Azure Templates Navigator

A must-have VS Code extension for anyone who develops, debugs, or reviews Azure Pipelines YAML files.

Hover over any - template: reference to instantly see its parameters. Get real-time diagnostics for missing or unknown parameters. Autocomplete parameter names as you type. Hover over $(variables) to see their values. Explore the full template dependency tree and an interactive workspace-wide dependency graph — all with zero runtime dependencies.

Full extension overview — hover tooltip, dependency tree with "Called by", template graph, and Problems panel all in one view:

Features

🔍 Template Parameter Hover

Hover over any - template: line to see a tooltip with all parameters declared in the referenced template — their types, default values, and which are required.

The tooltip also shows a 🔍 Search link next to the Parameters heading. Clicking it opens a QuickPick pre-populated with every parameter so you can:

• Type to instantly filter by name, type, or default value
• ↑ / ↓ to navigate the filtered list
• Enter (or double-click) to jump directly to that parameter's definition line in the template file

Particularly useful for templates with 20–40+ parameters where scrolling the tooltip is slow.

🔴 Parameter Validation Diagnostics

Real-time squiggly-line diagnostics on every template call site and inside template files themselves:

• Error — missing a required parameter (call-site)
• Warning — passing an unknown parameter not declared in the template (call-site)
• Warning — type mismatch (e.g. passing 'yes' to a boolean parameter) (call-site)
• Warning — parameter declared in the template parameters: block but never referenced in the template body (unused-param) Diagnostics update automatically as you type (debounced 500ms).

💡 IntelliSense Autocomplete

When typing inside the parameters: block under a - template: line, the extension offers autocomplete suggestions for every parameter declared in the referenced template:

• Required parameters appear first (marked with ⚠)
• Each suggestion shows the parameter type and default value
• Already-set parameters are shown at the bottom

📦 Pipeline Variable Hover

Hover over any $(variableName) or ${{ variables.name }} reference to see:

• The variable's value (from the pipeline variables: block)
• The line where it is defined
• For variable groups: the group name
• For Azure DevOps system variables (Build.*, System.*, Agent.*, etc.): a link to the official docs

🌲 Template Dependency Tree View

A sidebar panel in the Azure Templates Navigator Activity Bar showing the full dependency tree for the currently active pipeline file:

• Expand any node to see templates it references (recursive, nested templates supported)
• Cycle detection — circular references are shown as ↩ circular leaf nodes instead of causing infinite recursion
• Click any node to open the template file
• Right-click any node for context menu actions:
  • Open to Side — opens the template in a split editor column
  • Copy Template Path — copies the raw template: reference string to the clipboard
• Cross-repo templates show a 🔗 repo badge; missing templates show a ⚠ warning icon
• Parameter count shown as 3 params · 2 req ⚠ in the dimmed description
• Refresh button in the panel title bar; auto-refreshes on active editor change
• "Called by" section — shows which files call the currently active template (reverse dependency lookup)

🗺️ Template Graph View

An interactive force-directed graph in the same Activity Bar panel (below the tree view) showing all YAML files in the workspace and their template relationships at a glance:

Interactions:

• Click a node → opens the file in the editor
• Drag a node → pins it in place; double-click to unpin
• Scroll → zoom in/out; drag background → pan
• Hover a node → highlights its direct neighbours and dims the rest; shows a tooltip with path and parameter count
• Right-click a node → copies the file path to the clipboard
• Filter box → type to highlight matching nodes by filename or repo name
• ↺ Refresh → re-scans the workspace
• ⊡ Fit → fits the entire graph into the visible area
• ⟳ Reset → unpins all nodes and re-runs the simulation

Works fully offline — D3 v7 is bundled with the extension.

🔗 Cross-Repository Template Support

Resolves @alias references using resources.repositories declarations. The extension maps each alias to its repository name and resolves the template path as {repo-root}/../{repo-name}/{template-path} on the local filesystem.

⌨️ Go-to-Definition

Press F12 / Cmd+Click / Ctrl+Click on any - template: line to jump directly to the template file.

🎨 Configurable Required Parameter Color

Required parameters are highlighted in a configurable color (default: red) in the hover tooltip.

✅ Zero Dependencies

No npm install needed at runtime. Works straight from the marketplace.

How it works

Template Parameter Hover

A parameter is considered required when it has no default: key — exactly how Azure Pipelines itself treats parameters at runtime. No special comments or annotations are needed.

parameters:
  - name: environment        # required — no default:
    type: string
  - name: azureSubscription  # required — no default:
    type: string
  - name: vmImage            # optional — has a default
    type: string
    default: 'ubuntu-latest'

Then in your pipeline file, hover over any - template: line:

- template: templates/deploy.yml
  parameters:
    environment: 'Production'

The tooltip will show each parameter, its type, default value, and whether it is required.

Parameter Validation Diagnostics

The extension automatically validates every template call site in your pipeline files. No configuration needed — it works as soon as you open a YAML file.

Missing required parameter (red squiggly on the template: line):

- template: templates/deploy.yml   # ← Error: Missing required parameter 'environment'
  parameters:
    azureSubscription: my-sub

Unknown parameter (yellow squiggly on the parameter name):

- template: templates/deploy.yml
  parameters:
    environment: Production
    typoParam: value              # ← Warning: Unknown parameter 'typoParam'

Type mismatch (yellow squiggly on the parameter line):

- template: templates/build.yml
  parameters:
    publishArtifact: 'yes'        # ← Warning: expects 'boolean', got 'string'

Note: Parameters passed as pipeline expressions ($(var) or ${{ variables.x }}) are excluded from type checking since their values are only known at runtime.

Quick Fix Actions

When a diagnostic is reported, a Quick Fix lightbulb appears. Click it (or press Cmd+. / Ctrl+.) to apply a one-click fix:

All quick fixes are marked as isPreferred and appear at the top of the lightbulb menu.

IntelliSense Autocomplete

When your cursor is inside the parameters: block under a - template: line, press Ctrl+Space (or just start typing) to see autocomplete suggestions:

- template: templates/deploy.yml
  parameters:
    env<cursor>   # ← suggests: environment ⚠ required, ...

Each suggestion includes:

• The parameter name
• Its type (shown right-aligned)
• Whether it is required
• Its default value (if any)
• A snippet that places the cursor after the : for immediate value entry

Pipeline Variable Hover

Hover over any $(variableName) or ${{ variables.name }} reference in your pipeline:

variables:
  buildConfiguration: 'Release'   # defined on line 3

steps:
  - script: dotnet build --configuration $(buildConfiguration)
  #                                       ^^^^^^^^^^^^^^^^^^^
  #                                       Hover here → shows value 'Release', line 3

Variable groups are shown with their group name:

variables:
  - group: my-secrets-group   # hover over $(secretVar) → shows group name

System variables (Build.BuildId, System.TeamProject, etc.) show a link to the Azure DevOps predefined variables documentation.

Template Dependency Tree View

Open the Azure Templates Navigator panel in the Activity Bar (left sidebar). The tree automatically updates when you switch between YAML files.

📄 azure-pipelines.yml
  ├── 📄 build-dotnet.yml          3 params · 2 req ⚠
  ├── 📄 run-tests.yml             2 params · 1 req ⚠
  ├── 🔗 deploy-stage.yml @shared  6 params · 3 req ⚠
  └── 📄 notify-teams.yml          3 params
        └── 📄 teams-webhook.yml   1 param

Click any node to open the template file. Right-click for Open to Side or Copy Template Path. Use the ↺ Refresh button in the panel title bar to force a refresh.

Circular references are detected and shown as leaf nodes with a ↩ circular badge — no infinite recursion.

Template Graph View

The Template Graph panel (below the tree in the same Activity Bar container) scans every YAML file in the workspace and renders a force-directed graph of all template relationships.

This is complementary to the tree view:

Tips:

• Use the Filter box to highlight a specific template across the whole graph
• Drag nodes to arrange them; they stay pinned until you double-click or hit ⟳ Reset
• Use ⊡ Fit after a refresh to bring all nodes into view
• The graph works fully offline — D3 v7 is bundled with the extension

Cross-Repository Templates

Azure Pipelines lets you reference templates from other repositories using the @alias syntax. The extension resolves these references automatically by reading the resources.repositories block in the same file.

How it works

Given a pipeline like this:

resources:
  repositories:
    - repository: templates          # alias used in template references
      name: myorg/shared-templates   # the actual repository name

stages:
  - template: stages/build.yml@templates

The extension:

1. Reads the resources.repositories block and builds an alias → repo-name map (templates → shared-templates)
2. Resolves the template path as {repo-root}/../shared-templates/stages/build.yml (one level above the current repo root, next to it on disk)

Setup

Clone the external repository next to your current workspace:

parent-directory/
├── your-pipeline-repo/     ← your workspace (open in VS Code)
│   └── pipelines/azure-pipelines.yml
└── shared-templates/       ← clone the template repo here
    └── stages/build.yml

The hover tooltip will show the template's parameters and a 🔗 External repository badge. If the sibling directory doesn't exist yet, the tooltip shows a helpful message telling you which repo to clone.

Unknown alias

If you hover over a @alias reference that has no matching entry in resources.repositories, the tooltip explains what to add:

⚠️ Repository alias not found: @templates Add a resources.repositories entry with repository: templates to enable cross-repo template resolution.

Configuration

You can also run the command "Azure Templates Navigator: Set Required Parameter Color" from the Command Palette (Cmd+Shift+P) to change the color interactively. Accepts hex values (#ff0000), named colors (red, blue, green, pink, purple, orange, yellow, tesla), or random.

Local Development Workflow

Prerequisites

• Node.js (v16+)
• VS Code

First-time setup

# Clone the repo
git clone https://github.com/qSharpy/azure-templates-vscode-extension.git
cd azure-templates-vscode-extension

# Install dev dependencies (only needed for linting/packaging, NOT for running the extension)
npm install

Note: The extension itself has zero runtime dependencies. npm install is only needed if you want to run the linter (npm run lint) or package the extension (npm run package).

Test locally with F5

1. Open the project folder in VS Code
2. Press F5 (or go to Run → Start Debugging)
3. A new VS Code window opens — the Extension Development Host — with your extension loaded
4. In that new window, the samples/ folder is opened automatically
5. Open samples/azure-pipelines.yml and:
   • Hover over any - template: line to see the parameter tooltip
   • Hover over any $(variableName) to see the variable value
   • Look at the Problems panel for parameter validation diagnostics
   • Open the Azure Templates Navigator panel in the Activity Bar
6. You should see all features working immediately

To reload after making changes:

• Press Cmd+R (Mac) / Ctrl+R (Windows/Linux) in the Extension Development Host window, or
• Stop debugging (Shift+F5) and press F5 again

Lint

npm run lint

Package as .vsix (for manual install / sharing)

npm run package
# Produces: azure-templates-navigator-X.Y.Z.vsix

Install the .vsix locally:

Extensions panel → ··· menu → Install from VSIX...

Publish to the Marketplace

# One-time: log in with your Personal Access Token
npx vsce login bogdanbujor

# Publish (bumps version in package.json automatically with --patch/--minor/--major)
npm run publish

Running unit tests

The pure-logic unit tests run without a VS Code host and complete in milliseconds:

npm run test:unit

The full VS Code integration test suite (requires a desktop environment):

npm test

Known Limitations

• Only parses parameters: blocks at the top level of the template file
• Template references using variables (e.g. - template: ${{ variables.templatePath }}) are not resolved (skipped gracefully)
• Cross-repo resolution assumes the sibling repo is cloned locally; remote-only repos are not fetched automatically
• Variable group contents require an Azure DevOps connection to resolve (only the group name is shown)
• Type checking for object, step, job, stage parameter types is limited (multi-line YAML values are not fully parsed)
