DB Connector Extension

A powerful VS Code extension for managing and querying multiple database connections. Supports MySQL, PostgreSQL, SQL Server (MSSQL), MongoDB, and MariaDB.

Features

• Multi-Database Support: Connect to MySQL, PostgreSQL, SQL Server, MongoDB, and MariaDB
• Secure Credential Storage: Passwords stored securely using VS Code's Secret Storage API
• Database Explorer: Tree view showing connections, databases, tables/collections, and columns/fields
• Query Editor: Execute SQL and MongoDB queries with syntax highlighting
• Results Viewer: View query results in a rich webview panel
• Query History: Track and replay previous queries
• Export Results: Export query results to CSV or JSON
• Multiple Connections: Work with multiple database connections simultaneously

Installation

From Source

1. Clone the repository
2. Run npm install to install dependencies
3. Run npm run compile to build the extension
4. Press F5 to run the extension in debug mode

From VSIX

1. Download the .vsix file
2. Open VS Code
3. Go to Extensions view (Ctrl+Shift+X)
4. Click the ... menu and select "Install from VSIX..."

Getting Started

Adding a Database Connection

1. Open the Database Connections view in the Explorer sidebar
2. Click the + icon or run the command "DB Connector: Add Database Connection"
3. Select your database type (MySQL, PostgreSQL, MSSQL, MongoDB, or MariaDB)
4. Enter connection details:
   • Connection name
   • Host
   • Port
   • Username
   • Password
   • Database (optional)
5. The extension will test the connection before saving

Connecting to a Database

1. In the Database Connections view, find your connection
2. Click the connect icon or right-click and select "Connect"
3. Once connected, expand the connection to view databases, tables, and columns

Executing Queries

SQL Databases (MySQL, PostgreSQL, MSSQL, MariaDB)

1. Right-click a connection and select "New Query"
2. Write your SQL query
3. Click the play icon in the editor toolbar or run "DB Connector: Execute Query"
4. Results will appear in a new panel

MongoDB

1. Right-click a MongoDB connection and select "New Query"
2. Write your MongoDB query in JavaScript format:

   db.collection('users').find({age: {$gt: 18}}).toArray()


3. Execute the query to see results

Viewing Query Results

Query results appear in a webview panel with the following features:

• Tabular View: Results displayed in a sortable table
• Export: Export results to CSV or JSON
• Copy: Copy results to clipboard
• Statistics: View row count and execution time

Configuration

Configure the extension through VS Code settings:

{
  "dbConnector.connectionTimeout": 30000,
  "dbConnector.queryTimeout": 60000,
  "dbConnector.maxQueryHistorySize": 100,
  "dbConnector.autoExpandTreeItems": false,
  "dbConnector.showRowCount": true,
  "dbConnector.resultPageSize": 1000
}

Configuration Options

• connectionTimeout: Connection timeout in milliseconds (default: 30000)
• queryTimeout: Query execution timeout in milliseconds (default: 60000)
• maxQueryHistorySize: Maximum number of queries to keep in history (default: 100)
• autoExpandTreeItems: Automatically expand tree items when connecting (default: false)
• showRowCount: Show row count in query results (default: true)
• resultPageSize: Number of rows to display per page (default: 1000)

Commands

• DB Connector: Add Database Connection - Add a new database connection
• DB Connector: Remove Connection - Remove a database connection
• DB Connector: Edit Connection - Edit connection settings
• DB Connector: Connect - Connect to a database
• DB Connector: Disconnect - Disconnect from a database
• DB Connector: Refresh Connection - Refresh the tree view
• DB Connector: Execute Query - Execute the current query
• DB Connector: New Query - Create a new query file
• DB Connector: Show Query History - View query history
• DB Connector: Export Results - Export query results

Keyboard Shortcuts

• Ctrl+Shift+E (or Cmd+Shift+E on Mac) - Execute query
• F5 - Execute query (when in SQL/MongoDB file)

Security

• Passwords are stored securely using VS Code's Secret Storage API
• Credentials are never stored in plain text
• Connections use SSL/TLS when configured
• SSH tunneling support for secure remote connections

Database Support

MySQL / MariaDB

• Full SQL syntax support
• View databases, tables, columns
• Execute queries and view results
• Support for stored procedures and functions

PostgreSQL

• Full SQL syntax support
• Schema and table exploration
• Support for custom types and extensions
• Transaction support

SQL Server (MSSQL)

• T-SQL syntax support
• Database and schema exploration
• Support for stored procedures
• Windows and SQL authentication

MongoDB

• JavaScript query syntax
• Collection and field exploration
• Document sampling for schema inference
• Support for aggregation pipelines

Development

Building from Source

# Install dependencies
npm install

# Compile TypeScript
npm run compile

# Watch for changes
npm run watch

# Build production bundle
npm run package

# Run tests
npm test

# Lint code
npm run lint

# Format code
npm run format

Project Structure

db-connector-extension/
├── src/
│   ├── extension.ts              # Extension entry point
│   ├── connectionManager.ts      # Connection management
│   ├── types.ts                  # TypeScript interfaces
│   ├── databaseProviders/        # Database-specific providers
│   │   ├── mysqlProvider.ts
│   │   ├── postgresProvider.ts
│   │   ├── mssqlProvider.ts
│   │   ├── mongoProvider.ts
│   │   └── mariadbProvider.ts
│   ├── treeView/                 # Tree view components
│   │   ├── databaseTreeProvider.ts
│   │   └── treeItems.ts
│   ├── queryEditor/              # Query execution
│   │   ├── queryExecutor.ts
│   │   └── resultsPanel.ts
│   └── utils/                    # Utilities
│       ├── encryption.ts
│       └── logger.ts
├── resources/                    # Icons and resources
├── package.json                  # Extension manifest
├── tsconfig.json                 # TypeScript config
└── webpack.config.js             # Webpack config

Contributing

Contributions are welcome! Please follow these guidelines:

1. Fork the repository
2. Create a feature branch
3. Make your changes
4. Add tests if applicable
5. Run linting and formatting
6. Submit a pull request

Troubleshooting

Connection Issues

• Verify host, port, username, and password
• Check firewall settings
• Ensure the database server is running
• Try enabling SSL if required

Query Execution Errors

• Check query syntax
• Verify you have permission to execute the query
• Check the database connection is active
• Review error messages in the output panel

Extension Logs

View extension logs:

1. Open the Output panel (Ctrl+Shift+U)
2. Select "DB Connector" from the dropdown

License

MIT License - see LICENSE file for details

Support

For issues, questions, or feature requests:

• Create an issue on GitHub
• Check existing issues for solutions
• Review the documentation

Roadmap

• [ ] SSH tunnel support
• [ ] Connection grouping
• [ ] Query autocomplete
• [ ] Schema diff tool
• [ ] Data editing in results
• [ ] Import/export connections
• [ ] Multi-query execution
• [ ] Query performance analytics

Acknowledgments

Built with:

• VS Code Extension API
• mysql2
• pg
• mssql
• mongodb
