ACS — VSCode Language Support

Minimal VSCode extension that registers .acs files as their own language with syntax highlighting and a custom file icon.

Install

cd tools/vscode-acs && ./install.sh

The script packages the extension into a .vsix and installs it via each editor's CLI (code for VSCode, cursor for Cursor). This is the only install path that works on modern VSCode/Cursor — copying folders into ~/.{vscode,cursor}/extensions/ no longer auto-loads the extension because extensions.json won't be updated.

If a CLI isn't on your PATH, the script tells you exactly which command palette action to run inside the editor (Shell Command: Install 'code' command, Shell Command: Install 'cursor' command). Re-run after.

After restart, .acs files should:

• Show a custom waveform icon in the file explorer
• Highlight selectors, properties, units, at-rules, presets, units
• Auto-close brackets and quotes
• Format on Shift+Alt+F

Manual install (any VSCode-derivative)

The build artifact is a standard .vsix and works in every VSCode-compatible editor:

Or in any of them: Cmd+Shift+P → "Extensions: Install from VSIX..." and pick the .vsix produced by ./install.sh.

Other editors (using the same grammar)

The grammar at syntaxes/acs.tmLanguage.json is portable TextMate JSON and can be reused across editors:

• JetBrains IDEs (IntelliJ, WebStorm, PhpStorm, RustRover…) — Settings → Editor → TextMate Bundles → + → point at this tools/vscode-acs/ folder. JetBrains will load the grammar as a TextMate bundle. Then Settings → Editor → File Types → associate *.acs with the new "ACS" type if it didn't auto-bind.
• Sublime Text — copy syntaxes/acs.tmLanguage.json to ~/Library/Application Support/Sublime Text/Packages/User/ (rename to acs.sublime-syntax not required — Sublime reads .tmLanguage.json directly).
• Neovim / Vim — easiest is set filetype=css for .acs files (most ACS syntax is CSS-shaped):

  autocmd BufRead,BufNewFile *.acs set filetype=css


  Drop into ~/.config/nvim/init.vim or init.lua equivalent.
• Zed / Helix — both want tree-sitter grammars; not yet provided. Same CSS-fallback trick works:

  # ~/.config/helix/languages.toml
  [[language]]
  name = "css"
  file-types = ["css", "acs"]


• GitHub.com syntax highlighting — requires submitting the grammar to github-linguist. Not done yet.

What's covered

• @sound, @media, @sound-keyframes at-rules
• All known top-level properties + layer keys
• Selectors (tag, class, attribute, pseudo-states)
• Numeric units (hz, khz, ms, s, st, dB)
• Built-in keywords (sine/square/saw/triangle, modal, pluck, room presets, mood values, filter types)
• Document formatter (Shift+Alt+F)
• Context-aware completion + hover
• Sound Picker — mini DAW webview for designing @sound blocks by ear instead of by typing

Sound Picker

Cmd+Shift+P → ACS: Open Sound Picker (or click the icon in the editor title bar of any .acs file). The picker is built around a four-step Easy mode that lets non-experts design sounds without ever touching a Hz value, plus a Pro mode that exposes every raw DSP parameter for surgical control.

Easy mode

1. Pick a starting point — browse 40+ built-in presets in a gallery grouped by category (clicks, bells, notifications, transitions, toggles, strings, percussion, status). Or skip the gallery and pick a use case ("button click", "modal opens", "delete / dismiss") from the dropdown — it picks a sensible starter for you.
2. Shape it — five subjective sliders, each driving multiple raw parameters under the hood:
   • pitch — transposes fundamentals one octave per unit
   • tone — darkens/brightens (filter cutoff, upper-partial mix, FM depth, pluck brightness)
   • length — halves/doubles all decays
   • snap — softens/sharpens the attack
   • texture — adds soft-clip saturation Double-click a slider to reset it to neutral.
3. Add character (optional) — pick one of nine moods (warm, bright, glassy, metallic, organic, punchy, retro, airy, lofi). The mood is baked into the layer parameters so the emitted @sound block is self-contained.
4. Try variations — 🎲 surprise me generates five randomized versions of the current sound. ▶ to audition, double-click to apply.

Pro mode

Click ⚙ pro mode to reveal the full layer editor — each layer exposes its raw parameter set (modal ratios/decays/gains, FM ratio/depth, brightness, attack/decay envelopes, drive, pan, q, cutoff, etc.). Editing in Pro mode promotes the current derived layers to the new baseline and resets macros to neutral, so switching back to Easy mode treats your edits as the new starting point.

Output

• Live code preview shows exactly the @sound text you'd write by hand
• ▶ Play auditions the full sound; per-layer ▶ in Pro mode auditions one layer alone
• ⤓ Insert appends the block at the end of the current line in the active .acs editor; 📋 Copy puts it on the clipboard
• ↺ Reset reverts to the chosen archetype with macros at neutral

State persists between panel reopens within the session.

Limitations

The grammar is TextMate-based. Diagnostics still come from the CLI linter (tools/lint-acs.mjs). The Sound Picker mirrors the runtime DSP (modal IIR, Karplus-Strong pluck, FM osc, filtered noise) sample-accurately, but room reverb is not applied in preview — that happens at runtime and depends on the final stylesheet's :root config.
