LCH Markdown Code Runner

Introduction

Source code: LCHMarkdownCodeRunner

LCH Markdown Code Runner is a VS Code extension that allows you to run code blocks directly from Markdown files.

For example, given the following content in a Markdown file:

#GM[port=8080, debug=true]
eval('print("Hello, World!")')

this has been rendered as python code block. you need to wrap it with ```python ``` in your file like this:

```python #GM[port=8080, debug=true] eval('print("Hello, World!")') ```

And the following in your settings.json:

"lchMarkdownCodeRunner.gmConfigs": {
    "GM": {
        "scriptPath": "test/test_script.py",
        "commandTemplate": "python {scriptPath} {args}",
        "passCodeAsStdin": true,
        "passCodeAsFile": false,
        "timeout": 15000
    }
}

This will call the test/test_script.py script, passing --port=8080 --debug=true as arguments, and the code block content via stdin.

The matching rule is #GM[...], where GM is the config name and [...] is parsed as arguments. It supports both [port=8080, debug=true] and [8080, true] formats.

Matching code blocks will display a "Run" button above them. Clicking it executes the code block, making your documentation highly interactive.

Example test/test_script.py:

#!/usr/bin/env python3
# -*- coding: utf-8 -*-
# test_script.py

import sys
import argparse
import os

def main():
    print("\n🟦🟦🟦 BEGIN {} 🟦🟦🟦\n".format(os.path.basename(__file__)))
    print("🚩  Python Markdown Runner")
    print("🟢 Args:")
    print("   ", sys.argv)

    if not sys.stdin.isatty():
        code = sys.stdin.read()
        if code.strip():
            print("\n⭐ Markdown Code Content:")
            print(code)
            print("\n⭐ Exec:")
            exec(code)
    print("\n🟦🟦🟦 END 🟦🟦🟦\n")

if __name__ == "__main__":
    main()

Sample output:

==================================================
Running Python code from e:\LCHMarkdownCodeRunner\README.md
{
  "scriptPath": "test/test_script.py",
  "commandTemplate": "python {scriptPath} {args}",
  "passCodeAsStdin": true,
  "passCodeAsFile": false,
  "timeout": 15000
}
GM Identifier: GM
Script Path: test/test_script.py
Command Template: python {scriptPath} {args}
Pass Code As Stdin: true
Pass Code As File: false
Timeout: 15000
GM Directive args: []
GM Directive params: {"port":"8080","debug":"true"}
==================================================
Code to execute:
──────────────────────────────
eval('print("Hello, World!")')
──────────────────────────────
Executing: python test/test_script.py --port=8080 --debug=true

🟦🟦🟦 BEGIN test_script.py 🟦🟦🟦

🚩  Python Markdown Runner
🟢 Args:
    ['test/test_script.py', '--port=8080', '--debug=true']

⭐ Markdown Code Content:
eval('print("Hello, World!")')

⭐ Exec:
Hello, World!

🟦🟦🟦 END 🟦🟦🟦

──────────────────────────────────────────────────
Process exited with code: 0
✅ Execution completed successfully

Configuration

GM Configurations

Configure different GM identifiers in your VS Code settings:

"lchMarkdownCodeRunner.gmConfigs": {
    "GM": {
        "scriptPath": "test/test_script.py",
        "commandTemplate": "python {scriptPath} {args}",
        "passCodeAsStdin": true,
        "passCodeAsFile": false,
        "timeout": 15000
    },
    "GM2": {
        "scriptPath": "another_script.py",
        "commandTemplate": "python {scriptPath} {args}",
        "passCodeAsStdin": false,
        "passCodeAsFile": true,
        "timeout": 30000
    },
    "GM3": {
        "scriptPath": "http_gateway/python_gateway/lch_gateway_cli.py",
        "commandTemplate": "python {scriptPath} {args}",
        "passCodeAsStdin": true,
        "passCodeAsFile": false,
        "timeout": 3000
    }
}

Run Button Customization

You can customize the appearance of the run button:

Run Button Text

Set custom text for the run button:

"lchMarkdownCodeRunner.runButtonText": "🚀 Execute Code"

Run Button Icon

Choose from various icons for the run button:

"lchMarkdownCodeRunner.runButtonIcon": "🚀"

Available icons: ▶️, 🚀, ⚡, 🔥, 💫, 🎯, ⭐, 🌟, ✨, 🎪, 🎨, 🎭, 🎲, 🎊, 🎉

Note: If you set a custom runButtonText, it will override the icon setting. If you only set the runButtonIcon, it will be combined with the default text "Run Code".

Configuration Priority

• If runButtonText is customized: Uses the custom text exactly as specified
• If only runButtonIcon is set: Uses the selected icon + "Run Code"
• If neither is set: Uses the default "▶️ Run Code"

Installation

1. Search for LCH Markdown Code Runner in the VS Code Extensions Marketplace and install it.
2. Or download the .vsix file and install manually.

more Examples

For an advanced example of how to set up an HTTP gateway to send commands to a running application, see the HTTP Gateway Example.

License

MIT License
