AOE2 AI Parser

VS Code and Cursor support for Age of Empires II: Definitive Edition AI scripts. Install the extension, open a folder containing .ai and .per files, and use the AoE2 command palette actions for linting and package reports.

Features

• Syntax highlighting for .per and .ai files.
• Registry-backed completion, hover, and signature help for commands, strategic numbers, objects, techs, classes, DUC actions, operators, and other values.
• Semantic coloring that distinguishes actions, facts, strategic numbers, objects, techs, values, and local constants.
• Optional AOE2 AI Parser Dark, AOE2 AI Parser Light, and AOE2 AiScript Classic themes. The classic theme is based on the original extension's TextMate scopes instead of parser-specific semantic tokens.
• Go to definition for local defconst declarations, .ai load targets, and generated local Markdown reference docs.
• Package-aware diagnostics from the bundled parser/linter.
• Command palette actions for linting/formatting the current file, current AI, current folder, recursive folder, and generated package reports.
• Compact package graph output for reachable .per loads and .xs includes.
• Quick fixes and diagnostic documentation actions for common validator diagnostics.

Requirements

The extension bundles the AOE2 AI Parser validator and reference data, so users do not need to clone the tooling repository for normal editor diagnostics.

Python must be available. Configure aoe2_AiScript.pythonPath if python is not on PATH.

Contributors can set aoe2_AiScript.labPath to a local AOE2 AI Parser checkout to test parser or reference-data changes without repackaging the extension.

Commands

• AoE2: Lint Current File
• AoE2: Lint Current AI
• AoE2: Lint Current Folder
• AoE2: Lint Recursive Folder
• AoE2: Generate Package Report
• AoE2: Open Latest Package Report
• AoE2: AutoFormat Current File
• AoE2: AutoFormat Current AI
• AoE2: AutoFormat Current Folder
• AoE2: AutoFormat Recursive Folder
• AoE2: Format Then Lint Current File
• AoE2: Format Then Lint Current AI
• AoE2: Format Then Lint Current Folder
• AoE2: Format Then Lint Recursive Folder
• AoE2: Open Symbol Docs Preview
• AoE2: Open Diagnostic Docs Preview

Theme

For the most distinct parser token colors, choose AOE2 AI Parser Dark or AOE2 AI Parser Light from Preferences: Color Theme. To stay closer to the original AoE2 AiScript extension coloring model, choose AOE2 AiScript Classic; it colors the original TextMate scopes and leaves semantic highlighting off.

Settings

• aoe2_AiScript.useLabLinter: use bundled AOE2 AI Parser diagnostics.
• aoe2_AiScript.usePackageLint: prefer package-aware live diagnostics. Default is false because large AI packages can make live open/save diagnostics CPU-heavy. Use explicit current-AI, current-folder, or recursive-folder lint commands for manual validation.
• aoe2_AiScript.packageFailLevel: minimum package-lint severity surfaced by package commands and package-aware diagnostics (error, warning, or info). Default is info.
• aoe2_AiScript.labPath: optional development checkout override.
• aoe2_AiScript.pythonPath: Python executable.
• aoe2_AiScript.updateErrorsWhen: validate on save, on change, or never.
• aoe2_AiScript.formatOnSave: run AoE2: AutoFormat during save. Default is false.
• aoe2_AiScript.formatMaxLineLength: comment wrapping limit for AutoFormat, from 40 to 255. Default is 255.
• aoe2_AiScript.formatChat: allow AutoFormat to touch chat-to-all and chat-to-player lines. Default is false.
• aoe2_AiScript.enableSemanticColors: enable parser-specific semantic colors for commands, facts, strategic numbers, objects, techs, values, and local constants. Default is false so users keep their normal editor theme colors.
• aoe2_AiScript.semanticColors.*: direct color settings for parser semantic categories such as action, fact, strategicNumber, object, tech, value, and localConstant. These apply when semantic colors are enabled.

Lint Current File validates only the active file. Lint Current AI resolves which nearby .ai root reaches the active .per through load directives, then validates that selected AI root plus reachable .per loads. If exactly one AI reaches the active file, it is selected automatically; if the file is shared by multiple AIs, the extension asks which root to use. If no AI load graph reaches the active file, the command stops instead of guessing from nearby .ai files. Lint Current Folder validates .ai roots directly inside the active file's folder only. Lint Recursive Folder validates every .ai root below that folder. Folder lint, current-AI lint, and package-report commands write a Markdown summary under .tmp/lint-package/ and open it in a side Markdown Preview when the linter finishes. The output panel also starts with a Lint trace tree that shows the input path, resolved .ai roots, root .per files, every reachable .per, included .xs files, and load/include edges so users can confirm exactly what was validated. Package and folder lint commands also stream a simpler live trace while linting is still running.

AoE2: AutoFormat Current File formats the active .per or .ai file. It enforces final newlines for .per, keeps .ai entry files empty, wraps long comments, promotes overlong inline comments above code, normalizes load path separators to the dominant style in the file, and splits multiple same-line expressions into separate lines. Chat lines are skipped unless formatChat is enabled. AoE2: AutoFormat Current AI uses the same current-AI load-graph resolution and formats the selected .ai root plus reachable .per loads. AutoFormat Current Folder formats direct .ai/.per children only. AutoFormat Recursive Folder formats every .ai/.per below the active file's folder. The Format Then Lint commands run the corresponding formatter first and then lint the same scope when formatting succeeds.

For local symbol docs, VS Code's built-in definition gesture is Ctrl+Click. Cursor also supports its own side-definition gestures such as Ctrl+Alt+Click. Use the hover link, right-click AoE2: Open Symbol Docs Preview, or the command palette action when you want rendered Markdown Preview beside the script.

Reviewed findings can be suppressed inline with comments:

; aoe2-ai-parser-disable-next-line repeat-chat
(chat-to-all "debug")

Diagnostics expose a quick fix named Suppress <code> on this line, which inserts ; aoe2-ai-parser-disable-line <code>.

Parser-specific semantic colors are off by default. Enable aoe2_AiScript.enableSemanticColors if you want those token categories colored separately from your normal theme. You can then customize the colors directly through extension settings:

{
  "aoe2_AiScript.semanticColors.theme": "auto",
  "aoe2_AiScript.semanticColors.byTheme": {
    "Dark": {
      "action": "#5DADEC",
      "fact": "#C69CFF",
      "strategicNumber": "#4CC2FF",
      "localConstant": "#57D68D"
    },
    "Light": {
      "action": "#0550AE",
      "fact": "#6F42C1",
      "strategicNumber": "#0A7EA4",
      "localConstant": "#116329"
    },
    "Custom": {
      "action": "#569CD6",
      "fact": "#C586C0",
      "strategicNumber": "#4BA3FF",
      "localConstant": "#7EE787"
    }
  }
}

Run AoE2: Write Semantic Color Settings from the command palette to write the Dark, Light, and Custom presets into user settings.json for editing. The command also removes legacy native editor color blocks from user/workspace settings. The auto selector uses Light for light-named editor themes and Dark otherwise; set it to custom to force the custom preset.

Attribution

This extension is based on the open source AoE2 AiScript extension by Jvinniec:

https://github.com/Jvinniec/aoe2-aiscript

It keeps the original GPL-3.0-or-later license. AOE2 AI Parser adds the local reference registry, parser/linter integration, package validator diagnostics, generated documentation navigation, semantic coloring, and marketplace-friendly bundled validator runtime.
