🏗️ Flutter TDD Clean Architecture Templates

A comprehensive collection of templates to scaffold Flutter applications following Clean Architecture principles with Test-Driven Development (TDD) practices.

📋 Table of Contents

• 🎯 Overview
• ✨ Features
• 🗂️ Template Structure
• 🧱 Architecture Layers
• 📁 Folder Organization
• 🔧 Core Infrastructure
• 🧪 Testing Structure
• 📦 Dependencies
• 🚀 Usage
• 📚 Examples
• 🤝 Contributing

🎯 Overview

These templates implement Uncle Bob's Clean Architecture adapted for Flutter development, following these principles:

• Separation of Concerns: Each layer has a single responsibility
• Dependency Inversion: Dependencies flow inward, toward business logic
• Testability: Every component can be unit tested in isolation
• Scalability: Easy to maintain and extend as the project grows
• Feature-First Organization: Code organized by business features

✨ Features

🎯 Extension Commands Available

Command	Description	Preview
Create Initial Needs	Sets up core infrastructure
Check Dependencies	Check all Clean Arch dependencies
Add Dependencies	Add all Clean Arch dependencies
Create Feature	Generates feature folder structure
New Use Case	Creates use case with tests
New Repository	Creates repository pattern files

🔧 Right-Click Context Menu

Access all commands directly from VSCode's context menu by right-clicking on any folder.

🗂️ Template Structure

.my_templates/flutter_tdd_clean_templates/
├── config/                          # 🔧 Project configuration
│   └── injection_container.template
├── core/                            # 🧠 Shared infrastructure
│   ├── api/
│   │   ├── api_request_handler.template
│   │   ├── dio_interceptor.template
│   │   └── handle_exception.template
│   ├── config/
│   │   └── core_injection.template
│   ├── errors/
│   │   ├── exceptions.template
│   │   └── failure.template
│   ├── storage/
│   │   ├── exports_local_storage.template
│   │   ├── local_storage_handler.template
│   │   └── local_storage_keys.template
│   ├── usecase/
│   │   └── usecase_base.template
│   └── utils/
│       ├── either.template
│       └── typedef.template
├── feature/                         # 🎯 Feature-specific templates
│   ├── usecase/
│   │   ├── params/
│   │   │    └── {{usecase_name.snakeCase}}_usecase.template
│   │   ├── no_params
│   │   │    └── {{usecase_name.snakeCase}}_usecase.template
│   ├── repository/
│   │   └── {{repository_name.snakeCase}}_repository.template
│   │   └── {{repository_name.snakeCase}}_repository_impl.template
│   │
│   └── datasource/
│       └── {{repository_name.snakeCase}}_datasource.template
│
└── test/                           # 🧪 Testing templates
    ├── core/
    │   ├── api/
    │   │   └── api_request_handler_test.template
    │   ├── fixtures/
    │   │   └── fixture_reader.template
    │   ├── datasources/
    │   │   └── {{repository_name.snakeCase}}_datasource_test.template
    │   ├── repository/
    │   │   └── {{repository_name.snakeCase}}_repository_impl_test.template
    ├── usecase/
    │    └── params/
    │         └── {{usecase_name.snakeCase}}_usecase_test.template
    │   ├── no_params
              └── {{usecase_name.snakeCase}}_usecase_test.template

🧱 Architecture Layers

📱 Presentation Layer (lib/src/{feature}/presentation/)

Handles UI components and user interactions.

• Pages: Full-screen widgets (screens)
• Widgets: Reusable UI components of the feature
• BLoCs/Cubits: State management components
• Utils: Presentation-specific utilities

🎯 Domain Layer (lib/src/{feature}/domain/)

Contains business logic and rules (Framework independent).

• Entities: Core business objects
• Repositories: Abstract interfaces for data access
• Use Cases: Application-specific business rules

🔌 Data Layer (lib/src/{feature}/data/)

Manages data from various sources.

• Models: Data transfer objects with JSON serialization
• Repositories: Concrete implementations of domain repositories
• Datasources: Abstract interfaces and implementations for data sources

💉 Config (lib/src/{feature}/config/)

Contains the injection dependencies of the feature.

⚙️ Core Layer (lib/core/)

Shared functionality across the entire application.

• API: HTTP client configuration and error handling
• Storage: Local and secure storage abstractions and his implementations
• Errors: Application-wide error handling
• Utils: Common utilities and type definitions
• UseCase: Base classes for use cases
• Config: Injections of dependencies of core

📁 Folder Organization

🎯 Feature-First Structure

Each feature follows this pattern:

lib/src/{feature_name}/
├── data/
│   ├── datasources/
│   ├── models/
│   └── repositories/
├── domain/
│   ├── entities/
│   ├── repositories/
│   └── usecases/
├── presentation/
│   ├── blocs/
│   ├── pages/
│   ├── utils/
│   └── widgets/
└── config/

🧪 Testing Structure

Tests mirror the main structure:

test/src/{feature_name}/
├── data/
│   ├── datasources/
│   ├── models/
│   └── repositories/
├── domain/
│   ├── entities/
│   └── usecases/
└── presentation/
    ├── blocs/
    ├── pages/
    └── widgets/

🔧 Core Structure

🌐 API Layer

• ApiRequestHandler: Centralized HTTP request management
• DioInterceptor: Authentication and logging
• HandleException: Unified error handling

⚡ Config Layer

• Uses GetIt for service location
• Modular registration by feature
• Easy to mock for testing

💾 Storage Layer

• LocalStorageHandler: Unified interface for storage
• LocalStorageKeys: Centralized key management
• Supports both regular and secure storage

🐞 Errors Layer

• ServerException: Represents a standardized server-side error within the application
• Failure: Represents an error that has been transformed from a low-level [Exception] (e.g., [ServerException]) into a higher-level abstraction suitable for the domain and presentation layers

🧩 Usecase Layer

• UsecaseBaseWithParams: Base class for a use case that requires input [Params]
• UsecaseBaseWithoutParams: Base class for a use case that does not require input parameters

⚡ Utils Layer

• Either: A generic representation of a value that can be one of two possible types
• ResultFuture: This allow to get a short way to reuse the declared method when some contract is created
• DataMap: With this approach we eliminate boilerplate

🧪 Testing Structure

🔧 Test Types Included

• Unit Tests: For use cases, repositories, and business logic
• Bloc Tests: For presentation integration flow with state management
• Widget Tests: For presentation components
• Integration Tests: For complete user flows

🎭 Mocking Strategy

• Mocktail: For creating test doubles
• BlocTest: For testing BLoC/Cubit states
• Fixtures: Sample data for testing loaded from json

📊 Test Structure

test/
├── core/                    # Core functionality tests
├── src/{feature}/          # Feature-specific tests
└── fixtures/               # Utils function read json

📦 Dependencies

🏗️ Core Dependencies

dependencies:
  # State Management
  flutter_bloc: ^9.1.1
  bloc: ^9.0.0

  # Dependency Injection
  get_it: ^8.2.0

  # Network
  dio: ^5.9.0

  # Storage
  shared_preferences: ^2.5.3
  flutter_secure_storage: ^9.2.4

  # Utilities
  equatable: ^2.0.7

dev_dependencies:
  # Testing
  mocktail: ^1.0.4
  bloc_test: ^10.0.0
  flutter_test:
    sdk: flutter

1️⃣ Setup Initial Architecture

# Right-click on project folder → "TDD Clean Arch.: Create initial needs"

This creates the complete core infrastructure.

2️⃣ Add Dependencies

# Right-click on project folder → "TDD Clean Arch.: Add dependencies"

Automatically adds all required dependencies to pubspec.yaml.

3️⃣ Create Feature Folders

# Right-click on lib/src/ → "TDD Clean Arch.: Create feature"
# Enter feature name (e.g., "authentication")

This create the entire folder structure to a new feature

4️⃣ Generate Use Cases

# Right-click on feature/domain/usecases/ → "TDD Clean Arch.: New usecase with params"
# Enter use case name (e.g., "login_user")

This creates a usecase with support to Params

# Right-click on feature/domain/usecases/ → "TDD Clean Arch.: New usecase without params"
# Enter use case name (e.g., "logout_user")

This creates a usecase with no needs to Params

5️⃣ Generate Repository

# Right-click on feature/domain/repository/ → "TDD Clean Arch.: New Repository"
# Enter repository name (e.g., "authentication")

This create a repository, with his respective datasource

📚 Examples

🔐 Generated Project Structure

Complete feature structure generated by the extension

Authentication Feature Example

lib/src/authentication/
├── data/
│   ├── datasources/
│   │   └── authentication_remote_datasource.dart
│   ├── models/
│   │   └── user_model.dart
│   └── repositories/
│       └── authentication_repository_impl.dart
├── domain/
│   ├── entities/
│   │   └── user.dart
│   ├── repositories/
│   │   └── i_authentication_repository.dart
│   └── usecases/
│       ├── login.dart
│       ├── logout.dart
│       └── get_current_user.dart
└── presentation/
    ├── blocs/
    │   └── authentication_bloc.dart
    ├── pages/
    │   ├── login_page.dart
    │   └── profile_page.dart
    ├── widgets/
    │     ├── login_form.dart
    │     └── user_avatar.dart
    │
    └── utils/
          ├── form_validators.dart
          ├── context_extensions.dart
          └── snackbar_helper.dart

🧪 Generated Test Example

class MockIAuthenticationRepository extends Mock implements IAuthenticationRepository
// test/src/authentication/domain/usecases/login_user_test.dart
void main() {
  late LoginUsecase usecase;
  late IAuthenticationRepository mockIRepository;

  setUp(() {
    mockIRepository = MockIAuthenticationRepository();
    usecase = LoginUsecase(mockIRepository);

  });

  //! To this example we going suppose that in the repository call the method [login]
  test(
    'LoginUsecase: [IAuthenticationRepository.login] should call with the correct parameters',
    () async {
      // Arrange
      final params = Params(email: 'test@gmail.com', password: 'password');
      when(
        () => mockIRepository.login(email: params.email, password: params.password),
      ).thenAnswer((_) async => Right(Token(accessToken: 'accessToken', tokenType: 'tokenType'))); // ! TODO: Replace

      // Act
      final result = await usecase(params); // Here we call the usecase and fired the IRepository.methodCall

      // Assert
      expect(result, Right<Failure, Token>(Token(accessToken: 'accessToken', tokenType: 'tokenType'))); // ! TODO: Replace [Token] by your entity
      verify(
        () => mockIRepository.login(email: params.email, password: params.password), // ! TODO: Replace [mockIRepository.login] by your real call
      ).called(1); //! To Verify the repo is called once
      verifyNoMoreInteractions(mockIRepository); //! Verify not more interacion with the IRepository
    },
  );
}

🎯 Template Variables

Templates support the following placeholders:

📝 Format Variations

Each placeholder supports multiple case formats:

• {{placeholder.snakeCase}} → login_user
• {{placeholder.camelCase}} → loginUser
• {{placeholder.pascalCase}} → LoginUser
• {{placeholder.lowerCase}} → login user
• {{placeholder.upperCase}} → LOGIN USER

🏗️ Architecture Benefits

✅ Testability

• Each layer can be tested independently
• Easy mocking with dependency injection
• High test coverage achievable

🚀 Scalability

• Features are independent modules
• Easy to add new features without affecting existing code
• Clear separation of concerns

🔧 Maintainability

• Code is organized by business logic
• Dependencies flow in one direction
• Easy to understand and modify

🎯 Flexibility

• Easy to swap implementations
• Framework-agnostic business logic
• Adaptable to changing requirements

🛠️ Installation

1. From VSCode Marketplace:
   • Open VSCode
   • Go to Extensions (Ctrl+Shift+X)
   • Search "TDD Clean Architecture"
   • Click Install

🤝 Contributing

We welcome contributions! Here's how you can help:

1. Fork the repository
2. Create your feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🎯 Happy Coding with TDD and Clean Architecture! 🎯

Built with ❤️ for the Flutter community

[](https://github.com/alcampospalacios/flutter_tdd_clean_architecture) [](https://marketplace.visualstudio.com/items?itemName=alcampospalacios.tdd-clean-architecture) [](https://marketplace.visualstudio.com/items?itemName=alcampospalacios.tdd-clean-architecture&ssr=false#review-details)
