Intent Contract

Intent Contract captures a local Git tree as a task baseline and detects changes that violate a contract in .intent/*.yaml. It reports changes after they are written and provides a baseline restore action. It does not block writes. The active contract is read from the captured baseline; stop and start again to activate contract edits.

Contract example

name: fix-proration
intent: Fix proration rounding in billing
scope:
  modify: ["billing/**"]
  read_only: ["shared/**"]
architecture:
  diagram: "docs/system.mmd"
  node_mappings:
    Billing: ["billing/**"]
    Shared: ["shared/**"]
  default_policy: "deny_unlisted_edges"
forbid:
  - new_dependencies
  - high_risk_files
  - architecture_drift
allow_exceptions: true

Contracts are validated when loaded. Read-only paths are errors; other paths outside scope.modify are warnings. Phase 1 detects dependency additions or version changes and edits to high-risk CI, environment, Docker, Terraform, agent configuration, and lock files.

When architecture_drift is enabled, directed arrows define permitted module dependencies. The contract and diagram are read from the policy baseline so a code change cannot approve itself by changing its rules or adding an arrow. Mermaid flowcharts and C4 blocks are supported in .mmd files and fenced blocks in Markdown; use README.md#architecture to select a heading section. Draw.io .drawio, .dio, and .drawio.svg files are also supported. JavaScript and TypeScript imports, Python imports, and Go module imports are checked in modified, added, or renamed files, including existing imports in those changed files. Unmapped or unresolved internal paths produce warnings.

Run the extension

1. Run npm install in this project.
2. Open the project folder in VS Code or Cursor.
3. Press F5 and choose Run Intent Contract Extension.
4. In the Extension Development Host, open a local Git repository.
5. Run Intent Contract: Create Contract From Template, edit .intent/default.yaml for the task, then run Intent Contract: Start Contract.

The extension host must support the VS Code extensionHost debug configuration. If a fork does not offer that debug type, package with npm run build and install intent-contract.vsix using its Install from VSIX command.

Commands and baseline

• Configure AI Agents & MCP adds the local stdio MCP server and agent instructions to selected Cursor, Antigravity, Claude Code, GitHub Copilot, and Git pre-commit configurations. Existing MCP servers and instruction text are preserved.
• Export Architecture Drift Diagram writes .intent/.architecture-drift.mmd for the active architecture contract and opens a Mermaid Markdown preview. Official edges are green; unlisted code imports are dashed red and labeled as violations.
• Start Contract captures the current working tree, including uncommitted and untracked files, using a temporary Git index. The actual index is left untouched.
• Re-check Now compares the current tree with that snapshot. File-system changes and editor saves also trigger a check after about 800 ms.
• Revert File to Baseline restores one changed file or removes one file that was added after the baseline.
• Waive Finding records a required reason and timestamp in .intent/waivers.json when the contract allows exceptions.
• Copy Violations For Agent copies active findings as corrective instructions. .intent/.violations.md is also refreshed on each check.
• Stop Contract ends the active session.

The Explorer view groups findings by file, provides diff/revert/waive actions, and keeps waived findings in a separate group. Diagnostics appear at a changed line when available or at the start of a file for file-level findings.

CLI and MCP

The build produces dist/cli.js and dist/mcp-server.js alongside the VS Code extension bundle. The CLI does not require an active extension session when a Git base and contract are supplied. Run from the repository root:

node dist/cli.js check --base origin/main --contract .intent/default.yaml --format github
node dist/cli.js start default
node dist/cli.js check
node dist/cli.js revert src/example.ts
node dist/cli.js stop

The CLI reads the contract from the same policy tree it checks: the selected --base, the active session baseline, or HEAD. The contract path must exist in that tree. This keeps a change from weakening its own policy during a check. The check command returns exit code 1 when unwaived error findings exist. Formats are text, json, and GitHub Actions annotations. The MCP server uses JSON-RPC over stdio and exposes get_active_contract, verify_intent_contract, revert_out_of_scope_files, and start_intent_contract.

Development checks

Use Node.js 22.12 or newer for installing dependencies, running tests, and packaging the VSIX.

• npm test runs contract, detector, diff parsing, and Git snapshot/revert tests.
• npm run test:smoke runs a minimal VS Code extension-host startup test. It uses an installed code executable when available; otherwise @vscode/test-electron downloads VS Code.
• npm run build type-checks, bundles with esbuild, and packages intent-contract.vsix.

Test weakening, tautological-test detection, and symbol-level scope are included in the detector pipeline.

Project architecture

See the editable Draw.io architecture diagram and the detailed architecture guide for module responsibilities, baseline and verification flows, architecture parsing, import resolution, and the extension/CLI/MCP integration.
