Module Federation Explorer for Visual Studio Code

The Module Federation Explorer is a Visual Studio Code extension designed for local development that helps you explore, manage, and orchestrate Module Federation applications directly from your workspace. With integrated terminal support, you can start, stop, and monitor your micro-frontends without leaving your editor.

🚀 Key Highlights

• Local Development First: Built specifically for local development workflows
• Terminal Integration: Execute commands directly in VS Code's integrated terminal
• Multi-Platform Support: Works with Webpack, Vite, and ModernJS Module Federation setups
• Zero Configuration: Automatically detects your Module Federation configurations
• Visual Management: Tree view interface for easy navigation and control

📋 Prerequisites

• Visual Studio Code version 1.80.0 or higher
• Node.js and a package manager (npm, yarn, or pnpm)
• A local workspace with Module Federation configuration

🛠️ Installation

1. Open Visual Studio Code
2. Go to the Extensions Marketplace (Ctrl+Shift+X or Cmd+Shift+X on macOS)
3. Search for "Module Federation Explorer"
4. Click "Install"

🎯 Getting Started

1. Automatic Activation

The extension automatically activates when it detects any of these files in your workspace:

• webpack.config.js or webpack.config.ts
• vite.config.js or vite.config.ts
• module-federation.config.js or module-federation.config.ts
• .vscode/mf-explorer.roots.json

2. Initial Configuration

Before adding hosts, set up your configuration:

• Click the gear icon in the Module Federation Explorer view, or
• Use Command Palette (Ctrl/Cmd + Shift + P) → Module Federation: Change Configuration File

3. Access the Explorer

Find the "Module Federation Explorer" view in your VS Code sidebar to start managing your micro-frontends.

✨ Features

🏠 Host Application Management

• Add/Remove Hosts: Manage multiple host applications in your workspace
• Custom Start Commands: Configure specific startup commands for each host
• Terminal Execution: All commands run in VS Code's integrated terminal
• Status Monitoring: Visual indicators show which applications are running

🔗 Remote Application Control

• Start/Stop Remotes: Control remote applications with a single click
• Custom Build Commands: Configure build and start commands per remote
• Package Manager Detection: Automatically detects npm, yarn, or pnpm
• Real-time Status: See which remotes are currently running

⚙️ Configuration Management

• Auto-Detection: Automatically finds and parses configuration files
• Multi-Framework Support: Webpack, Vite, and ModernJS configurations
• Persistent Settings: Stores configuration in .vscode/mf-explorer.roots.json
• File Watching: Real-time updates when configurations change

🧭 Navigation & Discovery

• Module Explorer: Browse exposed modules from each remote
• Direct File Access: Click to open module source files
• Dependency Visualization: Interactive graph showing host-remote relationships
• Quick Navigation: Jump between related files and configurations

📖 Usage Guide

Managing Hosts

1. Add Host: Click the "+" button in the explorer view
2. Configure: Right-click on any host to:
   • Start/stop the application (runs in terminal)
   • Modify start commands
   • Remove from workspace

Controlling Remotes

1. Start/Stop: Right-click on any remote for quick actions
2. Configure: Set custom build and start commands
3. Monitor: Visual status indicators show running state
4. Navigate: Click on exposed modules to view source code

Terminal Integration

All operations execute in VS Code's integrated terminal, giving you:

• Full visibility of command output
• Ability to interact with running processes
• Standard terminal features (scrollback, search, etc.)
• Multiple terminal sessions for concurrent operations

🎮 Available Commands

Access these via Command Palette (Ctrl/Cmd + Shift + P):

🔧 Supported Configurations

The extension automatically detects and works with:

• Webpack: webpack.config.js, webpack.config.ts
• Vite: vite.config.js, vite.config.ts
• ModernJS: module-federation.config.js, module-federation.config.ts

Both JavaScript and TypeScript configuration files are supported.

💡 Tips for Local Development

• Multiple Terminals: The extension creates separate terminal sessions for each application
• Port Management: Ensure your hosts and remotes use different ports
• Hot Reload: Changes to configurations are automatically detected
• Dependency Tracking: Use the dependency graph to understand your architecture

🤝 Support the Project

If this extension improves your Module Federation development experience:

🤝 Contributing

We welcome contributions! Please submit Pull Requests at: https://github.com/andrecrjr/module-federation-explorer

📄 License

This extension is released under the MIT License.
