D2 Workshop

A VS Code extension for Diablo II 1.13c modding. Browse MPQ archives, edit game data tables, view and edit DC6 sprites, patch binaries, and share mods.

Features

MPQ Archive Browser

• Browse MPQ archive contents in a tree view
• Virtual d2mpq:// filesystem lets you open files from MPQ archives directly
• Read and write files inside MPQ archives using StormLib

Table Editor

• Edit .txt data tables (armor.txt, skills.txt, monstats.txt, etc.) with a spreadsheet-style UI
• Schema-aware column descriptions and validation
• Queue changes before publishing to preserve the original files

DC6 Sprite Viewer & Editor

• View DC6 sprite images with palette rendering (Act 1-5 palettes + custom palette support)
• Three display modes: Composite (grid layout), Animation (frame-by-frame playback), Button (toggle states)
• Click-to-select, drag-and-drop frame repositioning with soft-snap to adjacent edges
• Right-click context menu: insert, delete, reorder frames
• Import PNG images as new frames with automatic palette mapping
• Properties panel with editable X/Y position and frame dimensions
• Auto-detection of animation files based on frame size and count
• GIMP integration: export as PNG (composite) or OpenRaster with layers (animation/button), import changes back

Binary Patcher

• Patch .dll and .exe files using schema-defined hex edits
• PE format parsing for RVA-to-file-offset conversion
• Verify and revert individual patches

Save Queue

• All changes are staged before applying
• Cell-level diffs show exactly what changed (row name, column, old/new values)
• Three-level tree view: file > row > column changes
• Publish atomically to avoid partial updates
• Automatic backups of original files before first publish

Mod Packages

• Export your changes as a shareable JSON mod package
• Import mod packages from other modders
• Conflict detection and resolution

Game Launcher

• Launch Diablo II directly from VS Code with configurable command-line flags

Schema Validation

• Columns that reference other .txt files show dropdowns or autocomplete with valid values
• Multi-file refs (e.g., item codes from armor/weapons/misc) merge all valid options
• Boolean flag columns (0/1) render as toggles
• Integer columns validate against min/max ranges
• Duplicate values are flagged on columns marked as unique keys

Custom Schema Overrides

You can override or extend the built-in schemas by placing .schema.json files in your workspace:

<workspace>/.d2workshop/schemas/txt/armor.schema.json

Workspace schemas take priority over the bundled ones. This is useful when your mod adds custom columns or changes valid values. The schema format:

{
  "file": "armor.txt",
  "description": "My custom armor schema",
  "columns": {
    "code": {
      "type": "string",
      "required": true,
      "unique": true,
      "description": "Item code"
    },
    "type": {
      "type": "string",
      "ref": "itemtypes.txt/code",
      "description": "Item type reference"
    },
    "spawnable": {
      "type": "integer",
      "format": "boolean",
      "description": "Can this item spawn"
    },
    "myCustomCol": {
      "type": "string",
      "values": ["opt1", "opt2"],
      "description": "My mod-specific column"
    }
  }
}

Schema properties: | Property | Description | |----------|-------------| | ref | Reference to another file: "file.txt", "file.txt/column", or "a.txt\|b.txt" for multi-file | | values | Inline array of valid values (when no .txt file to reference) | | format | "boolean" renders integer 0/1 as a toggle | | min / max | Integer range bounds | | required | Cell cannot be empty | | unique | No duplicate values allowed in this column |

Requirements

• VS Code 1.85.0 or later
• Node.js 18+ (for development)
• Python 3 (optional, for native StormLib DLL support on Windows)
• GIMP (optional, for sprite editing integration)

StormLib

The extension uses StormLib to read and write MPQ archives. On Windows, a 64-bit StormLib DLL is bundled at wasm/StormLib_x64.dll and accessed via a Python ctypes bridge. The extension falls back to a WASM backend or a stub if StormLib is unavailable.

Installation

From VSIX

1. Download the .vsix file from Releases
2. In VS Code: Extensions > ... menu > Install from VSIX
3. Open a folder containing your Diablo II game files (.mpq files, Game.exe)

From Source

git clone https://github.com/bethington/d2-workshop.git
cd d2-workshop
npm install
npm run build

Then press F5 in VS Code to launch the Extension Development Host.

Usage

1. Open your Diablo II installation folder as a VS Code workspace
2. The D2 Workshop icon appears in the activity bar
3. Expand MPQ archives in the Game Files tree to browse contents
4. Click a .txt file to open the Table Editor, or a .dc6 file for the Sprite Viewer
5. Make your edits, then click Queue Save
6. Review changes in the Save Queue panel
7. Click Publish to write all changes to the MPQ archives

Configuration

Project Structure

src/
  extension.ts           Entry point
  mpq/                   MPQ archive reading/writing via StormLib
  providers/             VS Code editors, tree views, filesystem
  dc6/                   DC6 sprite parsing, encoding, palette handling
  binary/                Binary patching and PE parsing
  mod/                   Save queue, mod packages, conflict resolution
  launch/                Game launcher
  webviews/              React-based editor UIs
schemas/                 Table and binary patch schemas
wasm/                    StormLib DLL and Python helpers

Building

npm run build            # Build extension + webviews
npm run build:prod       # Production build (minified)
npm run watch            # Watch extension for changes
npm run watch:webviews   # Watch webviews for changes
npm run lint             # Run ESLint
npm run test             # Run tests

License

MIT
