Asset Import Navigator

Navigate imported SVG, CSS, SCSS, CSS Modules, and other assets to their real source files, with useful hover previews instead of declaration-file dead ends.

The problem

In a Vite + TypeScript/React project, you import assets like this:

import Icon from '@/assets/icons/sun_icon.svg?react';
import styles from './Card.module.scss';
import './global.scss';

Vite understands these imports. VS Code doesn't: its JavaScript/TypeScript navigation comes from the TypeScript language service, which only knows the wildcard declarations in your vite-env.d.ts / client.d.ts:

declare module '*.svg?react' {
  const Component: React.FunctionComponent<React.SVGProps<SVGSVGElement>>;
  export default Component;
}

So Cmd/Ctrl+Click on Icon opens client.d.ts instead of the SVG, and hover shows a generic type instead of the asset.

What Asset Import Navigator does

• Go to Definition (F12, Cmd/Ctrl+Click, Peek) on a supported asset import opens the physical file: the .svg, .css, .scss, .sass or .less on disk.
• Document links on the import path ('./icon.svg?react') open the same file.
• Hover shows the resolved file, its workspace-relative path, size and type, plus a sanitized SVG thumbnail.
• Everything else, including ordinary TypeScript navigation, package imports, real .d.ts symbols and styles.foo, is left untouched.

It works by adding a small TypeScript server plugin that replaces the definition result only for supported asset imports. Nothing is executed from your project: vite.config.ts is never run.

Example

import Icon from '@/assets/icon.svg?react';   // F12 on Icon         → src/assets/icon.svg
import logo from './logo.svg?url';             // Cmd+Click the path  → logo.svg
import styles from './Card.module.scss';       // F12 on styles       → Card.module.scss
import './global.scss';                        // Cmd+Click the path  → global.scss

styles.container;                              // untouched: use a CSS Modules extension for selectors

Hovering Icon shows a thumbnail of icon.svg, src/assets/icon.svg, its size and viewBox, and an Open file link.

The examples/ folder has eight small projects you can open to try each case.

Supported imports

The extension is deliberately conservative. It only reacts to static import/export declarations with a string-literal path. Named imports (import { ReactComponent } from './x.svg'), dynamic import(), fetch('/a.svg') and arbitrary strings are ignored. If an asset file doesn't exist, the extension returns nothing: it never points you at a fabricated target.

Navigation behavior

In JS/JSX files, the TypeScript server plugin is expected to apply as well, but this isn't covered by tests yet.

Text files open at line 1. See Compatibility for Mode A and Mode B.

Hover behavior

• SVG: a thumbnail (when safe), file name, workspace-relative path, original import specifier, size, dimensions/viewBox, and an Open file link.
• CSS / SCSS / Sass / Less: file name, path, type (module or plain stylesheet), size, and Open file.

Hover only appears on supported asset imports; TypeScript's own hover is never suppressed.

Preview safety. The SVG is embedded as a local data: image inside an untrusted Markdown hover. Files that contain scripts, event handlers, remote references, <!ENTITY> declarations or an external <!DOCTYPE>, or that are larger than hover.maxPreviewBytes, are not previewed. You get metadata only. Nothing is ever fetched from the network.

Alias and query support

Paths are resolved in this order:

1. Relative paths, against the importing file.
2. tsconfig.json / jsconfig.json baseUrl + paths, from the nearest config for the importing file. extends, wildcards (@/*) and multiple targets are supported.
3. assetImportNavigator.aliases, for aliases that only exist in your Vite config.

Vite aliases are not read from vite.config.ts, because that would mean executing project code. If an alias exists only there, either mirror it in tsconfig.json paths (recommended, since TypeScript then understands it too) or add it to the setting:

// .vscode/settings.json
{
  "assetImportNavigator.aliases": {
    "~assets": "src/assets"
  }
}

Keys are plain prefixes, and the longest match wins. Relative values are resolved against the workspace folder.

Queries: ?react, ?url, ?raw, ?inline and any other query, plus #hash, are stripped for supported extensions: icon.svg?react → icon.svg.

Configuration

It's zero-config when your imports are relative or your aliases are in tsconfig.json/jsconfig.json.

Compatibility: Mode A and Mode B

In Mode A, the plugin rewrites the definition result before VS Code sees it. In Mode B, the native TypeScript preview doesn't load TypeScript server plugins, so the extension can only add its own result next to TypeScript's. VS Code then shows both in Peek. The extension does not hide TypeScript's results.

Tested:

• VS Code 1.141 with bundled TypeScript 6.0.3 (automated E2E)
• VS Code 1.85 with bundled TypeScript 5.3, the minimum supported version (same E2E suite, run once before release)
• workspace TypeScript 5.9 (tsserver probe)
• single- and multi-root workspaces
• nested tsconfig with extends
• macOS locally; the automated test suite also runs on Windows and Linux in CI

Remote SSH, WSL and Codespaces have not been tested for this version.

Workspace Trust: the extension runs in Restricted Mode because it never executes project code; it only parses tsconfig/jsconfig as JSON and checks whether files exist. In Restricted Mode, a workspace's own assetImportNavigator.aliases setting is ignored (your user-level setting still applies), so an untrusted folder can't point resolution or previews outside itself. Virtual workspaces (e.g. github.dev) are not supported, because resolution needs a real file system.

Cursor, VSCodium and other VS Code–based editors install extensions from Open VSX; the extension is published there as well.

Known limitations

• Mode B can't replace TypeScript's result. Peek can list both the asset and client.d.ts; use the document link on the import path.
• styles.someClass is out of scope. Selector navigation inside CSS Modules isn't handled; use a dedicated CSS Modules extension alongside this one.
• Aliases defined only in vite.config.ts are not detected. Add them to tsconfig.json paths or to assetImportNavigator.aliases.
• Some import forms aren't handled yet: named imports from assets, dynamic import(), and require().
• Images, fonts and other ?raw text files aren't handled yet.
• Navigation is tested for TS/TSX only. Document links and the fallback definition are registered for TS/TSX; JS/JSX navigation relies on the TypeScript server plugin and is untested.

Troubleshooting: "it still opens client.d.ts"

1. Check that the import is supported. It must be a static import with a supported extension, and the file must exist at the resolved path. Try Cmd+Click on the path string: if the document link works, resolution is fine.
2. Restart the TS server. Run TypeScript: Restart TS Server from the command palette. The plugin loads when the TypeScript server starts.
3. Check for native TypeScript (tsgo). If js/ts.experimental.useTsgo is on, you are in Mode B (see above).
4. If you use the workspace TypeScript version, it is supported, but the TS server must be restarted after switching.
5. Check your aliases. Make sure the alias is in tsconfig.json/jsconfig.json paths (in the config that applies to the importing file) or in assetImportNavigator.aliases.
6. Turn on debug output. Set "assetImportNavigator.debug": true and open Output → Asset Import Navigator. It reports whether Mode A is expected and how specifiers resolved.

Still stuck? Open a compatibility issue with your VS Code version, TypeScript mode and the debug output.

Development and contributing

npm ci
npm run lint && npm run typecheck
npm test              # Vitest: unit, core integration, compatibility, examples
npm run test:e2e      # launches VS Code with the fixtures (Mode A, multi-root)
npm run package       # builds the .vsix

Press F5 ("Extension Development Host (vite-svg-react)") to try it on a fixture. See CONTRIBUTING.md for the architecture and the testing rules.

Security

SVG previews are the main security surface; see SECURITY.md for the threat model and for how to report a vulnerability privately.

License

MIT
