NodeMCU Lua for VS Code

Build • Flash • Sync • Monitor — everything you need for Lua development on NodeMCU / ESP8266 boards, in one VS Code extension.

First-time setup is fully automatic. The extension downloads the ESP8266 toolchain, the NodeMCU firmware source, and the required Python tools, builds the firmware, flashes the board, and creates your project. After that, development is as simple as editing files in src/ and pressing Save.

Features

• ✅ One-click project initialization — a single Initialize NodeMCU Project action
• ✅ Automatic firmware build and flash — toolchain and firmware are downloaded and managed for you.
• ✅ Auto-upload on save — save a file in src/ and it runs on the board
• ✅ Live Serial Console — always in view in the bottom panel
• ✅ NodeMCU Lua IntelliSense — completion and hover docs for the device API
• ✅ Lua and C module management — pick modules with checkboxes in the sidebar and automatically update the firmware and flash it to the board.
• ✅ Serial port explorer — seamless device switching, it warns if try to sync a different device from the one initially set.
• ✅ No ESPlorer, no nodemcu-tool setup, no firmware checkout required

Getting started with NodeMCU Lua used to mean assembling a toolbox by hand: clone nodemcu-firmware, set up a cross-compiler, edit C headers to select modules, flash with esptool, then switch to ESPlorer or nodemcu-tool to upload Lua files and watch serial output. This extension collapses all of that into one click.

How it works

                 VS Code
                    │
                    ▼
           NodeMCU Extension
                    │
     ┌──────────────┼──────────────┐
     ▼              ▼              ▼
Build Firmware  Upload Lua    Serial Console
Flash Device    on Save       (live monitor)
     └──────────────┴──────────────┘
                    │
                    ▼
            ESP8266 / NodeMCU

The firmware source, cross-compiler, and flashing tools live in VS Code extension storage — your project folder stays small (nodemcu.ini + src/).

Quick Start

1. Install the extension in VS Code.
2. Open the folder that will contain your NodeMCU project.
3. Open the NodeMCU Activity Bar item.
4. Click Initialize NodeMCU Project.
5. Connect your NodeMCU / ESP8266 board with a USB data cable.
6. Watch the bottom-panel NodeMCU Serial console.
7. Edit Lua files in src/ and save them.
8. Press F5 to upload pending changes; the Serial Console stays connected.

That's the whole setup — the only host prerequisites are Python 3 and CMake (see Requirements). The first run takes a while because the extension downloads tools and firmware, builds the firmware image, flashes the board, and performs the first device filesystem sync. After that, saving a file in src/ uploads only that file.

What Gets Created

Running NodeMCU: Initialize Project creates a project like this:

your-project/
|- nodemcu.ini
`- src/
   `- init.lua

Put your Lua application files in src/. The extension watches this directory and syncs it to the device.

Core Workflow

Initialize
    ↓
Write Lua in src/
    ↓
Save
    ↓
Auto Upload
    ↓
See output in Serial Console

1. Edit a Lua file in src/.
2. Save the file.
3. The bottom-panel NodeMCU Serial console remains focused and shows device output.
4. The first sync mirrors the whole src/ directory.
5. Later saves upload only the saved file.
6. Press F5 for Upload and Monitor when you want to upload pending changes explicitly.

The extension owns the selected serial port through a shared serial session. Commands such as upload, delete, run, reset, and Lua module sync write through that session while the Serial Console keeps reading. During those operations the console input box is disabled, but serial output continues to stream.

Use NodeMCU: Release Serial Port or NodeMCU: Disconnect Serial Session if you want another tool to use the port. NodeMCU: Open Serial Console shows the console and reconnects it.

First Run vs Later Runs

Sidebar Views

Device Explorer

Shows detected serial ports. Click a port to select it. When detection is unambiguous, the extension can select the port automatically and write it to nodemcu.ini.

The extension keeps a configured port when it is still available. If the configured port disappears, it only auto-selects a replacement when exactly one serial port is present or exactly one NodeMCU-like port is detected.

Lua Modules

Lists Lua helper modules from the managed firmware library. Checking a module adds it to [lua_modules] in nodemcu.ini; unchecking it removes the module from the device on the next sync.

Lua module autocomplete also participates in this workflow. Accepting a module completion inserts name = require("name"), enables the module in nodemcu.ini, refreshes the sidebar, and syncs the module to the device.

C Modules

Lists firmware C modules from app/modules plus supported optional/library modules. Checking a module enables it in [c_modules]. Changing C modules can require a firmware rebuild and flash because C modules are compiled into the firmware image.

The file module is mandatory for file upload support and cannot be disabled.

Building and Flashing Firmware

Press Ctrl+Alt+B (NodeMCU: Build & Flash) after changing C modules. The extension builds the firmware image with the managed toolchain, flashes it, and reconnects the Serial Console as the board reboots. Rebuilds happen only when the selected C modules change.

Commands

Open the Command Palette and run commands under the NodeMCU category. You usually won't need to use it, except for NodeMCU: Initialize Project.

Configuration

Most users can leave nodemcu.ini alone after initialization. The extension updates the selected port, enabled modules, device UUIDs, and sync timestamp as needed.

Example:

[nodemcu]
lua_version = 53
lua_number_integral = false
lua_number_64bits = false
port =
baud = 115200
upload_baud = 115200
src = src
flash_mode = dio
flash_freq = 80m
flash_size = 4M

[c_modules]
adc = true
file = true
gpio = true
net = true
node = true
tmr = true
uart = true
wifi = true
; mqtt = false
; sjson = false
; u8g2 = false

[devices]
uuids =

[lua_modules]
; bh1750 = lua/bh1750.lua
; gossip = https://github.com/nodemcu/nodemcu-firmware/raw/master/lua_modules/gossip/gossip.lua

[flash]
; extra_files = spiffs.bin@0x100000

[build]
parallel = true
verbose = false

Important settings:

VS Code settings:

Managed Firmware

By default, the extension uses managed firmware in VS Code global storage. This keeps normal projects small and avoids requiring every user to clone nodemcu-firmware.

Use a custom firmware checkout only when you need to patch firmware sources or build against a different tree. In that case, set firmware_path in nodemcu.ini to the checkout path.

Lua IntelliSense and Snippets

Typing a firmware Lua module name (such as fifo) offers a NodeMCU Lua module completion. Accepting it inserts fifo = require("fifo"), enables the module in nodemcu.ini, checks it in the sidebar, and syncs it to the device. Hover documentation comes from the Lua language server.

The extension can generate:

.vscode/nodemcu-api.lua
.luarc.json

These files let the Lua language server understand common NodeMCU globals. Run NodeMCU: Regenerate Lua API Stubs if they need to be recreated.

Snippet prefixes:

Device Safety

The first sync for a new device/workspace can format the device filesystem so the local src/ directory becomes the source of truth. When the workspace has known device UUIDs and a different device is attached, VS Code asks before adding that device and syncing.

Keep one workspace per physical project when possible. That makes the device UUID guard useful and reduces accidental cross-project uploads.

Requirements

• VS Code 1.85 or newer.
• A NodeMCU / ESP8266 board.
• A USB data cable that supports data, not just charging.
• Python 3 available as python, unless configured otherwise.
• CMake and a supported generator such as Ninja or Make for firmware builds.

You do not need a nodemcu-firmware checkout, an ESP8266 cross-compiler, or standalone esptool/ESPlorer installs — the extension manages those itself.

Troubleshooting

The first initialization is slow

This is expected. The first run may download managed tools, download firmware, build firmware, flash the board, format the device filesystem, and sync src/.

No serial port is detected

Check the USB cable, driver, and board power. Then run:

NodeMCU: Select Port

On Windows, common USB serial adapters may require CP210x or CH340 drivers.

Uploads do not appear on the device

Confirm the file is inside the configured src/ directory. Then check the bottom-panel NodeMCU Serial console for device output. The NodeMCU output channel still stores extension logs, but it does not open automatically.

C module changes are not visible on the board

C modules are compiled into firmware. Run:

NodeMCU: Build & Flash

Then upload the Lua files again.

Lua module require() fails

Make sure the module is checked in the Lua Modules sidebar or listed in [lua_modules]. Then run NodeMCU: Sync Lua Modules to Device or press F5.

The wrong project is syncing to the board

Open nodemcu.ini and check [devices] uuids. If the attached device belongs to another workspace, open that workspace before syncing.

Extension Development

Install dependencies and build:

npm install
npm run typecheck
npm run build

Run tests:

npm test

Package a VSIX:

npm run package

The extension host loads dist/extension.js, so rebuild after source changes. See AGENTS.md for internal architecture, testing notes, and handoff context.

License

MIT
