OpenAPI Converter

Convert OpenAPI and Swagger files, or move supported description markers into OpenAPI fields, directly in VS Code.

No telemetry. No network requests. The extension does not store your files.

Commands

Convert a file

All conversions support JSON and YAML input and output.

* The target version is older and may not support every feature. The extension completes the conversion and lists anything adjusted or removed. Your source file stays unchanged, and you decide whether to save the result.

To convert a file:

1. Open a JSON or YAML file, or right-click it in the Explorer.
2. Run OpenAPI: Convert Version.
3. Choose the target version and output format.
4. Review the result in a new tab. Select Save As to save it.

Apply markers

A supported marker in a description becomes an OpenAPI field. The marker is then removed from the description.

Customer request number. [example: "RQ/2026/000123"] [pattern: "^RQ/\d{4}/\d{6}$"]

becomes:

requestNumber:
  type: string
  description: Customer request number.
  pattern: ^RQ/\d{4}/\d{6}$
  example: RQ/2026/000123

Each marker is written the way the file's own version writes that field. The example above is a Swagger 2.0 or OpenAPI 3.0 file; from OpenAPI 3.1 on, where the schema keyword example is deprecated in favour of the JSON Schema examples keyword, the same marker gives examples: [RQ/2026/000123]. On a parameter the value goes on the parameter itself and the validation markers into its schema, because 3.x keeps the two apart.

Markers also work at the operation level. [response:] adds a status code with its description, body schema, and example, and [responseCase:] / [requestCase:] add several named example cases to one code or to the request body, which Swagger UI shows in a dropdown:

Creates an order.
[response: 404 "Order not found" #ApiError {"code": "NOT_FOUND"}]
[responseCase: [code: 200] [name: confirmed] [summary: Confirmed straight away] [exampleBody: {"orderId": "ORD-1"}]]
[responseCase: [code: 200] [name: awaitingStock] [summary: Waiting for stock] [exampleBody: {"orderId": "ORD-2"}]]

Every part of a case is written the same way the markers themselves are, as [part: value], so nothing has to be quoted and the parts may stand in any order — only the marker name comes first. A case with no [exampleBody:] takes its value from the model: the standard case of a large request body is composed from the [example:] values already on the fields, so adding a field does not mean editing an example by hand. [required] narrows it to the required fields alone, and [order:] sets where each case lands in the dropdown:

[requestCase: [name: minimal] [summary: Required fields only] [order: 1] [required]]
[requestCase: [name: standard] [summary: Standard order] [order: 2]]

Markers add to what the file already has: status codes that came from a generator stay as they are, and a marker naming an existing code changes only the parts it gives.

Unsupported markers, such as [TODO: ...], remain unchanged. Invalid values are not applied — the marker stays visible in the description, and the extension lists what it could not apply, which example keys are missing from the model, and which examples contradict their pattern. A marker left open, with its closing ] missing, is listed the same way instead of quietly doing nothing. Running the command again does not change an already processed file.

OpenAPI: Convert Version applies the markers to the converted file, so each marker is judged by the version you convert to. Converting a Swagger 2.0 file upwards applies the markers the newer version has gained — named cases and code ranges included — in one step, with no second command to run. Converting downwards applies what the older version still supports and leaves the rest in the descriptions, listed after the command finishes.

See the marker reference for all supported markers and value rules. A complete example is available in examples/markers-swagger2.json.

Privacy and security

All processing happens on your computer. The extension makes no network requests, sends no telemetry, and does not download external $ref files. It stores nothing: a result is written only when you save it. Restricted Mode is supported. The security policy describes the full scope.

Installation

Install OpenAPI Converter from the Visual Studio Code Marketplace, or download a .vsix file from the GitHub releases page and run Extensions: Install from VSIX.

Support

Report bugs in GitHub Issues. For security issues, and for what must not go into a report, read the security policy.

MIT License · Changelog
