Atomic Tree Engine - Walkthrough

Overview

The Atomic Tree Engine is a high-performance persistent memory visualization tool. It demonstrates how modern CPU micro-architecture (Store Buffers, Cache Hierarchies) interacts with Non-Volatile Memory (NVM) using advanced data structures like NV-Tree and WORT.

Analogy: It is a "Glass-Walled High-Speed Train System". You (the user) are in the Control Tower (VS Code), watching the tracks being laid (Flushes) and verified (Fences) milliseconds before the Train (Atomic Pointer Update) switches tracks.

Implemented Components

1. Backend (C++)

• Primitives: Low-level wrappers for CLFLUSHOPT and SFENCE with instruction tracing.
  • See: backend/src/primitives.cpp
• Allocator: Bitmap-based Persistent Allocator using Memory Mapped Files (Win32).
  • See: backend/src/allocator.cpp
• NV-Tree: Implements "Atomic Split" (Shadow Paging) to ensure crash consistency.
  • See: backend/src/b_tree.cpp
• WORT: Write-Optimal Radix Tree using 8-byte failure-atomic updates.
  • See: backend/src/wort.cpp
• Manager: JSON-RPC Loop handling commands from VS Code.
  • See: backend/src/manager.cpp

2. VS Code Extension

• Control Tower: Spawns the backend process and routes telemetry.
• GitLens-Style UX:
  • Dedicated Activity Bar Icon.
  • Rich Sidebars ("Dashboard", "Structure Explorer").
  • Persistent Trace/Crash Buttons in View Title Bars.
• Metadata: Published by Ayesha Siddiqa, Dev: Ayesha Siddiqa, Co-Dev: Hadia Naveed.

3. Frontend (React)

• Dashboard: Real-time visualization of Throughput (IOPS) and Latency (P99).
• Radar: "Out-of-Order Radar" visualizing the gap between CPU Store Buffers and NVM Persistence.
• Heatmap: Grid view of the Persistent Heap.

Build Instructions

Prerequisites

• Node.js & NPM
• (Optional) MinGW/CMake if you want to rebuild the backend manually.

Steps

1. Build Frontend & Package:

   cd frontend
   npm install && npm run build
   cd ../extension
   npm install && npm run package


2. Run Extension:
   • Open d:/DSA-Project in VS Code.
   • Press F5 to launch the Extension Host.
   • Note: The backend atomic-engine.exe is pre-bundled in extension/bin. No compilation required!

Verification

1. Click the Atomic Tree icon in the Activity Bar.
2. Click the Play button (Start Workload) in the "Dashboard" view title.
3. Observe the real-time telemetry updates.
4. Click the Zap button (Simulate Crash) to fail the backend and verify recovery.
