React Architecture Analyzer - VS Code Extension 🔌

This is the VS Code Extension codebase for the React Architecture Analyzer. It extracts React component properties and relations from codebases, uploads them, and embeds interactive diagrams in VS Code.

🛠️ Key Features

• Project Scanner: Searches .js, .jsx, .ts, .tsx files inside workspaces, skipping directories like node_modules, .git, etc.
• Static Parser:
  • Detects component declarations.
  • Identifies state variables and hooks.
  • Maps parent-child relations and analyzes types of properties passed to children.
• Sidebar view: Lists scanned projects and runs scans.
• Integrated Graph View: Opens a customized webview showing the diagram inside VS Code.

📂 Directory Layout

• media/ - Web assets for sidebar display:
  • sidebar.html: Sidebar UI template.
  • sidebar.css: Styling for the sidebar interface.
  • sidebar.js: Event handler passing UI events to the extension host.
  • icon.svg: Activity bar menu icon.
• src/ - Backend integration and file parsing logic:
  • api.js: Dependency-free node HTTP client helper.
  • scanner.js: Static regex-based code analyzer.
  • sidebarProvider.js: Registers the WebviewViewProvider for UI event handling.
• extension.js - Extension entry point registering triggers, context actions, commands, and options.
• package.json - Declares activations, configuration menus, custom VS Code attributes, and dev dependencies.

⚙️ Development Guide

1. Install Dependencies:

   cd extension
   npm install


2. Run and Debug:

   • Open /extension in VS Code.
   • Press F5 to launch an Extension Development Host window.

3. Scan Workspace:

   • Open a React workspace in the debug window.
   • Open the React Architecture sidebar panel and select Scan Workspace.
