SvelteDoc

Intelligent hover tooltips for your Svelte 5 components — See component props, types, and JSDoc comments without leaving your workflow.

Example video

What it does

Hover over any Svelte component tag to instantly see:

Props extracted from $props() type annotations
Type information including complex TypeScript types and generics
JSDoc comments explaining each prop
Default values and $bindable() indicators
Inherited types from extended interfaces

No need to jump between files or generate documentation blocks — SvelteDoc brings the information to you.

Example of documented component

Suggestions are welcome! Please create an issue on the GitHub repo and your suggestion will be taken into consideration!

Quick Start
Features
Best Practices
Configuration
Commands
Troubleshooting
References

Quick Start

1. Create a component with typed props:

<!-- Button.svelte -->
<script lang="ts">
	interface Props {
		/** Button text to display */
		label: string;

		/** Visual style variant */
		variant?: 'primary' | 'secondary';

		/** Click handler (method shorthand also supported: onClick(e: MouseEvent): void) */
		onClick?: (event: MouseEvent) => void;
	}

	const { label, variant = 'primary', onClick }: Props = $props();
</script>

<button class={variant} onclick={onClick}>
	{label}
</button>

2. Import and use the component:

<!-- App.svelte -->
<script lang="ts">
	import Button from './Button.svelte';
</script>

<!-- Hover over "Button" to see prop documentation -->
<Button label="Click me" variant="secondary" />

3. See the magic! Hover over <Button and see a tooltip with:

label: string — Button text to display ⚠️ (required)
variant?: 'primary' | 'secondary' — Visual style variant (default: 'primary')
onClick?: (event: MouseEvent) => void — Click handler

Features

🎯 Intelligent Prop Extraction — Parses multi-line properties, nested types, TypeScript utilities, and JSDoc comments automatically.
⚡ Smart Import Resolution — Resolves relative imports, tsconfig aliases, and workspace packages seamlessly.
📊 Customizable Tooltips — Choose between bullet list, table, or code block formats with four sorting options.
⚡ Performance Optimized — In-memory caching with automatic invalidation keeps tooltips fast and accurate.

Best Practices

Important Practices

It is highly recommended to follow best practices (for Svelte 5) to ensure SvelteDoc works optimally. The following list is essential:

Components must be capitalized (e.g., <Button>, <Card>) to be recognized.
Always use typed $props() destructuring in your components.

Read the following sections on path resolution and workspace packages to ensure imports are resolved correctly.

Path Resolution

SvelteDoc resolves imports intelligently. Here's how to configure your project for best results:

1. Relative Paths

Works out of the box:

import Button from './Button.svelte';
import Card from '../components/Card.svelte';

2. tsconfig.json Path Aliases

Define aliases in your tsconfig.json or jsconfig.json:

{
	"compilerOptions": {
		"paths": {
			"$lib/*": ["./src/lib/*"],
			"@components/*": ["./src/components/*"],
			"@utils/*": ["./src/utils/*"]
		}
	}
}

Then use them in imports:

import Button from '$lib/components/Button.svelte';
import Card from '@components/Card.svelte';

SvelteDoc will automatically find your aliases and resolve it to the actual file path, checking barrel files as needed. Path aliases that are defined in multiple tsconfig files (like extending a base config for SvelteKit) are also supported.

3. Local Libraries

Currently works with PNPM workspaces (see next section). Enusre you have a pnpm-workspace.yaml file at your monorepo root and the library package is referenced in your package.json file. Then just import as normal:

import { Button } from '@myorg/mylib';

SvelteDoc will resolve the library's package, check the exports field in package.json, and follow barrel files to find the component.

Workspace Packages

For monorepos using pnpm workspaces, SvelteDoc provides advanced barrel file resolution.

Setting up a Shared Package

1. Create workspace structure:

project-root/
├── pnpm-workspace.yaml
├── packages/
│   ├── shared/
│   │   ├── package.json
│   │   └── src/
│   │       ├── index.ts          # Barrel file
│   │       └── components/
│   │           ├── index.ts      # Nested barrel
│   │           ├── Button.svelte
│   │           └── Card.svelte
│   └── app/
│       ├── package.json
│       └── src/
│           └── App.svelte

2. Configure pnpm-workspace.yaml:

packages:
  - 'packages/*'

3. Set up package.json with exports:

{
	"name": "@myorg/shared",
	"exports": {
		".": {
			"svelte": "./src/index.ts",
			"default": "./src/index.ts"
		},
		"./components": {
			"svelte": "./src/components/index.ts",
			"default": "./src/components/index.ts"
		}
	}
}

4. Create barrel files:

packages/shared/src/index.ts:

// Re-export from nested barrels
export * from './components/index.ts';

packages/shared/src/components/index.ts:

// Named default re-exports (recommended)
export { default as Button } from './Button.svelte';
export { default as Card } from './Card.svelte';

// Or named re-exports
export { Button } from './Button.svelte';
export { Card } from './Card.svelte';

Tip: Use custom barrel file names like core.ts or main.ts instead of index.ts to organize exports. Configure recognized barrel file names via the barrelFileNames setting (default: ["index", "main"]).

5. Use in consuming packages:

<script lang="ts">
	// SvelteDoc will resolve through barrels automatically
	import { Button, Card } from '@myorg/shared';
</script>

<!-- Hover works! -->
<Button label="Click me" />
<Card title="My Card" />

Note: SvelteDoc automatically resolves barrel files (re-exports) with configurable depth (default 3 levels, adjustable via barrelFileMaxDepth setting) and customizable barrel file names (default ["index", "main"], adjustable via barrelFileNames setting). Results are cached for performance.

Configuration

All settings are under the sveltedoc namespace:

cacheExpirationMinutes (number, default: 30) — Minutes of inactivity before clearing cached props. ⚠️ Higher values may increase memory usage.
normaliseComment (boolean, default: false) — Remove extra whitespace from JSDoc comments for compact display.
normaliseType (boolean, default: true) — Remove extra whitespace from type definitions for compact display.
normaliseDefaultValue (boolean, default: true) — Remove extra whitespace from default values for compact display.
tooltipOrder (string, default: 'required') — Property display order: normal, alphabetical, required, or type.
tooltipFormat (string, default: 'code-block') — Tooltip format: bullet-list, table, or code-block.
showPropertyComments (boolean, default: true) — Show JSDoc comments for component properties in the tooltip.
showPropertyTypes (boolean, default: true) — Show type information for component properties in the tooltip. When disabled in code-block format, required props will show a // required comment.
showDefaultValues (boolean, default: true) — Show default values for component properties in the tooltip.
showTypeInheritance (boolean, default: true) — Show the "Extends" line when component props inherit from other types or interfaces.
detailedResolverLogging (boolean, default: false) — Enable detailed logging for import resolution debugging. Check Output panel (View → Output → SvelteDoc).
fallbackTypes (object, default: { "children": "Snippet", "class": "string" }) — Map of property names to types used when a prop has an 'unknown' type. Useful for common props like 'children' or 'class' that are often destructured without type annotations.
barrelFileMaxDepth (number, default: 3) — Maximum depth for resolving barrel files (index re-exports) in workspace packages. Range: 0-10. ⚠️ Warning: Higher values may slow down component resolution. Set to 0 to disable barrel file resolution.
barrelFileNames (array, default: ["index", "main"]) — List of file names (without extension) to recognize as barrel files. Files matching these names will be checked for re-export patterns when resolving workspace package imports. Use ["*"] to check any .ts/.js file for re-exports. ⚠️ Warning: Using wildcard * may impact performance on large projects.
hoverWithinTag (boolean, default: true) — Show component properties when hovering anywhere within opening tag brackets, not just on the tag name. This allows you to see props while hovering over attributes or values.
hoverWithinTagMaxLines (number, default: 50) — Maximum lines to search backwards when detecting component tags for the hover-within-tag feature. Range: 1-200. Lower values improve performance but may miss very long multi-line component tags.

Commands

Access via Command Palette (Ctrl+Shift+P / Cmd+Shift+P):

`SvelteDoc: Clear Cache`

Clears all cached component prop data. Useful if you see stale information after updating component types.

`SvelteDoc: Show Output`

Opens the SvelteDoc output panel showing detailed logs of hover attempts, component resolution, and prop extraction.

Troubleshooting

"No import found for component"

Problem: Tooltip shows error when hovering over component tag.

Solutions:

Verify the component is imported in your <script> block
Check import statement syntax (both default and named imports work)
Ensure component name matches the imported name exactly (case-sensitive)

Example:

<script lang="ts">
	// ✅ Works
	import Button from './Button.svelte';
	import { Card } from './Card.svelte';

	// ❌ Won't work — no import
	// <Alert /> won't show tooltip
</script>

<Button label="Test" />
<Card title="Works" />

"No $props() found"

Problem: Tooltip shows "No props found" even though component has props.

Solutions:

Add $props() destructuring to your component
Ensure $props() has a type annotation (: Props or : { ... })
Check that the type is defined in the same file or imported

Example:

<!-- ❌ Won't work — no type annotation -->
<script lang="ts">
	const { label } = $props();
</script>

<!-- ✅ Works — has type annotation -->
<script lang="ts">
	interface Props {
		label: string;
	}

	const { label }: Props = $props();
</script>

"Could not resolve component path"

Problem: Import path cannot be resolved (tsconfig alias or workspace package).

Solutions:

Verify tsconfig.json or jsconfig.json has correct paths configuration
For workspace packages, ensure pnpm-workspace.yaml exists and references the package
Check package.json has properly configured exports field
Enable detailedResolverLogging setting and check Output panel for details

Check Output Panel:

Open Command Palette (Ctrl+Shift+P / Cmd+Shift+P)
Run "SvelteDoc: Show Output"
Look for resolver logs showing which paths were tried

Stale or Incorrect Information

Problem: Tooltip shows outdated props after changing component definition.

Solutions:

Run command: "SvelteDoc: Clear Cache"
Check if file was saved (cache validates via modification time)
Adjust cacheExpirationMinutes setting for faster expiration

References

License

See LICENSE.
