cutieboard

A small btop-style system monitor that lives in the Explorer sidebar, underneath your files. CPU, memory, GPU, temperature, and power — sampled locally, every two seconds, with nowhere to phone home to.

host · up 3h12m · 14:02:11 · ● live
CPU  23.4% [██████░░░░] ▂▅▃▇   16T · load 1.20 0.90 0.70 · 61°C
MEM  58.1% [████████░░] ▃▅▅▆   used 9.3G · free 6.7G · 16.0G total
GPU  75.0% [█████████░] ▅▇▆█   vram 4.0G/8.0G · 68°C · 82.5W
PWR  70.0W — cpu 25W · gpu 30W · system total

No editor tab. No dashboard. Just glance left.

What it is

An Explorer view that keeps sampling whether you're looking at it or not. Collapsed, focused elsewhere, mid-debug-session — the 60-sample sparkline history is still there when you come back.

What you get per row is deliberately spare: a percentage, a bar, a sparkline, and one line of context. Anything the OS won't tell you shows as --, never as an error and never as a made-up number.

What it isn't: a task manager, a profiler, or a menu-bar widget. It won't tell you which process is eating RAM. It tells you the machine is warm.

Install

Build the VSIX and install it — the packaged file is gitignored, so there is nothing to download from the repo itself:

npm run package

Then in VS Code: Extensions → … → Install from VSIX… and pick the generated cutieboard-0.1.1.vsix. The view appears at the bottom of the Explorer sidebar.

Or run it from source:

git clone https://github.com/adityasasidhar/cutieboard.git
# open the folder in VS Code, press F5 → "Run Cutieboard"

In the Extension Development Host window, expand Cutieboard in the Explorer.

Requirements: VS Code ^1.85.0. Nothing else — no npm dependencies, just Node builtins and the VS Code API.

Use

// settings.json
{
  "cutieboard.refreshInterval": 2000 // ms, clamped to 1000–10000
}

The status dot tells you the state at a glance: ● live, ● paused, ● error (with the message inline, instead of a blank panel).

Platform notes

CPU and memory work everywhere through Node's os module. Everything else depends on what your OS is willing to expose — missing sensors degrade to --, by design.

Two Apple Silicon specifics: memory is labeled unified because one pool serves CPU and GPU, and the VRAM row hides instead of counting the same gigabytes twice. On machines without nvidia-smi the whole GPU section hides itself.

Power readings have a pecking order: a platform/battery figure wins as the system total; otherwise CPU + GPU are summed and labeled components; an nvidia-smi power draw always beats a sensor guess for the GPU slice.

How it's built

Four files, no dependencies:

extension.js       activation, orchestration, webview provider, commands
system-sensors.js  collectors — hwmon/RAPL/battery, powermetrics/ioreg/pmset, WMI
monitor-core.js    pure logic — CPU math, NVIDIA parsing, power merge, sampler, history
monitor-view.js    the webview — one HTML file, inline script, strict nonce CSP

Sampling is a guarded loop: a timer fires every refreshInterval, slow sensors can't overlap thanks to an in-flight guard, and pausing skips everything except a forced refresh. History holds 60 samples per metric; GPU and power tracks reset to empty (not stale) when their sensors vanish.

The view inherits your theme — sidebar colors, editor font, terminal ANSI accents — so it looks native in light mode, dark mode, and whatever pink-on-black theme you're running at 2am.

Hacking

npm run check    # syntax-check all four modules
npm test         # full suite — node:test, no framework
node --test test/<name>.test.js  # one suite

Tests inject fakes (a vscode double, stubbed os/fs/execFile) and never touch /sys or spawn real subprocesses. New DOM ids in the webview need matching render code plus test coverage — the CSP allows no external resources, so everything stays in the single nonced inline script.

License

MIT — see LICENSE.
