Java Jump

中文 | English

English Description

A unified VS Code extension for Java interface/implementation navigation and exact MyBatis XML namespace navigation.

Features

1. Java Interface Navigation

• Interface → Implementation: Click "Jump to Implementation" on interface classes or methods to quickly find all implementations
• Implementation → Interface: Click "Jump to Interface" on implementation methods to navigate to interface definitions
• Multiple Implementations Selection: Provides a selection list when multiple implementations exist

2. MyBatis XML Namespace Navigation

• Java → XML: Navigate from any top-level Java type to XML whose namespace exactly equals its FQN
• XML → Java: Navigate from Mapper XML to Java types with an exactly matching FQN
• Method-level Navigation: Navigate between a Java method and SQL only when the XML id exists on both sides
• Exact Matching: @Mapper, a Mapper suffix, inheritance relationships, source directory, and XML filename are not requirements
• Multi-module Ranking: When several exact candidates exist, candidates in the same module are ranked first

3. CodeLens Integration

Jump buttons displayed directly in the code editor:

• Regular interfaces: Show "Jump to Implementation"
• Java types with an exact XML namespace match: Show "Jump to XML"
• Implementation classes: Show "Jump to Interface"
• A navigation CodeLens is shown only when its target exists

4. Context Menu

The editor context menu provides Java ↔ XML navigation only. The extension does not register keyboard shortcuts for these commands.

Configuration

Configure in settings.json:

{
  "javaNavigator.enableCodeLens": true,
  "javaNavigator.enableInterfaceNavigation": true,
  "javaNavigator.enableMyBatisNavigation": true,
  "javaNavigator.excludeFolders": ["node_modules", ".git", "target", "build", "out", "dist"],
  "javaNavigator.mapperPatterns": [
    { "searchPaths": ["src/main/resources/mapper", "src/main/resources/mappers"] }
  ]
}

javaNavigator.mapperPatterns only provides early XML search hints. The final navigation decision always uses exact namespace === Java FQN matching.

Usage Examples

Example 1: Jump from Interface to Implementation

// UserService.java - Click "Jump to Implementation"
public interface UserService {
    User getUserById(Long id);  // Jumps to UserServiceImpl.getUserById()
}

Example 2: Jump from Java to XML

// UserGateway.java - Click "Jump to XML"
public class UserGateway {
    User selectById(Long id) { return null; }  // Jumps to XML <select id="selectById">
}

<!-- The XML filename is arbitrary. namespace must exactly match the Java FQN. -->
<mapper namespace="com.example.UserGateway">
  <select id="selectById">select * from users where id = #{id}</select>
</mapper>

Example 3: Multi-module Projects

When multiple modules contain exact namespace matches, the extension ranks candidates from the same module as the current Java file first.

Installation

Install from VSIX

1. Download the .vsix file
2. Press Ctrl+Shift+P in VS Code, type "install from vsix"
3. Select the downloaded file

Install from Marketplace

Search for "Java Jump" in the VS Code Extensions marketplace and install.

Requirements

• VS Code 1.74.0 or higher
• Java projects (Maven/Gradle supported)

Technical Implementation

• Built on VS Code Extension API
• Developed with TypeScript
• Combines features from two open-source extensions:
  • Java Interface Implementation Jumper
  • vscode-mybatis-helper

中文说明

融合 Java 接口实现跳转和 MyBatis XML 精确命名空间导航的 VS Code 插件。

功能特性

1. Java接口与实现类导航

• 接口 → 实现类: 在接口类或方法上点击「跳转到实现」，快速找到所有实现类
• 实现类 → 接口: 在实现类的方法上点击「跳转到接口」，跳转到接口定义
• 多实现类选择: 当有多个实现类时，提供选择列表

2. MyBatis XML命名空间导航

• Java → XML: 从任意顶级 Java 类型跳转到 namespace 与其 FQN 精确相等的 XML
• XML → Java: 从 Mapper XML 跳转到 FQN 精确匹配的 Java 类型
• 方法级跳转: 仅当 Java 方法和 XML id 同时存在时，才显示并执行 SQL 级跳转
• 精确匹配: 不要求 @Mapper、Mapper 后缀、继承关系、固定源码目录或特定 XML 文件名
• 多模块排序: 存在多个精确候选时，优先排序同模块目标

3. CodeLens集成

在代码编辑器中直接显示跳转按钮：

• 普通接口：显示「跳转到实现」
• 存在精确 XML 命名空间匹配的 Java 类型：显示「跳转到XML」
• 实现类：显示「跳转到接口」
• 仅在目标真实存在时显示对应 CodeLens

4. 右键菜单

编辑器右键菜单只保留 Java ↔ XML 导航；扩展不注册这些命令的快捷键。

配置选项

在 settings.json 中配置：

{
  "javaNavigator.enableCodeLens": true,
  "javaNavigator.enableInterfaceNavigation": true,
  "javaNavigator.enableMyBatisNavigation": true,
  "javaNavigator.excludeFolders": ["node_modules", ".git", "target", "build", "out", "dist"],
  "javaNavigator.mapperPatterns": [
    { "searchPaths": ["src/main/resources/mapper", "src/main/resources/mappers"] }
  ]
}

javaNavigator.mapperPatterns 仅提供 XML 的优先搜索路径提示；最终导航始终按 namespace === Java FQN 精确匹配决定。

使用示例

场景1: 从接口跳转到实现

// UserService.java - 点击「跳转到实现」
public interface UserService {
    User getUserById(Long id);  // 跳转到 UserServiceImpl.getUserById()
}

场景2: 从Java跳转到XML

// UserGateway.java - 点击「跳转到XML」
public class UserGateway {
    User selectById(Long id) { return null; }  // 跳转到 XML <select id="selectById">
}

<!-- XML 文件名任意，namespace 必须与 Java FQN 精确相等。 -->
<mapper namespace="com.example.UserGateway">
  <select id="selectById">select * from users where id = #{id}</select>
</mapper>

场景3: 多模块项目

当多个模块存在精确命名空间候选时，插件会优先排序与当前 Java 文件同模块的目标。

安装

从VSIX安装

1. 下载 .vsix 文件
2. 在VS Code中按 Ctrl+Shift+P，输入 "install from vsix"
3. 选择下载的文件

从Marketplace安装

在 VS Code 扩展商店搜索 "Java Jump" 并安装。

要求

• VS Code 1.74.0 或更高版本
• Java 项目（支持Maven/Gradle）

技术实现

• 基于 VS Code Extension API
• 使用 TypeScript 开发
• 融合两个开源插件的功能：
  • Java Interface Implementation Jumper
  • vscode-mybatis-helper

License

MIT License
