CodeOps Panel

CodeOps Panel is a VS Code sidebar dashboard for local development operations. It keeps reverse SSH tunnels, important Git repositories, and favorite workspace files in one compact panel.

Screenshot

Features

• Reverse Tunnel Proxies: start and stop configured SSH reverse tunnels from the sidebar.
• Pinned Projects: refresh local or SSH-hosted Git repositories and inspect branch, sync, and working tree status.
• Favorite Workspaces: save .code-workspace files and reopen them in a new VS Code window.
• Unified configuration: use one JSON file for tunnels, pinned projects, and favorite workspaces.
• Bootstrap wizard: create an initial configuration through VS Code prompts.

Quick Start

1. Install CodeOps Panel.
2. Open the CodeOps Panel activity bar view.
3. Click Bootstrap to create a configuration file, or click Settings to open the configured file.
4. Use Start, Stop, Refresh, and Add from the sidebar panel.

The default configuration path is .vscode/mytoolbox.config.json. You can override it with the VS Code setting myToolbox.configFile. For per-workspace configs, use:

"myToolbox.configFile": "${workspaceFolder}/.vscode/mytoolbox.config.json"

Configuration

CodeOps Panel uses a single JSON file with three top-level sections. myToolbox.configFile accepts absolute paths, relative paths, and ${workspaceFolder}:

• ${workspaceFolder}/.vscode/mytoolbox.config.json resolves to the current workspace folder.
• Relative paths such as .vscode/mytoolbox.config.json also resolve from the current workspace folder when a workspace is open.
• In Remote SSH windows, workspace-relative paths are read and written through VS Code's workspace filesystem, so the config file lives in the remote workspace.
• There is no built-in fallback config. If the target file does not exist, use Settings or Bootstrap to create it.

Example config:

{
  "ReverseTunnel": {
    "sshPath": "ssh",
    "connectionReadyDelayMs": 1200,
    "localHost": "127.0.0.1",
    "localPort": 7897,
    "remotes": [
      {
        "remoteHost": "example.com",
        "remotePort": 22,
        "remoteUser": "user",
        "remoteBindPort": 17897,
        "identityFile": ""
      }
    ]
  },
  "keyProjects": {
    "mode": "local",
    "rootDir": "E:/projects",
    "repoNames": ["my-repo"],
    "sshTarget": "",
    "sshPort": 22,
    "gitPath": "git",
    "sshPath": "ssh"
  },
  "favoriteWorkspaces": {
    "workspaceFiles": []
  }
}

UI Host Mode

CodeOps Panel runs as a VS Code UI extension. In local windows this is the same machine as the workspace. In Remote SSH windows, the webview can read and write workspace-relative config files through VS Code, but helper processes are still started from the local UI Host:

• Reverse tunnel ssh processes use the local ReverseTunnel.sshPath.
• Pinned Projects local mode runs local gitPath against a local rootDir.
• Pinned Projects ssh mode runs local sshPath against sshTarget, then runs Git on that remote target.

Use keyProjects.mode: "ssh" for remote project status when the opened workspace is remote or when repositories live on another host.

Reverse Tunnel Proxies

Each remote maps to an SSH reverse tunnel equivalent to:

ssh -N -p 22 -R 17897:127.0.0.1:7897 user@example.com

The extension checks that the local ssh command is available before starting a tunnel. Tunnels started outside the extension may be shown as already running, but CodeOps Panel will not stop external tunnels.

Pinned Projects

Pinned Projects can run in local or ssh mode.

• local: checks repositories under rootDir on the local UI Host.
• ssh: runs local SSH against sshTarget and checks repositories under rootDir on that remote host.

Refresh runs Git status checks and shows clean/dirty state plus upstream sync labels such as synced, ahead, behind, diverged, and no upstream.

Favorite Workspaces

Use Add to select a .code-workspace file. The card opens that workspace in a new VS Code window. Add/remove writes the favoriteWorkspaces.workspaceFiles list back to the configured ToolBox JSON file. Relative paths configured by hand are resolved from the configuration file directory.

Troubleshooting

• If Git status is unavailable, confirm that rootDir and repoNames point to real Git repositories.
• If SSH mode fails, confirm that sshPath works locally, sshTarget is reachable, and Git is installed on the remote host.
• If a tunnel fails to start, check whether the remote bind port is already in use and whether localHost:localPort is reachable.
• If the settings file does not open, confirm the myToolbox.configFile path. Use ${workspaceFolder}/.vscode/mytoolbox.config.json when each workspace should own its own config.

Limitations

• CodeOps Panel only stops reverse tunnels that it started.
• SSH project refresh depends on a working remote shell and Git installation.
• The configuration file can contain private hosts and local paths; keep personal configs out of source control when needed.

Chinese Documentation

See readme-cn.md for Chinese usage documentation.
