Shrimpl Language Server for VS Code

This extension adds full Shrimpl language support to VS Code:

• Syntax highlighting and basic editor configuration for .shr files.
• A Language Server Protocol (LSP) backend implemented in Rust (shrimpl-lsp).
• Live diagnostics, hover help, keyword snippets, and document symbols for Shrimpl APIs.

This document is aimed at contributors who want to understand how the LSP works and how to extend it.

---

1. Architecture overview

The Shrimpl tooling is split across two projects:

• Core language + LSP backend Repository: shrimpl-language

  • Library crate: parser, AST, interpreter, docs/diagnostics.
  • Binary: shrimpl-lsp (Rust, uses tower-lsp).

• VS Code extension (this repo)

  • TypeScript code that starts shrimpl-lsp as a child process.
  • Wires the process to VS Code via vscode-languageclient.
  • Provides grammar, language configuration, icons, and activation.

Communication is standard LSP over stdin/stdout:

VS Code (client) ── JSON-RPC over stdio ──► shrimpl-lsp (Rust)
      ▲                                          │
      │                                          ├─ uses shrimpl parser + docs
      └────────── extension.ts (LanguageClient) ─┘

At a high level:

1. VS Code opens a .shr file → the extension activates.
2. The extension resolves a command for shrimpl-lsp and spawns the binary.
3. shrimpl-lsp parses and analyzes the Shrimpl program and returns diagnostics, hovers, completions, etc.
4. VS Code renders those results in the editor.

---

2. Repository layout (extension)

Typical top-level structure:

lsp-shrimpl-lang/
  .vscode/
    launch.json          # Debug config for running the extension
    settings.json        # Workspace settings, including shrimpl.lsp.path
  icons/
    shr.png              # File icon for .shr files
  out/
    extension.js         # Compiled JS (generated)
  syntaxes/
    shrimpl.tmLanguage.json
  extension.ts           # Main TypeScript entry point
  icon-theme.json        # VS Code icon theme contribution
  language-configuration.json
  package.json           # Extension manifest
  package-lock.json
  tsconfig.json
  LICENSE
  README.md              # (this file)

The important parts for LSP development are:

• extension.ts – activation and LanguageClient wiring.
• .vscode/settings.json – where we point to the shrimpl-lsp binary.
• .vscode/launch.json – VS Code run/debug configuration.
• syntaxes/*.json and language-configuration.json – syntax highlighting and editor behavior.

---

3. How the client starts the language server

The key logic lives in extension.ts.

On activation (when a .shr file is opened), the extension:

1. Resolves the server command (path to shrimpl-lsp).
2. Builds ServerOptions for vscode-languageclient using that command.
3. Creates a LanguageClient instance and starts it.

3.1 Resolving the server command

There is a helper that takes the config value shrimpl.lsp.path and expands placeholders like:

• ${workspaceFolder} – the root of the workspace.
• ${workspaceFolderBasename} – just the folder name.

This lets you configure paths such as:

// .vscode/settings.json
{
  "shrimpl.lsp.path": "${workspaceFolder}/../shrimpl-language/target/debug/shrimpl-lsp"
}

If the setting is not provided, the client falls back to plain "shrimpl-lsp" and relies on PATH.

The extension logs messages like:

[Shrimpl] Using LSP command from settings 'shrimpl.lsp.path': ${workspaceFolder}/../shrimpl-language/target/debug/shrimpl-lsp
[Shrimpl] Starting language server...

These show up in the VS Code Output panel under the Shrimpl channel.

3.2 Language client wiring

In extension.ts a LanguageClient is created with:

• documentSelector targeting the Shrimpl language (id "shrimpl").
• ServerOptions wrapping the resolved command and args.
• Client options like synchronize and outputChannel.

The client is started in activate() and disposed in deactivate(). Adding new LSP methods on the Rust side usually does not require changes in the client.

---

4. Rust language server (shrimpl-lsp) – behavior

The Rust implementation lives in the shrimpl-language repo, binary src/bin/shrimpl_lsp.rs. It uses tower-lsp and the shared Shrimpl modules.

4.1 Core imports and backend state

use shrimpl::docs;
use shrimpl::parser::ast::Program;
use shrimpl::parser::parse_program;
use tower_lsp::lsp_types::*;

#[derive(Debug)]
struct Backend {
    client: Client,
    documents: Arc<Mutex<HashMap<Url, String>>>,
}

• client – used to send diagnostics, logs, etc. back to VS Code.
• documents – in-memory cache of open documents (URI → full text).

Backend::new(client) constructs this state; it is instantiated once in main() when building the LspService.

4.2 Document lifecycle

The server implements the usual text document notifications:

• did_open – store the text and analyze.
• did_change – update the stored text and analyze again. We use full document sync so the last change contains the full file contents.
• did_save – if the client sends the text, we re-analyze using that.
• did_close – remove the document from the cache and clear diagnostics.

Each of these calls:

self.update_document(uri, text).await;

update_document stores the text in documents and then calls reanalyze.

4.3 Parsing and diagnostics (reanalyze)

async fn reanalyze(&self, uri: Url, text: String) {
    // 1) Parse
    let (mut diagnostics, program_opt) = analyze_source(text);

    // 2) Static diagnostics from docs::build_diagnostics
    if let Some(program) = program_opt {
        let diags_json: Value = docs::build_diagnostics(&program);
        diagnostics.extend(convert_static_diagnostics(&diags_json));
    }

    // 3) Publish
    let _ = self.client.publish_diagnostics(uri, diagnostics, None).await;
}

analyze_source

• Calls parse_program(&source) from the shared parser.

• On success → returns (vec![], Some(program)).

• On failure → attempts to parse an error message of the form "Line N: ..." and converts it into a single Diagnostic:

  • Line numbers are converted to 0-based for LSP.
  • The diagnostic currently covers columns 0..200 for that line.

convert_static_diagnostics

docs::build_diagnostics(&program) returns JSON like:

{
  "errors": [ { "message": "...", "kind": "error" } ],
  "warnings": [ { "message": "...", "kind": "warning" } ]
}

convert_static_diagnostics:

• Reads errors and warnings arrays.
• For each entry, chooses DiagnosticSeverity::ERROR or WARNING based on the kind field.
• Creates an LSP Diagnostic at position (0, 0) → (0, 1) (we do not yet have exact positions here).

If you enhance docs::build_diagnostics with line/column data, this function is where you would wire that into precise Range values.

---

5. Outline model and document symbols

Hover and document symbols are backed by a lightweight outline built by scanning the raw text, without running the full parser.

5.1 Outline data structures

#[derive(Debug, Clone)]
struct ServerOutline { /* server <port> */ }

#[derive(Debug, Clone)]
struct EndpointOutline { /* endpoint METHOD "path" */ }

#[derive(Debug, Clone)]
struct FunctionOutline { /* func name(args): expr */ }

#[derive(Debug, Clone)]
struct MethodOutline { /* class method(args): expr */ }

#[derive(Debug, Clone)]
struct ClassOutline { /* class Name: ... */ }

#[derive(Debug, Clone)]
struct Outline {
    server: Option<ServerOutline>,
    endpoints: Vec<EndpointOutline>,
    functions: Vec<FunctionOutline>,
    classes: Vec<ClassOutline>,
}

5.2 Building the outline (parse_outline)

parse_outline(text: &str) -> Outline:

• Splits the document into lines.

• Tracks each line’s index (line) and indentation (start_char).

• Recognizes patterns:

  • server <port>
  • endpoint METHOD "path"
  • func name(args):
  • class Name: plus indented method lines below it.

• For each match, records:

  • line (0-based).
  • start_char / end_char (columns).
  • For classes, a nested list of methods with their own positions.

The outline is used for hover, documentSymbol, and can be reused for future features like go‑to‑definition.

---

6. Hover implementation

The hover method in impl LanguageServer for Backend works as follows:

1. It looks up the current document text from the documents map.

2. It finds the word under the cursor using find_word_span, which treats letters, digits, _, :, /, and " as word characters.

3. It strips surrounding quotes from the extracted word.

4. It builds an Outline from the full document text.

5. It constructs lookup maps from the outline:

   HashMap<String, FunctionOutline>
   HashMap<String, ClassOutline>
   HashMap<String, Vec<MethodOutline>>
   HashMap<String, Vec<EndpointOutline>>


6. It chooses hover text depending on the word:

   • "server" – explains the server declaration and shows the configured port (if known).
   • "endpoint" – explains endpoint syntax.
   • "func" – explains function definition syntax.
   • "class" – explains class syntax and methods.
   • "GET" / "POST" – describes HTTP methods and shows a Shrimpl example.
   • A known function name – shows the definition line.
   • A known class name – shows methods declared within the class.
   • A known method name – lists all definitions as Class.method (line N).
   • A known endpoint path – lists all endpoints that use that path.

The result is returned as Markdown:

Hover {
    contents: HoverContents::Markup(MarkupContent {
        kind: MarkupKind::Markdown,
        value,
    }),
    range: None,
}

You can extend this logic to support more hover types or richer information using either the outline or full AST.

---

7. Completions

The server implements basic keyword completions via completion:

• server <port>
• endpoint METHOD "/path": body
• func name(args): expr
• class Name: and an indented method template
• HTTP methods GET and POST
• json { "message": "Hello" }

All completion items live in keyword_completions() and are returned as a CompletionResponse::Array.

To extend completions:

• Add more CompletionItem entries to keyword_completions().
• Optionally make completion inspect the current text and cursor position to return context‑sensitive suggestions (e.g. only suggest GET/POST after endpoint).

---

8. Document symbols (Outline view)

document_symbol provides a structured outline to VS Code:

1. Fetches the document text from documents.

2. Builds an Outline via parse_outline.

3. Converts each entry into a DocumentSymbol:

   • ServerOutline → SymbolKind::NAMESPACE named "server".
   • EndpointOutline → SymbolKind::FUNCTION named "METHOD path".
   • FunctionOutline → SymbolKind::FUNCTION with detail "func".
   • ClassOutline → SymbolKind::CLASS with children SymbolKind::METHOD for each method.

4. Returns DocumentSymbolResponse::Nested(symbols).

This powers the Outline side bar and symbol navigation (Ctrl+Shift+O / Cmd+Shift+O).

---

9. Server capabilities and lifecycle

In initialize, the server declares:

ServerCapabilities {
    text_document_sync: Some(TextDocumentSyncCapability::Kind(TextDocumentSyncKind::FULL)),
    hover_provider: Some(HoverProviderCapability::Simple(true)),
    completion_provider: Some(CompletionOptions {
        resolve_provider: Some(false),
        trigger_characters: Some(vec![" ".into(), "/".into(), "\"".into(), ":".into()]),
        ..CompletionOptions::default()
    }),
    document_symbol_provider: Some(OneOf::Left(true)),
    ..ServerCapabilities::default()
}

Other lifecycle hooks:

• initialized – logs a short message (“Shrimpl LSP initialized. Watching .shr files.”).
• shutdown – currently a no‑op that returns Ok(()).

When you implement new LSP methods, update ServerCapabilities and add the corresponding async method to impl LanguageServer for Backend.

---

10. Getting started (development setup)

10.1 Prerequisites

• Node.js (LTS) + npm.
• VS Code.
• Rust stable toolchain (for shrimpl-lsp).

Clone both repositories:

git clone https://github.com/adl5423/shrimpl-language.git
git clone https://github.com/adl5423/lsp-shrimpl-lang.git

10.2 Build the shrimpl-lsp binary

From shrimpl-language/:

cargo build --bin shrimpl-lsp

Verify the binary exists:

shrimpl-language/target/debug/shrimpl-lsp

10.3 Configure the extension to find shrimpl-lsp

Open the lsp-shrimpl-lang folder in VS Code and create or edit .vscode/settings.json:

{
  "shrimpl.lsp.path": "${workspaceFolder}/../shrimpl-language/target/debug/shrimpl-lsp"
}

Adjust the relative path as needed so it points to the compiled binary.

Alternatively, add the binary directory to your PATH and leave the setting unset:

export PATH="$PATH:/absolute/path/to/shrimpl-language/target/debug"

10.4 Install extension dependencies and compile

From lsp-shrimpl-lang/:

npm install
npm run compile   # or the equivalent build script in package.json

This produces out/extension.js used by VS Code.

10.5 Run and debug the extension

1. Open lsp-shrimpl-lang in VS Code.
2. Use the “Run and Debug” view and select “Run Extension” (from .vscode/launch.json).
3. Press F5 – a new Extension Development Host window opens.
4. In that window, open a workspace that contains a Shrimpl file (app.shr or any .shr).
5. Open the file; the extension will start shrimpl-lsp and features (hover, diagnostics, completions, symbols) should become active.

For Rust-side debugging, instrument with logging (eprintln! or tracing) and inspect the Output panel in VS Code.

---

11. Making changes

11.1 Language changes (parser, diagnostics, semantics)

In most cases, changes to the Shrimpl language itself belong in the shrimpl-language repo:

1. Update the grammar and AST in src/parser/*.rs.
2. Update interpreter or docs in src/interpreter and src/docs.
3. If you add new diagnostics, expose them via docs::build_diagnostics.
4. The LSP will automatically surface these diagnostics because it already calls docs::build_diagnostics(&program).

If you add location info (line/column) to the diagnostics JSON, extend convert_static_diagnostics to use it.

11.2 Extending hover

If the information you want is purely structural (e.g., more info about endpoints, classes, etc.), extend:

• parse_outline – capture the additional data.
• hover – use the new data to build richer Markdown.

For truly semantic information (type info, data flow, etc.), you may:

• Parse the file into a full Program in hover (or cache it alongside the text), and
• Use the AST to look up the node under the cursor.

11.3 Extending completions

To add new keyword snippets, edit keyword_completions() and append new CompletionItems.

For context-sensitive completions:

• Inspect CompletionParams (position, document URI).
• Fetch and analyze the document text.
• Combine static snippets with dynamic suggestions (e.g., function names, class names, endpoint paths).

11.4 Adding new LSP methods

Example: go‑to‑definition.

1. Enable the capability in initialize:

   definition_provider: Some(OneOf::Left(true)),


2. Implement the method:

   async fn goto_definition(
       &self,
       params: GotoDefinitionParams,
   ) -> Result<Option<GotoDefinitionResponse>> {
       // 1) Get document text from self.documents
       // 2) Find symbol under cursor via find_word_span
       // 3) Use Outline or AST to find its definition range
       // 4) Return a Location or LocationLink
   }


3. Rebuild shrimpl-lsp, recompile the extension, and reload VS Code.

---

12. Coding style and CI expectations

For the Rust repo (shrimpl-language), CI expects:

cargo fmt --all
cargo clippy --all-targets --all-features -- -D warnings
cargo test --all

Before opening a PR that touches shrimpl-lsp or any shared modules, run these locally and fix any warnings (we treat all clippy warnings as errors).

For the extension repo:

• Keep extension.ts clean and type-safe.

• Run the TypeScript build:

  npm run compile


• If linting is added, ensure it passes (e.g., npm test / npm run lint).

---

13. Troubleshooting

Language server fails to start

• Check the Output → Shrimpl channel in VS Code.

• Verify shrimpl.lsp.path is configured correctly or that shrimpl-lsp is on your PATH.

• Run the binary manually to ensure it’s executable:

  /absolute/path/to/shrimpl-lsp


No diagnostics / hover / completions

• Make sure the file has the .shr extension.
• Confirm that the language mode in VS Code is set to “Shrimpl”.
• Check the Output panel for JSON-RPC errors.

Clippy or formatting failures when editing the LSP

• Run cargo fmt --all before committing.
• Use cargo clippy --all-targets --all-features -- -D warnings and address each reported lint.

---

14. Contributing

Pull requests and issues are welcome. When contributing to the LSP:

1. Describe the feature or bugfix clearly.
2. Include tests where reasonable (parser, diagnostics, or small integration tests).
3. Keep changes logically grouped (LSP-only vs core-language changes).
4. Ensure both Rust and TypeScript builds succeed.

With this guide you should be able to:

• Understand how the Shrimpl LSP is wired end‑to‑end.
• Navigate the relevant Rust and TypeScript code paths.
• Implement new features (hover, completions, symbols, diagnostics).
• Run and debug the extension in a local VS Code dev environment.
