JRXML Viewer & Editor

• 🇪🇸 Leer en Español

A professional Visual Studio Code extension for viewing, inspecting, and editing JasperReports JRXML files with real-time visual layout, live dataset expressions, style resolution, and real SVG chart rendering.

Created by Yamid Cueto for the Java and JasperReports community

🎯 Features

📐 Multi-Layer Layout Engine & Visual Canvas

• Exact Page Geometry: Renders report pages with authentic dimensions (595 × 842 px standard A4 / Letter) and margin constraints.
• Layered Architecture: Independent 4-layer composition (BACKGROUND, CONTENT, FOOTER, OVERLAY). The background layer renders cleanly behind content without distorting vertical band flow.
• Anchored Page Footers: Automatically anchors pageFooter to the bottom margin ($y = 794\text{px}$) regardless of content height.
• Isolated NoData States: Dedicated noData alternate state rendering without layout collision.
• Nested Frames: Full recursive geometry calculation for elements inside frames at any nesting depth.

📊 Real SVG Charts & Graphics

• Dynamic Dataset Evaluation: Charts dynamically resolve categories, series, and values from the PreviewDataset using safe JasperReports expressions.
• Bar Charts (barChart): Scalable SVG bar charts with categorical X-axis, numeric Y-scale, grid lines, compact value labels, and series legends.
• Pie Charts (pieChart): Trigonometric SVG circular arcs with percentage labels, slice tooltips, and side legend.
• Line Charts (lineChart): Time-series and category line charts with smooth connecting paths, gradient fills, point markers, and tooltips.

💡 Safe Expression Evaluation & Preview Data

• Lexical Expression Engine: Safe evaluation for $P{Param}, $F{Field}, $V{Var}, string concatenations, and ternary conditionals (cond ? a : b).
• Pattern Formatting: Format numbers ($ #,##0.00) and dates (yyyy-MM-dd) cleanly.
• Synthetic Preview Dataset: Built-in sample data with automatic report and group scope variable aggregations (Sum, Count, Average).
• Zero Arbitrary Code Execution: Pure lexical parser with 0 use of eval(), new Function(), or shell commands.

🎨 Style Inheritance & Visual Fidelity

• Cascading Style System: Full support for <style> hierarchies, parentStyle inheritance, and cyclic dependency protection.
• Per-Side Box & Pen Rendering: Renders topPen, bottomPen, leftPen, rightPen with custom line widths and styles (Solid, Dashed, Dotted, Double).
• Biaxial Text Alignment: Precision flexbox alignment matching JasperReports horizontal (Left, Center, Right, Justified) and vertical (Top, Middle, Bottom) alignment.
• JasperReports Styled Markup: Automatically parses and converts <style isBold="true"...>, <b>, <i>, <u>, <font> into safe HTML formatting.
• Text Rotation: Native support for rotated text (rotation="Left", Right, UpsideDown).

✏️ Bidirectional Editing & Safe XML Persistence

• AST-Based Serialization: Safely edits elements via AST transformations instead of fragile regex replacements.
• Deterministic Element IDs: Unique structural ElementId addressing prevents coordinate collisions.
• Preserved JRXML Integrity: Comments, CDATA blocks, expressions, and formatting remain intact upon saving.
• Properties Inspector: Real-time property editing (coordinates, dimensions, text, expressions, colors, fonts, borders).

🗂️ JRXML Explorer Sidebar

• JRXML Files Navigator: Browse all .jrxml files in the workspace with folder structure.
• Document Properties: Real-time inspection of report metadata, dimensions, margins, and variable counts.
• Element Hierarchy Tree: Expand bands and frames to inspect and highlight every visual element.

⚡ Navigation & Controls

• Interactive Zoom & Panning: Mouse wheel zoom (Ctrl/Cmd + Wheel), button controls, and click-and-drag panning.
• View Switching: Instant one-click toggle between visual canvas and XML source code editor.
• Standalone HTML Export: Export reports to self-contained HTML files with embedded SVG graphics and resolved styles.

📦 Installation

From VS Code Marketplace

1. Open Visual Studio Code.
2. Open the Extensions view (Ctrl+Shift+X / Cmd+Shift+X).
3. Search for JRXML Viewer & Editor (or YamidCuetoMazo.jrxml-viewer).
4. Click Install.

Command Palette Installation

Press Ctrl+P (or Cmd+P) and paste:

ext install YamidCuetoMazo.jrxml-viewer

🚀 Usage

Opening JRXML Files

1. Open any .jrxml file in VS Code.
2. The visual viewer opens automatically by default.
3. Switch Views:
   • Click the </> button in the editor toolbar to switch to the XML source code.
   • Right-click any .jrxml file in the File Explorer → "Open JRXML Source".
   • Use the JRXML Explorer sidebar to navigate reports.

Keyboard Shortcuts

• Ctrl/Cmd + +: Zoom in
• Ctrl/Cmd + -: Zoom out
• Ctrl/Cmd + 0: Reset zoom (100%)
• Ctrl/Cmd + Mouse Wheel: Smooth zoom
• Click + Drag: Pan the canvas
• Escape: Deselect element / close properties panel

Extension Settings

📝 Supported JasperReports Elements

🛣️ Roadmap

Completed ✅

• [x] Strongly-typed JRXML Document Model (AST)
• [x] Multi-layer Layout Engine & layer separation (BACKGROUND, CONTENT, FOOTER)
• [x] Pure Layout Renderer with transparent band canvases
• [x] Deterministic structural ElementId addressing
• [x] AST-driven safe XML persistence & properties editing
• [x] Safe expression evaluation ($P{}, $F{}, $V{}) & variable aggregations
• [x] Style cascade, inheritance & cycle detection
• [x] Real vector SVG charts (barChart, pieChart, lineChart)
• [x] JasperReports styled markup conversion (<style>, <b>, <i>, <u>)
• [x] 114 automated tests across 8 verification suites (100% passing)

In Progress 🚧

• [ ] Visual authoring palette (drag & drop new elements onto canvas)
• [ ] Interactive visual element resizing handles
• [ ] End-to-End Playwright visual regression suite

Planned 📋

• [ ] PDF export directly from VS Code
• [ ] Real-time JasperReports schema validation
• [ ] Common JRXML snippet templates & autocompletion
• [ ] Live JasperReports Server connector

📄 License

This project is licensed under the MIT License. See the LICENSE file for details.
