NavTrace

A VS Code extension that records your code-navigation trail as a branching tree you can browse and walk back through.

Current release: 0.1.2 — see CHANGELOG for what's new.

The problem

When you're exploring an unfamiliar or legacy codebase, navigation is rarely a straight line. You follow a call chain five levels deep, realize you need to backtrack, then explore a different branch — and VS Code's built-in Alt+Left history is a flat list that discards everything the moment you take a new turn.

NavTrace keeps every fork. Each time you backtrack and navigate somewhere new, it opens a new branch in the tree rather than overwriting the old one. You can see the full shape of your exploration and jump to any point in it.

Installation

From the VS Code Marketplace (recommended)

1. Open the Extensions panel (Ctrl+Shift+X / Cmd+Shift+X)
2. Search for NavTrace
3. Click Install

From the command line

code --install-extension breadkrumb.navtrace

From a .vsix file

code --install-extension navtrace-<version>.vsix

Usage

1. Open a project and navigate your code normally — use F12 (Go to Definition), Shift+F12 (Go to References), Ctrl+Click, or any other built-in navigation command.
2. Click the NavTrace icon (milestone icon) in the activity bar to open the Trail panel. Each navigation step appears as symbol — file:line.
3. Click any node in the tree to jump directly to that location.
4. Press Ctrl+Alt+Left (Cmd+Alt+Left on macOS) to step backward through the trail without losing your forward history.
5. Navigate from any earlier node and NavTrace forks a new branch — both paths stay in the tree.

Example: exploring a legacy codebase

processOrder          orders.ts:42
  └─ validateCart     cart.ts:18       ← you stepped back here...
       ├─ applyRules  rules.ts:91      ← ...explored this path
       └─ checkStock  inventory.ts:55  ● ← ...then explored this one (current)

Both branches are preserved. Click either to jump there instantly.

Commands

The Step Back and Clear Trail buttons also appear in the Trail panel's toolbar.

Supported languages

TypeScript, JavaScript, TypeScript React, JavaScript React, Python, Java, Go, Rust, C, C++, C#, PHP, Ruby.

You can add or remove languages via the navtrace.languages setting:

"navtrace.languages": ["typescript", "typescriptreact", "python", "kotlin"]

Settings

How it works

NavTrace listens for two VS Code events:

• onDidChangeTextEditorSelection with Command kind — captures the symbol under the cursor just before a navigation command fires.
• onDidChangeActiveTextEditor — if a symbol was captured within the last 5 seconds and the active editor changes (or the cursor jumps within the same file), it records a step from the captured position to the new one.

After recording, it asynchronously queries the language server (vscode.executeDocumentSymbolProvider) to resolve the real containing function or method name and updates the node label if a better name is found.

The trail is stored as a tree of NavNode { id, parentId, symbol, fromFile, fromLine, toFile, toLine } with a currentId pointer. The state persists per workspace under navtrace.trail.v2 in workspaceState.

Known limitations

• Symbol capture is heuristic (word-under-cursor + a noise filter) rather than fully language-server aware, so labels on dense lines may occasionally be imprecise. The language server lookup corrects most of these asynchronously.
• Same-file jumps are detected via a follow-up cursor move; rapid keyboard navigation can occasionally miss a step.

Development

npm install
npm run compile    # one-off build
npm run watch      # incremental rebuild on save
npm test           # run the test suite

Press F5 in VS Code to launch the Extension Development Host with the extension loaded.

To package a .vsix for local distribution:

npm run package
