Apache Flink SQL Notebook & Toolkit for VS Code

Transform your editor into a powerful Stream Processing and Big Data workstation. Write, debug, and execute Flink SQL queries in real-time. Manage your Flink clusters, explore catalogs, and monitor jobs without leaving VS Code.

Designed for Data Engineers, Platform Engineers, and Data Scientists working with Apache Flink, Kafka, and Real-time Analytics.

✨ Why this Extension? (Key Features)

• 📓 Interactive Notebooks:

  • Run Flink SQL interactively in .fsqlnb or .flinksql files.
  • Live Streaming Results: Watch your streaming data flow in real-time within the editor.
  • Sorting & Filtering: Client-side analysis of result sets. Export to CSV/JSON.

• ⚡ Intelligent Coding:

  • Context-Aware Autocomplete: Smart suggestions for Tables, Views, Columns, and Functions.
  • Snippet Library: Built-in templates for Kafka Connectors, DataGen, Window TVFs (TUMBLE, HOP), and more.
  • Syntax Highlighting: Dedicated support for Flink SQL dialect.

• 🔍 Cluster Explorer:

  • Metadata Browser: Navigate Catalogs, Databases, Tables, and Views.
  • One-Click Actions: Right-click to "Script SELECT" or "Copy CREATE TABLE" statements.
  • View Schema: Instantly check column types and table properties.

• 🛡️ Job & System Management:

  • Job Monitoring: View Running and Completed jobs.
  • Control: Cancel jobs directly from the sidebar.
  • Deep Dive: Open the Flink Dashboard for specific jobs with a single click.
  • System Health: Monitor TaskManagers, Slots, and resource usage.

🚀 Zero to Hero: Quick Start Guide

Follow these steps to run your first Flink SQL streaming job in minutes.

1. Prerequisites

• VS Code: v1.85+
• Apache Flink Cluster: Running (v1.16+ recommended).
• Flink SQL Gateway: Must be running (default port 8083).

2. Setup

1. Install Flink SQL Toolkit from the VS Code Marketplace.
2. Open VS Code and navigate to the Flink Activity Bar (Flink Logo).
3. Click "Configure Connection" (or run command Flink: Configure Connection).
   • Gateway URL: http://localhost:8083
   • JobManager URL: http://localhost:8081

3. "Hello World" Streaming Job

Create a new file named demo.fsqlnb or demo.flinksql and paste the following:

-- 1. Create a Source Table (Data Generator)
CREATE TABLE orders (
    order_id BIGINT,
    price DECIMAL(10, 2),
    buyer STRING,
    order_time TIMESTAMP(3)
) WITH (
    'connector' = 'datagen',
    'rows-per-second' = '1'
);

-- 2. Create a Sink Table (Print to Console/Log)
CREATE TABLE print_sink (
    order_id BIGINT,
    price DECIMAL(10, 2),
    buyer STRING
) WITH (
    'connector' = 'print'
);

-- 3. Run a Continuous Query
INSERT INTO print_sink
SELECT order_id, price, buyer
FROM orders
WHERE price > 10;

Run it! Click the "Run" lens (or Ctrl+Enter). You will see the job submitted and results streaming (for SELECT queries) or job ID returned (for INSERT).

⚙️ Configuration

You can customize the extension via .vscode/settings.json:

💡 Pro Tips

• Invalid Session? No problem. The extension automatically recovers invalid sessions by creating a new default session, so you never lose your flow.
• Column Autocomplete: Type SELECT t. to see column suggestions for table aliased as t.
• Drag & Drop: Drag a table from the Explorer into your editor to insert its full name.

🔧 Troubleshooting

"Session is invalid" loop?

• Ensure your Flink SQL Gateway is running and accessible.
• Check logs: View > Output > Flink SQL Toolkit.

"Failed to fetch metadata"?

• Verify the gatewayUrl in settings.
• Ensure Flink is listening on the correct host/port (docker containers might need host networking or port mapping).

🤝 Contributing & Support

Found a bug? Want a feature? Open an Issue on GitHub

License: MIT
