CanvasXpress Notebook Renderer for VS Code

A VS Code notebook output renderer for CanvasXpress. Call CanvasXpress the way you normally do in R, Python or JavaScript and the chart is drawn, live and interactive, in the cell output. The library is loaded from the CanvasXpress CDN inside the notebook webview.

There is no helper function to learn and no mime bundle to hand-write: the renderer reads the output each package already produces and recovers the {data, config} spec from it.

Use it natively

R — the ordinary canvasXpress() call. It returns an htmlwidget; the renderer reads the widget payload.

library(canvasXpress)

revenue <- data.frame(Q1 = 10, Q2 = 14, Q3 = 9, Q4 = 17, row.names = "Revenue")

canvasXpress(data = revenue, graphType = "Bar", title = "Quarterly Revenue")

Python — the ordinary CanvasXpress + CXNoteBook API.

from canvasxpress.canvas import CanvasXpress
from canvasxpress.render.jupyter import CXNoteBook
from IPython.display import display

chart = CanvasXpress(
    render_to="bar1",
    data={"y": {"vars": ["Revenue"], "smps": ["Q1", "Q2", "Q3", "Q4"], "data": [[10, 14, 9, 17]]}},
    config={"graphType": "Bar", "title": "Quarterly Revenue"},
)

display(*CXNoteBook(chart).render())

CXNoteBook(...).render() returns a list of display objects rather than displaying them, so on its own it prints [<HTML object>, ...] and nothing is drawn — in any Jupyter frontend, not just VS Code. Unpacking it into display() is what hands those objects to the notebook.

JavaScript — the ordinary new CanvasXpress({...}) constructor, via the Deno or Node kernel. A kernel has no DOM, so the shim in kernel-js/canvasxpress.mjs gives the object a Jupyter display representation instead of drawing it directly.

import { CanvasXpress } from "../kernel-js/canvasxpress.mjs";

new CanvasXpress({
  renderTo: "bar1",
  data: { y: { vars: ["Revenue"], smps: ["Q1", "Q2", "Q3", "Q4"], data: [[10, 14, 9, 17]] } },
  config: { graphType: "Bar", title: "Quarterly Revenue" },
});

In Deno, leaving the chart as the cell's last expression is enough. In a Node kernel (tslab, ijavascript) there is no last-expression hook — use that kernel's display helper with chart.toMimeBundle():

$$.mime(chart.toMimeBundle());

fromRows() is also exported for the common tabular case, covering what a data.frame / DataFrame does in the other two languages: row keys become vars, column keys become smps.

Emitting the spec directly

Any cell that emits the mime type application/canvasxpress+json is also drawn. The payload is a {data, config} object (optionally events, afterRender, width, height) — the arguments to new CanvasXpress({...}). This is what the JavaScript shim produces, and it stays available for kernels with no CanvasXpress package of their own.

from IPython.display import display

display({"application/canvasxpress+json": {"data": ..., "config": ...}}, raw=True)

Which outputs are claimed

Mime type	Source	How the spec is found
`application/canvasxpress+json`	emitted directly; the JS shim	the payload is the spec
`text/html`	R `canvasXpress()` htmlwidget	the widget's JSON island (`data-for="htmlwidget-…"`)
`application/javascript`	Python `CXNoteBook(...).render()`	the inlined `new CanvasXpress({...})` argument

Outputs with no CanvasXpress payload are passed through untouched — HTML is shown as HTML, script is shown as source and never executed. Other htmlwidgets (plotly, leaflet) use the same JSON-island carrier and are deliberately not claimed.

VS Code's built-in renderer also handles text/html and application/javascript. If a cell shows raw markup instead of a chart, click the ··· on the output and choose Change Presentation → CanvasXpress.

Examples

Three ready-to-run notebooks live in examples/. Open one in VS Code with this extension installed and run the cells:

canvasxpress-demo.ipynb — Python (Jupyter kernel)
canvasxpress-demo-R.ipynb — R (IRkernel)
canvasxpress-demo-JS.ipynb — JavaScript (Deno kernel)

Each covers a bar chart, a scatter plot and a heatmap, then a fourth case specific to the language — sample annotation in R, a DataFrame and multi-chart output in Python, explicit display in JavaScript.

Kernel setup, if you do not already have them:

pip install canvasxpress pandas          # Python
deno jupyter --install                    # JavaScript

install.packages(c("canvasXpress", "IRkernel")); IRkernel::installspec()   # R

Build

npm install
npm run build          # bundles src/renderer.ts -> out/renderer.js via esbuild

Press F5 in VS Code to launch an Extension Development Host, or package with vsce:

npx @vscode/vsce package

How it works

src/renderer.ts exports the VS Code activate() renderer. Its renderOutputItem resolves the output to one or more CanvasXpress specs, creates a <canvas> per spec in the (already-attached) output element, loads CanvasXpress once from the CDN, and calls new CanvasXpress({...}).

src/extract.ts holds the recovery logic for the text/html and application/javascript carriers. Both payloads are machine-generated JSON, so a string-aware brace scan plus JSON.parse is enough — no HTML parser is bundled, and nothing from the output is executed.

The chart-drawing logic is factored into the exported renderCanvasXpress(element, spec, opts) and renderCanvasXpressAll(element, specs) so it can be reused and tested outside the VS Code renderer API.

License

This extension and the CanvasXpress JavaScript library it renders are covered by the CanvasXpress Community License (Attribution) (LicenseRef-CanvasXpress-Community-Attribution; see LICENSE). CanvasXpress is free to use anywhere — including in commercial products — as long as the attribution mark it renders stays visible; a Commercial License (license key) removes the mark. Terms and pricing: https://canvasxpress.org/license.html.
