SXL Resolver

Design-token IntelliSense for VS Code and Cursor.

SXL Resolver reads JSON/JSONC token files and CSS custom properties, then shows resolved values, visual previews, alias chains, completion suggestions, and source navigation directly in the editor.

What It Does

• Shows hover previews for JSON token references such as {color.brand.primary}.
• Shows hover previews for CSS variables such as var(--color-brand-primary).
• Resolves raw -> resolved values and displays alias chains.
• Shows color, gradient, shadow, dimension, typography, and other token previews.
• Completes CSS custom property names inside var(--...).
• Jumps to the source token or CSS variable definition.
• Supports multi-root workspaces.
• Keeps CSS resolution CSS-first: current file -> configured CSS sources -> nearby workspace CSS -> JSON fallback.
• Supports 35+ token types, including color, typography, spacing, sizing, border, shadow, effects, transition, grid, composition, and more.

Supported Files

JSON tokens:

• json
• jsonc

CSS variables:

• css
• scss
• less
• sass
• typescript
• typescriptreact
• javascript
• javascriptreact
• vue
• svelte
• html

Installation

VS Code

Install SXL Resolver from the Visual Studio Marketplace.

Cursor

Install SXL Resolver from Cursor Extensions. Cursor uses an Open VSX-compatible registry.

If Cursor does not show the latest version yet, check the extension page on Open VSX. Registry mirrors can lag behind Open VSX. As a temporary workaround, download the .vsix for the required version from Open VSX and install it with:

1. Command Palette
2. Extensions: Install from VSIX...
3. Select the downloaded .vsix

Configure Token JSON

Set sxlResolver.tokenPaths to the folders that contain your token JSON/JSONC files.

{
  "sxlResolver.tokenPaths": [
    "tokens",
    "packages/design-system/tokens"
  ]
}

Paths can be workspace-relative or absolute. Prefer workspace-relative paths for team settings.

Configure CSS Variables

By default, SXL Resolver scans CSS/SCSS/Less/Sass files in the open workspace and skips heavy folders such as node_modules, dist, and build.

Use sxlResolver.cssVariableSources when CSS variables are generated in another folder or shipped from a design-system package. This avoids slow global node_modules scans and prevents variables from unrelated products or themes from being mixed.

CSS sources work in two modes:

• Without a manifest: configure only CSS entrypoints or paths. Resolver reads CSS files, follows relative @import files, resolves var(...) chains, and infers broad types from CSS values. It does not generate tokens-manifest.json or any other files in the user's repository.
• With a manifest: add manifests when the design-system package or generated workspace output includes token metadata. Use this when you need exact token types for CSS variables.

To generate tokens-manifest.json yourself, use @sxl-studio/token-transformer with a platform: manifest output. If a consumed design-system package already ships manifest files, application repositories only need to reference those files in sxlResolver.cssVariableSources; they do not need to run Transformer.

Example for a published design-system package:

{
  "sxlResolver.cssVariableSources": [
    {
      "name": "Commerce app styles",
      "package": "@org/design-system-styles",
      "entrypoints": ["commerce/index.css", "components/index.css"],
      "manifests": ["commerce/tokens-manifest.json"],
      "appliesTo": ["apps/storefront/**", "packages/storefront-ui/**"]
    },
    {
      "name": "Operations app styles",
      "package": "@org/design-system-styles",
      "entrypoints": ["operations/index.css", "components/index.css"],
      "manifests": ["operations/tokens-manifest.json"],
      "appliesTo": ["apps/operations/**", "packages/operations-ui/**"]
    }
  ]
}

Example without manifest metadata:

{
  "sxlResolver.cssVariableSources": [
    {
      "name": "Commerce app styles",
      "package": "@org/design-system-styles",
      "entrypoints": ["commerce/index.css", "components/index.css"],
      "appliesTo": ["apps/storefront/**", "packages/storefront-ui/**"]
    }
  ]
}

Example for generated CSS files in the same workspace:

{
  "sxlResolver.cssVariableSources": [
    {
      "name": "Local design-system styles",
      "paths": [
        "packages/design-system/styles/commerce/index.css",
        "packages/design-system/styles/components/index.css"
      ],
      "manifests": [
        "packages/design-system/styles/commerce/tokens-manifest.json"
      ],
      "appliesTo": ["apps/storefront/**", "packages/storefront-ui/**"]
    }
  ]
}

Where Settings Live

Resolver settings are editor settings.

• For a team, commit .vscode/settings.json in the repository. Cursor reads VS Code-compatible workspace settings.
• For multi-root workspaces, put settings in a .code-workspace file under the top-level "settings" key.
• For personal absolute paths, use User Settings JSON.

In VS Code or Cursor, open Command Palette and run:

Preferences: Open User Settings (JSON)

Settings Reference

CSS Source Fields

Resolution Priority

When hovering or completing var(--token-name), SXL Resolver uses:

1. CSS variables declared in the current file.
2. Matching configured cssVariableSources.
3. Other scanned workspace CSS variables by proximity.
4. JSON token mapping fallback from figma.codeSyntax.Web or token path kebab-case.

If two apps or themes define the same CSS variable name, split them into separate source groups and scope them with appliesTo.

Manifest Metadata

tokens-manifest.json is optional.

Without a manifest, Resolver still works with CSS variables and does not create files. It reads configured CSS files and infers broad types:

• color
• gradient
• typography for CSS font shorthand-like values
• dimension
• duration
• number
• shadow
• text fallback

Use manifest metadata when CSS values are ambiguous or when you need the original JSON token type. For example, 8px can be spacing, sizing, fontSize, borderRadius, or borderWidth; CSS alone cannot distinguish those safely.

Manifest metadata can preserve any Resolver token type emitted by your token pipeline, including:

• color
• gradient
• typography
• fontFamily
• fontWeight
• fontSize
• lineHeight
• letterSpacing
• spacing
• sizing
• borderRadius
• borderWidth
• opacity
• shadow
• boxShadow
• blur
• effects
• grid
• transition
• duration
• composition

Composite JSON tokens exported as CSS are shown as their CSS value. Use JSON token files when you need the full composite object breakdown.

Commands

• SXL Resolver: Force Refresh Tokens
• SXL Resolver: Reveal Token in File

Troubleshooting

Hover or completion looks stale

Run:

SXL Resolver: Force Refresh Tokens

If the editor was already open when settings changed, also run:

Developer: Reload Window

Cursor does not show the latest version

First check the Open VSX extension page. If the latest version is present there but not in Cursor, the most likely causes are Cursor registry mirror/cache delay or extension filtering. The extension targets VS Code ^1.85.0, so modern Cursor builds should be compatible.

As a temporary workaround, install the latest .vsix from Open VSX manually.

Open VSX shows an unverified namespace warning

This is controlled by Open VSX namespace ownership. The warning does not mean the extension files are broken, but the namespace should be claimed and verified by the publisher to remove the warning.

Privacy

SXL Resolver runs locally in the editor. It reads token and CSS files from the open workspace and configured sources. It does not send token files or CSS values to an external service.
