       │   │   ├── MessageComponents.tsx  # User + assistant message rendering
│       │   │   ├── PanelComponents.tsx    # All right-panel sections
│       │   │   ├── StreamingComponents.tsx
│       │   │   ├── BudgetIndicator.tsx
│       │   │   ├── SubagentDetailModal.tsx
│       │   │   ├── ImagePreviewModal.tsx
│       │   │   └── lib/
│       │   │       ├── store.ts           # React reducer + context
│       │   │       ├── types.ts           # All shared TypeScript types
│       │   │       ├── messageHandler.ts  # Processes extension → webview messages
│       │   │       ├── structuredOutputValidator.ts
│       │   │       └── generated/        # Auto-generated from structured output contract
│       │   ├── plan/                      # Plan viewer webview
│       │   ├── diff-review/               # Diff review webview
│       │   └── components/ui/             # Shared UI primitives (Button, Badge, etc.)
│       └── dist/                          # Built assets (chat.js, chat.css)
├── scripts/
│   ├── sync-structured-output-contract.mjs
│   └── patch-timeline.js
├── tests/                         # Node test runner (.mjs) test suite
├── resources/                     # Extension icons and static assets
├── AGENTS.md                      # Agent contribution rules (for AI agents)
├── LOGGING.md                     # Logging system documentation
├── package.json
├── tsconfig.json
└── esbuild.config.js

Core Services

`OpencodeServerManager`

Starts and manages the local OpenCode server process. Handles:

Dynamic port allocation (default start: 4097)
Server readiness detection (stdout scan for "Server running" / "listening")
Cross-platform process cleanup (Unix SIGKILL vs Windows taskkill /T /F)
Automatic reconnection with 5-second back-off after unexpected exit
Emits status events consumed by StatusBarProvider and ChatViewProvider

`MessageStreamService`

Custom fetch-based SSE client connecting to GET /event. Features:

Manual SSE line parsing with chunk-boundary buffering
AbortController-based cancellation
Subscriber count management (starts/stops connection automatically)
5-second auto-reconnect when connection drops with active subscribers

`SessionService`

Persists sessions between VS Code restarts using context.globalState. Syncs with the server on startup, reconciling any sessions created externally.

`SubagentTracker`

Parses SSE events for subagent.* event types, builds a tree of parent → child session relationships, and exposes SubagentSummary and SubagentDetail objects to ChatViewProvider for forwarding to the webview.

`QuotaService`

Polls provider-specific quota APIs on a configurable interval (default: 5 min):

OpenAI — chatgpt.com/backend-api/wham/usage
GitHub Copilot — api.github.com copilot billing endpoints
Google Gemini — cloudcode-pa.googleapis.com + OAuth token refresh
Zhipu / ZAI — bigmodel.cn and api.z.ai usage endpoints

`RequestBudgeter`

Calculates a daily request allowance based on monthlyQuota and days remaining in the billing cycle. Stores usage in a per-date JSON file under ~/.opencode/budget/. Provides ok / warning / critical warning levels and optional hard enforcement.

`PlanParser`

Regex-based parser for implementation_plan.md files. Extracts:

Goal (first heading)
Description text
File operations ([MODIFY], [CREATE], [DELETE] annotations)
Verification steps
Checklist items with completion state

Webview (React UI)

The webview is a standalone React application bundled by Vite/esbuild into webview/shared/dist/chat.js and chat.css. It uses a Redux-style reducer (store.ts) and communicates with the extension host exclusively through vscode.postMessage / window.addEventListener('message', ...).

State Management

AppState in types.ts holds all UI state:

Field	Type	Purpose
`messages`	`Message[]`	Full session message history
`streaming`	`StreamingState \\| null`	Live streaming card state
`availableAgents`	`Agent[]`	Agents from `client.app.agents()`
`availableCommands`	`SlashCommand[]`	Skills from `client.command.list()`
`mcpServers`	`McpServerInfo[]`	Live MCP server status
`lspServers`	`LspServerInfo[]`	Live LSP server status
`subagentsByParentMessageId`	`Record<…>`	Subagent summaries per message
`quotaData`	`QuotaData \\| null`	Provider quota details
`budgetInfo`	`BudgetInfo \\| null`	Daily budget calculations
`todoItems`	`TodoItem[]`	Session-scoped todos from AI
`sessionStats`	`SessionStats`	Token counts and duration

Message Protocol

The extension host and webview communicate through typed messages. Key types:

Direction	`type`	Payload
→ webview	`initState`	Full initial state on panel open
→ webview	`streamEvent`	SSE event chunk during AI response
→ webview	`mcpStatus`	`{ servers, toolIds }`
→ webview	`lspStatus`	`{ servers }`
→ webview	`agentsList`	`{ agents, selectedAgent }`
→ webview	`commandsList`	`{ commands }`
→ webview	`quotaData`	Provider quota payload
→ webview	`budgetInfo`	Daily budget payload
webview →	`sendPrompt`	`{ text, files, agent, model }`
webview →	`getMcpStatus`	—
webview →	`getLspStatus`	—
webview →	`getAgents`	—
webview →	`stopRequest`	—
webview →	`newSession`	—

Structured Output

AI responses use a JSON schema format instead of raw markdown when the server is asked for type: 'json_schema'. The responseType field routes the response to the correct renderer:

message — standard markdown text
implementation_plan — triggers plan detection and "View Implementation Plan" button
progress_update — subagent progress cards
question / interactive — clickable option buttons
error — error card

The contract is defined in scripts/sync-structured-output-contract.mjs and auto-generated into webview/shared/src/chat/lib/generated/ before every build.

Logging

The extension uses a comprehensive structured logging system with feature flow tracking, correlation IDs, and performance monitoring.

Key Features

Correlation IDs: Track multi-step operations from start to finish
Feature Flow Tracking: Monitor operations like "SendMessage" or "SwitchSession"
Performance Monitoring: Automatic warnings for operations taking >3 seconds
State Change Logging: Track state transitions with old/new values
UI Interaction Logging: Capture user actions for debugging
Log Analysis Tools: Query and analyze logs via CLI or API

Quick Start

# Enable file logging in settings.json
{
  "opencode.logging.enableFile": true,
  "opencode.logging.level": "info"
}

# Analyze logs
npm run analyze-logs:summary  # Generate a summary
npm run analyze-logs:flows    # Show all feature flows
npm run analyze-logs:errors   # Show errors only
npm run analyze-logs:perf     # Show performance issues

Log Format (JSON)

{
  "timestamp": "2026-04-02T14:30:00.000Z",
  "level": "info",
  "category": "CHAT_VIEW",
  "message": "Feature started: SendMessage",
  "context": {
    "correlationId": "CHAT_VIEW-1712051400000-abc123",
    "featureName": "SendMessage",
    "sessionId": "sess-456",
    "messageLength": 240
  }
}

Viewing Logs

Console: Open Output panel → select OpenCode from the dropdown.

File: Check logs/opencode.log in the extension storage (when enableFile: true).

Debugging with Correlation IDs

Each feature flow gets a unique correlation ID that ties all related logs together. Use the LogQuery utility's filterByCorrelationId() method for programmatic filtering, or the --correlation flag with the CLI tool—see LOGGING.md for details.

Performance Monitoring

Operations taking >3 seconds automatically log a warning:

{
  "level": "warn",
  "category": "QUEUE_MANAGER",
  "message": "Slow operation detected: executeQueue",
  "context": {
    "operation": "executeQueue",
    "duration": 3247
  }
}

See LOGGING.md for complete documentation including:

All logging methods and usage patterns
Feature flow tracking best practices
Log analysis CLI and API
Debugging tips and troubleshooting

Testing

Tests use Node's built-in test runner (.mjs files, no additional framework required):

# Run all tests
npm test

# Run a specific test file
node --test tests/plan-parser.test.mjs

The test suite covers:

Unit tests for services (plan parsing, structured output validation, quota logic, subagent tracking)
Integration tests for message streaming and session CRUD
Regression tests for UI contracts, streaming behaviour, MCP/LSP panels, and model dropdown

Regression Guardrails

Use the built-in guard scripts to catch regressions before push:

# one-time setup: activate repo-managed git hooks
npm run hooks:install

# run the same local pre-push guard manually
npm run guard:prepush

# run only impacted tests based on changed files
npm run test:impacted

What this enforces:

structured-output:check before tests
extension compile and lint checks
webview build check when webview files changed
impacted contract/regression suites (or full npm test on high-risk changes)

Contributing

Fork the repo and create a feature branch
Follow the rules in AGENTS.md — core features are protected
Run npm run structured-output:check before committing if you changed the output contract
Run npm test and ensure all tests pass
Open a pull request with a clear description of the change

Core Feature Protection

The following must never be silently removed or broken:

Token usage sticky header — real-time prompt/response/cache token counts
View Implementation Plan button — appears on any message that produced a plan
Stop Request button — aborts in-flight AI responses
React webview contract — <div id="root">, chat.js, and chat.css must be wired in getHtmlContent

License

MIT

Credits

Built on top of OpenCode by Anomaly.

OpenCode (VS Code Extension)

Christian Rey Villablanca

OpenCode VS Code Extension

Screenshots & GIFs

Demo GIF

Conversation View

Extended Panels

Quota + Questions

Table of Contents

Overview

Features

AI Chat

Implementation Planning

Agents & Skills

Subagent Orchestration

Interactive Q&A Flow

Session Management

Quota & Budget Monitoring

Plugin Ecosystem Support

Extended Right Panel (Desktop ≥ 1100 px)

Streaming & Reliability

Architecture

Prerequisites

Installation

From Source

Packaging (.vsix)

Development

Structured Output Contract Sync

Usage

Opening the Chat Panel

Sending a Message

Plan Mode

Managing Sessions

Stopping a Response

Keyboard Shortcuts

Configuration

Server

Logging

Example settings.json

Project Structure

Core Services

OpencodeServerManager

MessageStreamService

SessionService

SubagentTracker

QuotaService

RequestBudgeter

PlanParser

Webview (React UI)

State Management

Message Protocol

Structured Output

Logging

Key Features

Quick Start

Log Format (JSON)

Viewing Logs

Debugging with Correlation IDs

Performance Monitoring

Testing

Regression Guardrails

Contributing

Core Feature Protection

License

Credits

Example `settings.json`

`OpencodeServerManager`

`MessageStreamService`

`SessionService`

`SubagentTracker`

`QuotaService`

`RequestBudgeter`

`PlanParser`
