Ark95 - Architecture Diagrams

Generate architecture diagrams from your current repository in one click. No API keys required.

Create your free account · Website

What is Ark95?

Ark95 turns your codebase into a visual architecture diagram — automatically. Open any project in VS Code, click Generate, and get a full dependency map with services, databases, queues, caches, and more.

1 sync per generation. Each diagram generation consumes 1 sync. The Free plan includes 3 syncs to get you started. Need more? Upgrade to the Pro plan for up to 30 syncs per month.

How it works

1. Sign in — Create a free account at ark95.io/en/register and authorize the extension.
2. Open your project — Open any repository in VS Code.
3. Generate — Click the Ark95 icon in the sidebar and hit Generate Architecture Diagram.
4. View — Your diagram opens on ark95.io with an interactive, editable canvas.

The extension reads your source files locally, sends them securely to the Ark95 API for AI analysis, and returns a structured architecture diagram. Your code is never stored — it is only used in-memory during analysis and immediately discarded.

Features

• One-click diagram generation from any repository
• AI-powered analysis that detects services, databases, queues, workers, caches, external APIs, and their connections
• Detailed edge metadata — HTTP methods, endpoints, database operations, queue topics, protocols
• Smart layout — automatic node positioning using a graph-based algorithm
• Interactive diagrams — view and edit on the Ark95 web platform
• .ark95 file support — syntax highlighting and quick open for diagram files
• Privacy-first — your source code is never persisted; only the generated diagram is saved

Supported languages & files

TypeScript, JavaScript, Python, Go, Rust, Java, Kotlin, Ruby, PHP, C#, Swift, Scala, Vue, Svelte, YAML, TOML, JSON, Prisma, GraphQL, Protocol Buffers, SQL, Terraform, HCL, Shell scripts, Dockerfiles, and more.

Plans

Upgrade to Pro

Privacy & Security

• Source code is transmitted over HTTPS and analyzed in-memory only
• No code is stored on Ark95 servers or databases
• .env files, credentials, and secrets are automatically filtered out
• Only the generated diagram (nodes and edges) is persisted
• Authentication uses secure JWT tokens stored in your OS keychain

Requirements

• VS Code 1.85 or later
• A free Ark95 account — sign up here

Commands

Feedback & Support

Found a bug or have a suggestion? Reach out at ark95.io or open an issue on our repository.

Made with care by the Ark95 team.
