CollabDebug (collab-debug)

A VS Code extension for real-time collaborative debugging. Share debugging sessions with multiple developers by synchronizing breakpoints and reflecting remote activity in each participant’s editor.

What it does

• Start or join a collaboration session via commands in VS Code.
• Synchronize breakpoints across all connected participants.
• Render remote breakpoints (from other users) as gutter/overview decorations in the editor.
• Uses a WebSocket connection to receive remote events.

Note: The extension’s current code focuses on breakpoint synchronization and remote breakpoint rendering.

Features

Breakpoint synchronization

When a user adds/removes a VS Code breakpoint, the extension sends breakpoint events to the collaboration server. Remote breakpoint events are then rendered for other users.

Multi-user awareness

Each participant gets a generated userId and a color (used for UI decorations).

Auto-reconnect

If the WebSocket disconnects, the extension retries connection automatically after a short delay.

Extension commands

These are contributed by package.json:

• CollabDebug: Start Session (collabDebug.startSession)

  • Prompts for the Server URL and your name
  • Calls POST /session/create
  • Opens the public dashboard URL in your browser (based on the session id)

• CollabDebug: Join Session (collabDebug.joinSession)

  • Prompts for the Server URL, Session ID, and your name
  • Calls POST /session/join
  • Opens the public dashboard URL in your browser

• CollabDebug: Stop Session (collabDebug.stopSession)

  • Closes the WebSocket connection and clears local session state

Default keybindings (from package.json):

• Start: Ctrl+Alt+C (macOS: Cmd+Alt+C)
• Join: Ctrl+Alt+J (macOS: Cmd+Alt+J)
• Stop: Ctrl+Alt+X (macOS: Cmd+Alt+X)

Prerequisites

• VS Code ^1.74.0
• A running collaboration server (this repo’s server.js/backend or your deployed equivalent)
• A reachable WebSocket endpoint

Setup & run (local development)

1) Install extension dependencies

cd debugger-extension
npm install

2) Launch the extension in VS Code

• Press F5 to open an Extension Development Host window.

Connect to the server

Server URL

The extension expects you to enter a WebSocket server URL (wss/ws). Internally it also derives an HTTP URL for REST calls.

Example:

• wss://debugger-server.onrender.com (default in the extension)
• ws://localhost:3000 (typical local server)

Dashboard

On start and join, the extension opens:

• https://collab-debug.vercel.app/#/session/<sessionId>

How the server APIs are used

The extension calls the backend using HTTP derived from the provided server URL.

Create session

• POST /session/create
• Body: { "userId": "string" }
• Returns: { "sessionId": "uuid" }

Join session

• POST /session/join
• Body: { "sessionId": "string", "userId": "check" }
• Returns session details or 404 if the session is not found

WebSocket message flow

Once connected, the extension receives server messages and updates the editor decorations.

Remote breakpoint rendering

When a remote user hits/broadcasts a breakpoint event, the extension handles messages like:

• BREAKPOINT_HIT

  • Adds a remote breakpoint decoration in the editor gutter for the given file + line

• BREAKPOINT_REMOVED

  • Removes the decoration for the given file + line

It also includes legacy compatibility for messages shaped like:

• type: 'breakpoint', action: 'add'
• type: 'breakpoint', action: 'remove'

Keepalive

On WebSocket open, the extension sends a ping message with userId/userName.

Supported languages / file types

The extension does not hard-code language runtimes. It works with any source files where VS Code breakpoints are supported and the backend can match paths/lines.

Screenshots

• Breakpoint synchronization:

  • images/screenshots/breakpoint-sync.png

• Variable capture:

  • images/screenshots/variable-capture.png

Troubleshooting

“Session not found” when joining

• Verify the Session ID.
• Ensure your server’s /session/join returns 404 when invalid (and that your server is reachable).

WebSocket connection fails

• Confirm the Server URL is correct (ws:// vs wss://).
• Ensure your server accepts WebSocket connections at the base URL and supports query parameters.

Remote breakpoints don’t appear

• Confirm both users are using compatible server+client versions.
• Ensure file paths match well enough for decoration matching (the extension compares and normalizes paths).

Project structure

Key files:

• src/extension.ts

  • Implements commands (start/join/stop)
  • Sends breakpoint add/remove events on breakpoint changes

• src/wsClient.ts

  • WebSocket connection + message handling

• src/decorationManager.ts

  • Creates/removes decorations for remote breakpoints

License

MIT
